Use Sites
Initialization Script
Modem Timeout
Caller ID Logging
Modem Command
Dial-Back Number
Dial-Back Delay
Dial-Back Retries

Modem Settings: Text Mode

Timeout Logins
Dial-in Host List
SLC™ 8000 Advanced Console Manager User Guide
Enables the use of site-oriented modem parameters which can be activated by
various modem-related events (authentication, outbound network traffic for dial-
on-demand connections, etc.). Sites can be used with the following modem
states: dial-in, dial-back, dial-on-demand, dial-in & dial-on-demand, dial-back &
dial-on-demand, and CBCP server.
Commands sent to configure the modem may have up to 100 characters. Consult
your modem's documentation for recommended initialization options. If you do
not specify an initialization script, the SLC unit uses a default initialization string of
AT S7=45 SO=0 L1
Note: We recommend that the modem initialization script always be preceded
with AT and include E1 V1 x4 Q0 so that the SLC 8000 advanced console
manager may properly control the modem. For information on AT commands,
refer to the modem user guide, or do a web search for
Serial modems may need to include &B1 in the modem initialization string to set
the DTE rate to a fixed baud rate.
Timeout for all modem connections. Select Yes (default) for the SLC un
terminate the connection if no traffic is received during the configured idle time.
Enter a value of from 1 to 9999 seconds. The default is 30 seconds.
Select to enable the SLC advanced console manager to log caller IDs on
incoming calls. Disabled by default.
Note: For the Caller ID
AT
Modem command used to initiate caller ID logging by the modem.
AT
Note: For the command, refer to the modem user guide.
AT
Users with dial-back access can dial into the SLC device and enter their login and
password. Once the SLC 8000 advanced console manager authenticates them,
the modem hangs up and dials them back.
Select the phone number the modem dials back on -a fixed number or a number
associated with their login. If you select Fixed Number, enter the number (in the
format 2123456789).
The dial-back number is also used for CBCP client as the number for a user-
defined number. See Device Ports - Settings (on page 160)
For dial-back and CBCP Server, the number of seconds between the dial-in and
dial-out portions of the dialing sequence.
For dial-back and CBCP Server, the number of times the SLC unit will retry the
dial-out portion of the dialing sequence if the first attempt to dial-out fails.
If you selected Text mode, you can enable logins to time out after the connection is
inactive for a specified number of minutes. The default is No. This setting is only
applicable for text mode connections. PPP mode connections stay connected until
either side drops the connection. Disabled by default.
From the drop-down list, select the desired host list. The host list is a prioritized list
of SSH, Telnet, and TCP hosts that are available for establishing outgoing modem
connections or for connect direct at the CLI. The hosts in the list are cycled
through until the SLC 8000 advanced console manager successfully connects to
one.
To establish and configure host lists, click the Host Lists link.
V1 X4 &D2 &c1
command, refer to the modem user guide.
9: Device Ports
.
E1 Q0
.
at command set
it
to
for more information.
168
