Parts List - Maxxus 8.1 Operating Manual And Assembly Manual

Description
Part
93 Wire to controller
94 Inner hex full thread screw
95 Screw
96 Fan
97 Tube plug
98 Decorate rail
99 Wire clip
100 Spring cushion
101 Cross Allen screw
102 Computer Wire
103 Cross self-taping screw
104 Cross allen full head screw
Description
Part
47 Complete computer
47-1 Computer housing(up)
47-2 Computer housing(down)
47-3 Computer front cover
47-4 The swinging plate
47-5 air outlet left
47-6 air outlet right
47-7 Fan
47-8 Speaker
47-9 Safety key metal sheet
47-10 Safety key press part
47-11 Safety sensitive switch
47-12 Safety key sticker
47-13 Cross screw M4*40
47-14 Console overlay
47-15 PCB board
47-16 PCB board for big buttons
47-17 PCB board for small buttons
47-18 Earphone socket(for option)
47-19 Safety key pull part
47-20 Spring

Parts List

Size
M8*15
M8*65
Ø19.5xØ14.2x8.5
M5x15
ST4x12
M3x28
Parts - Cockpit
Size
M4x40
25
Qty
1
4
1
1
2
2
1
Ø8 2
2
1
14
4
Qty
1
1
1
1
1
1
1
1
2
1
1
1
1
2
1
1
1
1
1
1
1
