Maxxus 7.3 Installation & Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Treadmill
MAXXUS 7.3
ENG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7.3 and is the answer not in the manual?

Questions and answers

Related Manuals for Maxxus 7.3

Summary of Contents for Maxxus 7.3

  • Page 1 Treadmill MAXXUS 7.3...

  • Page 2: Table Of Contents

    Maxxus Group GmbH & Co. KG. Errors, colour and technical modification subject to change, reproduction as well as electronic duplication only with written permission of MAXXUS Group GmbH & Co. KG.

  • Page 3: Safety Instructions

    Safety Instructions Before you start exercising, be sure to read the entire user guide, especially the safety information, the maintenance & cleaning infor- mation and the training information. Make sure also that everyone who uses this training device is also familiar with this information and observes it.
  • Page 4 Product Overview Cockpit Shelf Safety Key Hand pulse sensor Side frame Motor housing Running Deck Tread Cushion-Flex ™ cushioning system Parts and Tools Bevel head Allen screw Dome head Allen screw M8x20 M8x50 8 pieces 4 pieces Allen key Allen key Allen key You are welcome to supplement or replace the tools included with your own.

  • Page 5: Scope Of Delivery

    Scope of Delivery Cockpit Base Frame Screw Set Safety Key Side Frames Assembly Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are bulky and heavy. Check that all the parts and fixing materials (screws, nuts, etc.) have been delivered. Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not covered by the warranty or guarantee.

  • Page 6: Assembly

    Assembly Step 2: Ideally, you will need two people for this step. As person A holds the cockpit, person B joins the cable where it protrudes up out of the right Side frame, with the cable that protrudes from the right side of the cockpit frame. Now carefully insert the cockpit into the two side frames and attach it to both side frames with two hexagon socket screws M8x20.

  • Page 7: Folding Mechanism

    Folding mechanism This treadmill is equipped with a folding mechanism. To save space fold the treadmill deck up and down as follows: Fold up the tread Step 1: Make sure that the slope of the treadmill is set to level „0“, and is turned off at the main switch.Remove the treadmill the mains plug from the socket.

  • Page 8: Transport

    Transport When folded up, the treadmill can be moved without much effort. To move the treadmill please proceed as follows: Step 1: Fold up the tread as in the chapter „Folding mechanism“ descri- bed above. Then grasp the tread on the upper right and left with both hands and pull the tread towards you until the weight of the treadmill can be felt on the transport wheels.

  • Page 9: Mains Cable

    Mains cable Mains cable Connect the mains plug of the mains cable into a socket. The device must only be connected to a professionally installed, earthed mains socket. Connecting the treadmill no multiple sockets. If an extension cable is required, then it must comply with DIN standards, VDE regulations and guidelines, technical ru- les issued by other European Union member states or other states which are party to the Agreement on the European...

  • Page 10: What To Do In An Emergency

    What to do in an Emergency Safety Distance Select a location so that there is a clear space behind the treadmill of at least 200 cm and a width of at least 100 cm for the full length of the treadmill on the right and left sides during exercise. What to do in an Emergency Stop exercise immediately if you feel that you cannot keep up with the pace, you feel sick or if another emergency situation arises, immediately pull the saftey key out with the cord to make an emergency stop.

  • Page 11: Care, Cleaning & Maintenance

    Care, cleaning & maintenance WARNING Turn off your training device before you carry out care, cleaning, maintenance, repair or similar work and remove the power cord. Always check that the equipment is completely disconnected from the mains and switched off before starting work.

  • Page 12: Lubricating The Treadmill Belt

    To lubricate the running belt properly take the MAXXUS care oil bottle, remove the regular screw cap (Diagram 1) and then insert the screw cap with tube (Diagram 2). Before you start to lubricate make sure the treadmill is off and the running belt is not moving.
  • Page 13 Adjusting the running belt The treadmill must always be switched off and the mains plud disconnected from the power socket. before maintenance, cleaning, repair or other work is performed! The running belt should always run straight and in the middle of the deck to achieve as long a service life as possible.

  • Page 14: Cockpit

    Cockpit LCD display Direct dial keys - slope Control buttons - gradient Speed dial buttons - km / h Control buttons - km / h PROGRAM button MODE button START / STOP button The display informs you about the following training values: CAL* Energy consumption in kcal TIME...
  • Page 15 Cockpit STOP button Stop / Pause function: Press the STOP / RESET button once to stop the treadmill. The cockpit switches to pause mode for 5 minutes. If the START button is pressed again within these 5 minutes, the training continues as it was when it was inter- rupted.
  • Page 16 Cockpit Step 3: Training start After entering the desired workout values, press the START button. The display will show a countdown displayed. Each countdown value is accompanied by an acoustic signal. After completion of the countdown the treadmill starts automatically. End of training The treadmill stops automatically after the specified training goal has elapsed.
  • Page 17 Cockpit Segment Programm SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE...

  • Page 18: Cockpit

    Cockpit Heart rate controlled programs (HRC 1, HRC 2 and HRC 3) These programs are heart rate controlled exercise programs. Here the user pre-sets a desired target heart rate. This is constantly compared from the cockpit with the actual heart rate of the user. If the actual heart rate is lo- wer than the desired target heart rate, the treadmill automatically increases the speed.

  • Page 19: Heart Rate Monitoring

    Heart Rate Monitoring 100% of maximum heart rate of maximum heart rate of maximum heart rate of maximum heart rate Calculating your personal heart rate when training Calculate your personal heart rate when training as follows: 220 - Age = maximum heart rate This value represents your maximum heart rate and serves as a basis from which to calculate your personal training heart rate.
  • Page 20 Heart Rate Monitoring using Chest Belt A large number of MAXXUS® training devices are already fitted with a receiver as standard which allows you to wirelessly measure heart rate. We recommend the exclusive use of an uncoded POLAR® chest belt which is available as an accessory.

  • Page 21: Technical Details

    Home – only for private use! Recommended accessories These accessories are the perfect supplement for your training device. All products are available in our online shop at www.maxxus.de or directly in our showroom in Gross-Gerau. POLAR® Transmitter chest strap T34 Chest strap for determining the heart rate with optimized transmission ran- ges.

  • Page 22: Exploded Drawing

    Exploded Drawing...

  • Page 23: Parts List

    Part List Part-Nr. Description Part-Nr. Description Base Frame Decorate side rail Platform Frame End cover (left) Incline Frame End cover (right) Right Upright frame Inner hex bolt M10x45x20 1 Left Upright frame Cross bolt Computer frame Motor base frame Wheel Ø62 Ezfit linking parts Computer Inner hex half thread bolt M10x60x20...

  • Page 24: Warranty

    The warranty period for your training device starts on the date of purchase and applies solely to products which were purchased direct- ly from the MAXXUS Group GmbH & Co KG or one of the MAXXUS Group GmbH & Co KG direct and authorised distribution partners.

  • Page 25: Repairs Contract / Notification Of A Damage Claim

    I accept the General Terms and Conditions of MAXXUS® Group GmbH & Co. KG. I hereby instruct the company MAXXUS® Group GmbH & Co. KG to repair the above defects. In Warranty cases I will not be char- ged for the cost. The costs for repairs which are excluded from liability for defects in quality will be charged to me and must be settled immediately.

  • Page 26: Notes

    Notes...

  • Page 27: Notes

    Notes...
  • Page 28 Maxxus Group GmbH & Co. KG Zeppelinstr. 2 D-64331 Weiterstadt Germany E-Mail: info@maxxus.de www.maxxus.de...
