  • Page 1 Treadmill MAXXUS 8.1...

  • Page 2: Table Of Contents

    Alle Rechte vorbehalten / All rights reserved Die Verwertung der Texte und Bilder, auch auszugsweise, ist ohne die schriftliche Zustimmung der MAXXUS Group GmbH & Co. KG urheberrechtswidrig und strafbar. Dies gilt auch für Vervielfältigung; Mikroverfilmung und die Verarbeitung mit elektronischen Systemen.

  • Page 3: Safety Instructions

    Safety Instructions Please read and observe all sections of this Operating Manual. Thorough attention should be paid to the safety, service and maintenance instructions and to the training information at all times It is very important to adhere strictly to the service and maintenance instructions contained in this Manual. This training device is only to be used for its intended purpose.

  • Page 4: Scope Of Delivery

    Overview of the Device Cockpit Shelf Safety Key/ EMERGENCYButton Housing Motor Hand Sensors & Hand Rail Control Side Frame Running Deck Treadmill Deck Scope of Delivery Covers Cockpit Side Frame Base Frame Assembly Material & Tools Hexagonal head screw (30) M4x20 4 Pieces Hexagonal head screw (94)

  • Page 5: Assembly

    Assembly Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are bulky and heavy. Check that all the parts and fixing materials (screws, nuts, etc.) have been delivered. Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not covered by the warranty or guarantee.

  • Page 6: Assembly

    Assembly Step 3: Ideally, you will need 2 people for this step. Person A holds the cockpit and person B connects the cable protruding from the right-hand side frame to the cable coming out of the right-hand side of the cockpit frame Carefully place the cockpit into the two side frames and attach it on each side with two hexagonal head screws 8x50 (19).

  • Page 7: Folding Mechanism

    Folding Mechanism This treadmill is equipped with a folding mechanism. To save space, fold the treadmill deck up and down as follows: CAUTION: Only fold up the treadmill deck if: - the treadmill has been turned off at the mains switch - the incline is at 0% - the mains cable plug is removed from the socket.

  • Page 8: Hydraulic Cylinder

    Hydraulic Cylinder Hydraulic Cylinder The folding mechanism relies on a hydraulic cylinder. This is filled with oil under high pressure. If a cylinder is damaged; the safe folding of the treadmill deck is no longer guaranteed. It must then be replaced before raising the treadmill deck again. Hydraulic Cylinder Safety Lever Transport...

  • Page 9: Safety Key

    Safety Key Safety Key and EMERGENCY button The treadmill will only operate if the safety key is correctly in contact with contact point in the cockpit. The treadmill will stop automatically if the safety key is no longer in contact. Before each training session make sure to attach the safety key to your clothing with the clip.

  • Page 10: What To Do In An Emergency

    What to do in an Emergency Safety Distance Select a suitable place to keep your training device with a free safety area space of at least 200 cm long and 100 cm wide behind the training device. Furthermore, during training, a safety distance down the length of the treadmill with a minimum width of 100 cm should be kept to the right and/or left-hand side of the treadmill.

  • Page 11: Care, Cleaning & Maintenance

    Care, Cleaning & Maintenance CAUTION: Before you perform any care, cleaning, maintenance, repair or similar work on your training device, turn off your exerciser and remove the power cord. Check before starting the planned work that your exerciser is completely disconnected and switched off. Only when all work is fully completed, and the device is completely re-assembled, may the training device to be reconnected to the mains and turned on.

  • Page 12: Lubricating The Treadmill Belt

    To achieve optimum lubrication of the belt, use the MAXXUS maintenance oil bottle, remove the normal screw bottle top (Diagram 1) and screw on the thin tube top (Diagram 2). Before lubricating the belt, make sure that the treadmill is switched-off and that the belt is no longer moving.

  • Page 13: Adjusting The Treadmill Belt

    Adjusting the Treadmill Belt The treadmill belt must always be switched off and the mains cable plug removed from the socket before starting any maintenance, cleaning, repairs or any other works! To achieve as long a service life as possible, the belt should always be kept running straight along the centre of the deck.

  • Page 14: Cockpit

    Cockpit Ventilator LCD-Display Quick Select Key – Incline Control Key - Incline Ventilator On-/Off-Key Control Key - km/h Quick Select Key - km/h PROGRAM Key MODE Key START/STOP Key The display of the display informs you about the following training values: CAL* Energy consumption in kcal TIME...
  • Page 15 Cockpit STOP Key Stop/Pause Function: Press the STOP/RESET key once and the treadmill belt will stop. The cockpit will switch into pause mode for 5 minutes. If the START key is pressed in these five minutes, training will continue from where it stopped. After the five- minute break, the cockpit will automatically reset, and all values will be set back to Zero.
  • Page 16 Cockpit Selecting the Training Distance: Press the MODE key twice. The value "1.00" flashes in the display field for "DISTANCE". Enter the desired distance from 0.5 to 99.5km by pressing the keys for SPEED or INCLINE. Selecting the Calorie Consumption: Press the MODE key three times.
  • Page 17 Cockpit Program S9 S10 S11 S12 S13 S14 S15 S16 km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h Incline km/h...
  • Page 18 Cockpit Heart Rate-Controlled programs (HRC) These programs are heart rate-controlled exercise programmes. The user specifies a target heart rate. This is continuously compared with the actual heart rate of the user by the cockpit. If the actual heart rate is lower than the target heart rate, the treadmill automatically increases the speed. If the value is higher, the treadmill automatically reduces the speed.

  • Page 19: Cockpit

    Cockpit Free Memory Space U01, U02 and U03 Here there are 3 free memory slots for individual training profiles. Step 1: Program Selection After switching the treadmill on „P0“ will appear on the display. Select the memory slot you want from U01, U02 or U03 using the “P”...

  • Page 20: Heart Rate Monitoring

    Heart Rate Monitoring 100% of maximum heart rate of maximum heart rate of maximum heart rate of maximum heart rate Calculation of the individual training heart rate Your individual training heart rate is calculated as follows: 220 - Age = maximum heart rate This value sets your maximum heart rate and serves as the basis for the calculation of the individual training heart rate.

  • Page 21: Pulse Rate Monitoring Using Hand Sensors

    Heart Rate Measurement via Chest Belt Many MAXXUS® training devices are already fitted with a receiver as standard. Using a chest belt (we recommend the exclusive use of an uncoded POLAR® chest strap) allows you to wirelessly measure heart rate. The chest belt is as accessories available.

  • Page 22: Technical Details

    Counteracts static build-up on the frame, trim parts and training computer. Devices that stand on carpets or synthetic flooring, charge up static. The MAXXUS® anti-static spray prevents this. Treated synthetic surfaces do not attract the dust so quickly and stay clean longer.

  • Page 23: Exploded Drawing

    Exploded Drawing...

  • Page 24: Parts List

    Parts List Description Size Description Size Part Part Base fame 47 Computer up cover 48 Computer down cover Platform frame 49 Switch Incline frame 50 Hand bar cover Motor base frame 51 Motor cover left Left Upright frame 52 Motor cover middle Right Upright frame 53 Motor cover right Computer frame...

  • Page 25: Parts List

    Parts List Description Size Part Wire to controller Inner hex full thread screw M8*15 Screw M8*65 Tube plug Ø19.5xØ14.2x8.5 Decorate rail Wire clip 100 Spring cushion Ø8 101 Cross Allen screw M5x15 102 Computer Wire 103 Cross self-taping screw ST4x12 104 Cross allen full head screw M3x28 Parts - Cockpit...

  • Page 26: Warranty

    The warranty period for your training device starts on the date of purchase and applies solely to products which were purchased directly from the MAXXUS Group GmbH & Co KG or one of the MAXXUS Group GmbH & Co KG direct and authorised distribution partners.
  • Page 27 I acknowledge the General Business Terms and Conditions of Maxxus Group GmbH & Co. KG. I hereby instruct the company Maxxus Group GmbH & Co. KG to repair the above-mentioned fault. In Warranty cases I will not be charged for the costs. The costs for repairs which are excluded from liability for defects in quality will be charged to me and must be settled immediately.
  • Page 28 Maxxus Group GmbH & Co. KG Zeppelinstr. 2 w D-64331 Weiterstadt Germany E-Mail: info@maxxus.de www.maxxus.de...
