Frequency Converter
VFC 3610 / VFC 5610 Series
Quick Start Guide
Edition 16
R912005518

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFC 3610 and is the answer not in the manual?

Questions and answers

Mohd.Shamim Akhtar
April 22, 2025

What is external analog atAI1 parametre setting?

0
1 comments:
Mr. Anderson
May 11, 2025

The external analog input at AI1 for the REXROTH VFC 3610 can be set as either a voltage input or a current input. The settings are:

- Voltage input range: 0/2...10 V
- Input impedance: 27 kΩ
- Current input range: 0/4...20 mA
- Input impedance: 250 Ω

To switch between voltage and current input or to set related functions, refer to Group E1 settings.

This answer is automatically generated

0
victor
March 4, 2025

why is my vfc 36100 running at 50 htz on manual status but running at 10 when on auto status

0
1 comments:
Mr. Anderson
March 4, 2025

The REXROTH VFC 3610 runs at 50 Hz in manual status because the digital setting frequency (E0.07) and output frequency limits (E0.08 and E0.09) are set to 50 Hz by default. In auto status, the frequency may be limited by other parameters, such as a lower setting frequency in automatic mode or restrictions based on control settings. The difference could be caused by auto-tuning adjustments, predefined limits in automatic operation, or control logic that reduces the frequency for specific conditions. Checking the auto mode frequency settings and related parameters would help identify the exact reason.

This answer is automatically generated

0
VICTOR
March 4, 2025

**** HAVING ERROR 5 ON VFC 36100

0
1 comments:
Mr. Anderson
March 4, 2025

Error 5 on the REXROTH VFC 3610 corresponds to "APE5," which indicates "Application error 5."

This answer is automatically generated

0
