Specifications - Lectrosonics M2T-X Series Instruction Manual

Specifications

RF Power Output:
Antenna Output:
Operating Frequencies:
NOTE: It's the user's responsibility to select the approved
frequencies for the region where the transmitter is operating
Frequency Selection
Steps:
Frequency Stability:
Modulation:
Emission Designator:
Spurious Radiation:
Encryption:
Equivalent input Noise:
Latency: (overall system)
Digital Source:
Analog Source:
Audio Frequency
Response:
Audio Input:
Audio Input Jack:
Input impedance:
Dante Connection:
Ethernet Connection:
USB Connection:
IRDA:
Headphone jack
Power Requirements:
Power Consumption:
Weight:
Dimensions:
Specifications subject to change without notice.
Rio Rancho, NM
• Two carriers; two audio
channels each
• M2T: Power adjustable on each carrier to
10, 25 or 50 mW
• M2T/E06: Power adjustable on each carrier to
20, 50 or100 mW EIRP
2 x BNC sockets
M2T: 470.100 – 607.975 MHz
M2T/E01: 470.10 – 614.375 MHz
M2T/E06: 520.000 - 614.375 MHz
25 kHz
± 0.002%
8 PSK
200KG7E
M2T: Compliant with ETSI EN 300 422-1
E01: Compliant with ETSI EN
300 422-1 v2.1.2
AES 256-CTR (per FIPS 197 and
FIPS 140-2)
–128 dBV
1.0 ms plus Dante network
(on Dante unit)
<1.4 ms
M2T: 10 Hz – 12 kHz, +0, -3 dB
M2T/E01: 20 Hz - 15 kHz, -3 dB
-10 dBV or +4 dBu settings
w/ ±5 dB trim
4 x combo XLR/TRS connectors
Line: 2k Ohm
2 x RJ45, 4 audio RX channels,
internally routable
RJ45
Micro USB on front panel for
firmware updates
IR transceiver for sync of receivers
3.5 mm stereo jack
9-18 VDC
5 Watts
2.2 lbs (997.903 grams)
Height: 1.750 in. / 44.45 mm
Width: 8.375 in. / 212.7 mm
Depth: 7.750 in. / 196.8 m.
Digital IEM Transmitter
17
