Specifications and Features

Operating Frequency Range:
HMa:
HMa/X:
HMa/E01:
HMa/E02:
HMa/E06:
HMa-941:
HMa/E07-941:
NOTE: It's the user's responsibility to select the
approved frequencies for the region where the
transmitter is operating
Frequency Selection Steps:
RF Power output:
Compatibility Modes:
Pilot tone:
Frequency stability:
Spurious radiation:
Equivalent input noise:
Input level:
Input impedance:
Input limiter:
Gain control range:
Operating temp. range:
16
Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.950
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band B2: 563.200 - 639.900
Band C1: 614.400 - 691.175
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
Band C2: 640.000 - 713.900
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
941.525 - 951.975
952.875 - 956.225
956.475 - 959.825
941.525 - 951.975
953.025 - 956.225
956.475 - 959.825
Selectable; 100 kHz or 25 kHz
HMa: Selectable 100 or 50 mW
HMa/E01: Selectable 25 or 50 mW
HMa/E02: 10 mW
HMa/E06: Selectable 50
or 100 mW EIRP
HMa/E07-941: Selectable 50 or 100 mW
HMa-941: Selectable 50 or 100 mW
HMa: Nu Hybrid, Mode 3, IFB Mode
HMa/E01: Digital Hybrid, Mode 3, IFB Mode
HMa/E02: Digital Hybrid, Mode 3, IFB Mode
HMa/E06: Digital Hybrid,Mode 3, IFB Mode
HMa/E07-941, HMa-941: Nu Hybrid, IFB Mode
HMa/X: Digital Hybrid, Mode 3, 200 Mode, 100
Mode, Mode 7, Mode 6, IFB Mode
25 to 32 kHz; 5 kHz deviation
(in the Digital Hybrid mode)
± 0.002%
HMa/E01/E02/941/X:
60 dB below carrier
HMa: Compliant with ETSI EN
300 422-1 v1.4.2
–125 dBV (A-weighted)
Nominal 2 mV to 300 mV, before limiting.
Greater than 1V maximum, with limiting.
1K Ohm
Dual envelope "soft" limiter; greater
than 30 dB range
55 dB; panel mounted
membrane switches
Celsius: -20° - 40°
Farenheit: -5° - 104°
Modulation indicators:
Audio Performance (overall system):
Frequency Response:
Low frequency Roll-off:
THD:
Signal to Noise Ratio (dB) at receiver output:
Note: The dual envelope "soft" limiter provides exceptionally good handling of
transients using variable attack and release time constants. Once activated, the
limiter compresses 30+ dB of transmitter input range into 4.5 dB of receiver output
range, thus reducing the measured figure for SNR without limiting by 4.5 dB.
Input Dynamic Range:
Controls & Indicators:
Audio Input Jack:
Phantom Power:
max.
USB port:
IR (infrared) port:
Antenna:
Battery:
Battery Life (Duracell Ultra):
AA alkaline; No Phantom Power: 5h 0m*
AA alkaline; 48V Phantom Power: 3h 30m**
* Tested with a dynamic microphone
** Tested with a Sanken CS1 for a phantom-powered microphone
Weight:
Dimensions:
Emission Designator:
Specifications subject to change without notice.
Dual bi-color LEDs indicate
modulation of -20, -10, 0, +10 dB
referenced to full modulation
35 Hz to 20 kHz (+/-1dB);
Adjustable for -3dB @30, 50, 70, 100,
120 or 150 Hz)
0.2% (typ. 100 Hz to 20 kHz -
see table)
SmartNR no limiting w/limiting
OFF 103.5 108.0
NORMAL 107.0 111.5
FULL 108.5 113.0
125 dB (with full Tx limiting)
• Power/Phantom "ON-OFF"
• Phantom voltage selector
• Audio input gain
• LCD w/membrane switches
• LED audio level indicators
Standard 3-pin XLR (female)
5V @ 18 mA max., 15V @ 15 mA
and 48 V @ 4 mA max.,
plus "OFF"
Used for firmware updates
For quick setup by transferring
settings from an IR enabled receiver
Housing and attached microphone
form the antenna
Two 1.5 Volt AA alkaline
6.7 oz (190 grams) without batteries
4.25x1.62x1.38 inches
107.95x41.15x35.05 mm
A1: 44K3F3E
B2: 57K9F3E
HMa/E06: 180KF3E
HMa/E07-941: 110KF3E
