M2T-X* and M2T-X/ND*
M2T-X Dante
M2T-X Non Dante
M2T-X/E01 Dante
M2T-X/E01 Non Dante
M2T/E02
M2T-X/E06
Fill in for your records:
Serial Number:
Purchase Date:
INSTRUCTION MANUAL
* M2T-X is a firmware option for the M2T
allowing encryption and removing the
flexlist feature.
Rio Rancho, NM, USA
www.lectrosonics.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lectrosonics M2T-X
Summary of Contents for Lectrosonics M2T-X
- Page 1 M2T-X Dante M2T-X Non Dante M2T-X/E01 Dante M2T-X/E01 Non Dante M2T/E02 M2T-X/E06 * M2T-X is a firmware option for the M2T allowing encryption and removing the flexlist feature. Fill in for your records: Serial Number: Rio Rancho, NM, USA Purchase Date:...
- Page 2 M2T-X LECTROSONICS, INC.
-
Page 3: Table Of Contents
Digital IEM Transmitter Table of Contents Introduction ................4 Encryption ................4 What is Dante? ..............4 System Setup Procedures ............5 Summary of Steps ..............5 Panels and Features ..............6 M2T Front Panel ..............6 M2T Back Panel ..............6 Operating Instructions ............7 IR (infrared) Port ..............7 USB Port ................7 Headphone Volume Adjustment.........7 Dante Ports (optional) ............7... -
Page 4: Introduction
Encryption The special firmware version M2T-X provides AES 256 bit encryption. When transmitting audio, there are situations where privacy is essential, such as during professional sporting events, in court rooms or private meetings. High entropy encryption keys are first created by the M2T-X Transmitter. -
Page 5: System Setup Procedures
Digital IEM Transmitter System Setup Procedures Summary of Steps 1) Connect M2T power using supplied DCR15/4AU power supply, and power on the transmitter (RF off). 2) Power receiver and scan RF spectrum on site. 3) Sync Scan to transfer information from receiver to transmitter. -
Page 6: Panels And Features
M2T-X Panels and Features M2T Front Panel Menu/Select Reset Button Menu navigation Return to Power switch buttons previous screen Headphone Volume Headphone Jack USB Port IR Port Adjustment Channel Function Buttons/ Quick Sync M2T Back Panel Antenna Antenna Jack Dante Ports (optional) -
Page 7: Operating Instructions
Operating Instructions When powering on the M2T, there are two screens that IR (infrared) Port appear in the following order, Duet and Lectrosonics: Settings, including frequency, name, limiter, mix mode, encryption keys, etc. can be transferred to and from the M2T transmitter via this port to an IR enabled receiver to simplify setup. -
Page 8: Lcd Menu Map
M2T-X LCD Menu Map Main Menu Tree Use arrow keys Press SEL to RF ENABLE/LEVEL RF ENABLE/LEVEL to enable or select desired BACK BACK adjust adjustment Use arrow keys Press SEL to RF TUNING RF TUNING to select desired select desired... -
Page 9: Menu Item Descriptions
Digital IEM Transmitter the function and then use the transmitter to send the Menu Item Descriptions profile over IR: Stereo Mix: The current receiver settings are sent as is, except the mix mode is set to stereo. RF Enable/Level Mono Ch. 1 Only: The current receiver settings are Allows RF transmission to be turned on and off and set sent as is, except the mix mode is set to Mono RF levels at 10, 25 or 50 mW (E06 options are 20, 50 or... -
Page 10: Audio Level/Trim (Audio Input Gain)
Select normal or inverted polarity for each level of encryption security. The Volatile Key ex- audio channel. ists only as long as the power on both the M2T-X Transmitter and the receiver remains on during a single session. If the receiver is powered off, but the M2T-X has remained turned on, the Volatile Key must be sent to the receiver again. -
Page 11: Encryption Keys
The M2T-X generates high entropy encryption keys to sync with encryption-capable receivers. The user must select a key type and create a key in the M2T-X, and then sync the key with a receiver. 1. Begin by selecting a key type. -
Page 12: Wireless Designer Software
M2T-X Wireless Designer Software Download the Wireless Designer software installer from the web sites under the SUPPORT tab at: http://www.lectrosonics.com/US Wireless Designer only needs to be installed the first time the software is used. Once the software is installed, updates are available by simply clicking on an item in the Help Menu. -
Page 13: Hardware Installation
Digital IEM Transmitter Hardware Installation DCR15/4AU DC power supply 21926 Cable USB 35800 Hex L 25991 Bracket key wrench front tie 25990 Bracket rear tie 27076 Rack flange bracket 27082 Rack handle 35959 Hole Plug (4) 28885 SCR10 cap screw (4) 35664 Rubber foot large (2) A500RA20... -
Page 14: Installing Two M2T Transmitters Into A Single Rack Space
M2T-X Installing two M2T Transmitters into a Single Rack Space 4. Insert two (2) cap screws (Part #28885) through the The M2T transmitter occupies a half rack space, and rack handle (Part #27082) holes and install the rack comes with hardware to mount two transmitters into a handle onto the flange bracket through the holes in single rack space. - Page 15 Digital IEM Transmitter Rear tie bracket (Part #25990) Tensioning lock Front tie bracket nuts on the rear (Part #25991) side of the bracket Slide the other transmitter over the tie bracket and 6. Install one side of the front tie bracket (Part insert the screws, but do not tighten them com- #25991) into the side panel opening in one of the pletely until the rear tie bracket is installed.
-
Page 16: Accessories
M2T-X Accessories SNA600a Antenna DCR15/4AU Front Mount Antenna Kit FMAKM2T 27080 Dante Port Cover (included with Non-Dante Model) SNA600a Accessories: ARG 15 A 15 foot antenna cable of standard RG-58 coax Dante 4X4-TM Dante Card Kit cable with BNC connectors at each end. -
Page 17: Specifications
Digital IEM Transmitter Specifications RF Power Output: • Two carriers; two audio channels each • M2T, M2T/E02: Power adjustable on each carrier to 10, 25 or 50 mW • M2T/E06: Power adjustable on each carrier to 20, 50 or 100 mW EIRP Antenna Output: 2 x BNC sockets Operating Frequencies:... -
Page 18: Service And Repair
LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 19 Digital IEM Transmitter ISEDC Notices: Per RSS-210 This device operates on a no-protection no-interference basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio licence is required. Please consult Industry Canada’s document CPC-2-1-28, Optional Licensing for Low-Power Radio Apparatus in the TV Bands, for details.
- Page 20 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
