Specifications - Lectrosonics UT300 Operating Instructions Manual

Operating Frequencies:
RF Power Output:
Pilot Tone:
Frequency Stability:
Deviation:
Spurious Radiation:
Equivalent Input Noise:
Input Level:
Input Compressor:
Gain Control Range:
Modulation Indicators:
Controls:
Battery
Battery Life
Weight:
Dimensions:
This product meets the CE Compliance Standards - ETS 300 445; January 1996
and I ETS 300 422 (December 1995). A copy of the Declaration of Conformity
may be requested from your dealer or by contacting the factory directly:
Lectrosonics, Inc.
Marketing Department
581 Laser Rd. NE, Rio Rancho, NM 87124 USA
tel: 505-892-4501 fax: 505-892-6243 e-mail: marketing@lectrosonics.com

SPECIFICATIONS

537.6 to 862.0 MHz in 26.5MHz blocks
10mW
32.765 kHz, ±2 Hz, 5kHz deviation
±0.002%
± 50 kHz max
Effectively none below 1GHz, above 1GHz At least 50dB
below the carrier
–126 dBv
Maximum SPL depends on mic element used
Soft compressor, >30 dB range
43 dB, semi-log rotary control
Dual LEDs indicate modulation level 10 dB below clipping and at the onset of limiting
• Power ON/OFF, Audio ON/OFF and Battery Condition LED
located on bottom of unit
• Bypass controls located inside battery door
• Gain control located inside battery door
• Frequency switches to adjust the transmitter frequency
in COARSE and FINE increments located just below the
mic head on the outside body of the case.
Precision compartment auto-adjusts to accept any known
alkaline or lithium 9 Volt battery. (We've tried 150 different models!)
Alkaline: 8 hours typical
Lithium: 18 to 20 hours typical
13.2 ozs. with VariMic capsule and alkaline battery
9." long x 2.05" diameter (at largest point) with VariMic capsule
Emission Designator:
Specifications subject to change without notice.
Rio Rancho, NM - USA
Frequency Agile Handheld Transmitter, Euro Model
150KF3E
13
