Specifications - Lectrosonics UT200C Operating Instructions Manual

Operating Frequencies:
RF Power Output:
Pilot Tone:
Frequency Stability:
Deviation:
Spurious Radiation:
Equivalent Input Noise:
Input Level:
Input Compressor:
Gain Control Range:
Modulation Indicators:
Controls:
Battery
Weight:
Dimensions:
Emission Designator:
12

SPECIFICATIONS

537.600 to 607.900 MHz
614.100 to 767.900 MHz
100mW
32.765 kHz, ±2 Hz, 5kHz deviation
±0.002%
± 75 kHz max
Effectively none below 1GHz, above 1GHz At least 50dB
below the carrier
–126 dBv
Maximum SPL depends on mic element used
Soft compressor, >30 dB range
43 dB, semi-log rotary control
Dual LEDs indicate modulation level 10 dB below clipping
and at the onset of limiting
Power ON/OFF, Audio ON/OFF and Battery Condition LED
located on bottom of unit; Bypass controls located inside
battery door
Gain control located inside battery door; Frequency switches to
adjust the transmitter frequency in 1.6 MHz and 100 kHz increments located just
below the mic head on the outside body of the case.
Precision compartment auto-adjusts to accept any known
alkaline or lithium 9 Volt battery. (We've tried over 150 different ones!)
13.2 ozs. with VariMic capsule and alkaline battery
9" long x 2.05" diameter (at largest point) with VariMic capsule
200KF3E
Specifications subject to change without notice.
The UT200C transmitter is FCC type accepted under part 74:
UT200C Emission Designator: 180KF3E
