Operation And Display - Danfoss VLT AQUA Instruction

VLT AQUA Low Harmonic Drive Instruction
Manual

6.4.2 0-** Operation and Display

Par. Parameter description
No. #
0-0* Basic Settings
0-01 Language
0-02 Motor Speed Unit
0-03 Regional Settings
0-04 Operating State at Power-up
0-05 Local Mode Unit
0-1* Set-up Operations
0-10 Active Set-up
0-11 Programming Set-up
0-12 This Set-up Linked to
0-13 Readout: Linked Set-ups
0-14 Readout: Prog. Set-ups / Channel
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-25 My Personal Menu
0-3* LCP Cust. Readout
0-30 Custom Readout Unit
0-31 Custom Readout Min Value
0-32 Custom Readout Max Value
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
0-41 [Off] Key on LCP
0-42 [Auto on] Key on LCP
0-43 [Reset] Key on LCP
0-44 [Off/Reset] Key on LCP
0-45 [Drive Bypass] Key on LCP
0-5* Copy/Save
0-50 LCP Copy
0-51 Set-up Copy
0-6* Password
0-60 Main Menu Password
0-61 Access to Main Menu w/o Password
0-65 Personal Menu Password
0-66 Access to Personal Menu w/o Password
0-7* Clock Settings
0-70 Date and Time
0-71 Date Format
0-72 Time Format
0-74 DST/Summertime
0-76 DST/Summertime Start
0-77 DST/Summertime End
0-79 Clock Fault
0-81 Working Days
0-82 Additional Working Days
0-83 Additional Non-Working Days
0-89 Date and Time Readout
Default value
(SR = Size related)
[0] English
[1] Hz
[0] International
[0] Resume
[0] As Motor Speed Unit
[1] Set-up 1
[9] Active Set-up
[0] Not linked
0 N/A
0 N/A
1602
1614
1610
1613
1502
ExpressionLimit
[1] %
ExpressionLimit
100.00 CustomReadoutUnit
0 N/A
0 N/A
0 N/A
[1] Enabled
[1] Enabled
[1] Enabled
[1] Enabled
[1] Enabled
[1] Enabled
[0] No copy
[0] No copy
100 N/A
[0] Full access
200 N/A
[0] Full access
ExpressionLimit
null
null
[0] OFF
ExpressionLimit
ExpressionLimit
null
null
ExpressionLimit
ExpressionLimit
0 N/A
®
MG.20.T1.22 - VLT is a registered Danfoss trademark
6 How to Program the Low Harmonic Drive
4 set-up Change during Conver-
operation sion index
1 set-up TRUE
2 set-ups FALSE
2 set-ups FALSE
All set-ups TRUE
2 set-ups FALSE
1 set-up TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
0 Int32
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
0 Uint16
6
- Uint8
-2 Int32
-2 Int32
0 VisStr[25]
0 VisStr[25]
0 VisStr[25]
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
- Uint8
0 Int16
- Uint8
TimeOf-
0 Day
- Uint8
- Uint8
- Uint8
TimeOf-
0 Day
TimeOf-
0 Day
- Uint8
- Uint8
TimeOf-
0 Day
TimeOf-
0 Day
0 VisStr[25]
6-49
