PN: 1725-36126-001_K.doc
Cards contain components that may be damaged by electrostatic
discharge. Before handling any of the cards, the installer must
attach the grounding strap (included in the Administration Kit) to
his or her wrist, and attach the other end of the strap to ground.
Only handle the cards by their edges. Do not touch connector
contact areas, do not lift cards by any of the components, and do
not lay cards down on their component sides. When laying a card
down, place it component side up on top of the anti-static bag in
which it was shipped.
Install T1 Remote Module
1. Slide the T1 Remote Module into slot 1 of the Expansion Shelf,
until the card clicks into place. Tighten the screws at the top and
bottom of the card to secure it.
Install Expansion Shelf Controllers (CSC300)
2. Slide the Expansion Shelf Controller Card into slot 2 of each shelf
(2 through 20), until the card clicks into place. Tighten the screws
at the top and bottom of the card to secure it.
3. Slide the Interface Modules into slots 3 through 12 of each shelf (2
through 20) until the card clicks into place.
Install Interface Modules (CPx316)
4. Slide the first Interface Module into slot 3 of the Primary Shelf,
until the card clicks into place. Tighten the screws at the top and
bottom of the card to secure it.
5. Slide additional Interface Modules into their slots. Slots can be left
empty if desired.
The following diagram shows a sample fully loaded Remote
Expansion Shelf.
Install System at Remote Site
21
