O
PTIONS MANUAL

3 SUB-D connector for release relay, CNC ready relay

3.1 SUB-D adapter from 10-pin FB connector X5
to 9-pin SUB-D connector
At connector X5, relay points are provided for the CNC ready-request and amplifier release. These are
'normally open' contacts. All relays are switched off after the PC is switched on, after a reset action or after
an error occurs.
The CNC ready relay is activated after the boot process (mcbt.exe).
The release relay is activated for the respective selected axis channels by using the cl() command for PCAP
and the CL() command for SAP.
This adapter cable is used to convert the X5 connector to a 9-pin SUB-D connector. This connector is fitted
to a PC slot board. The conversion results in a different pin assignment than to X5.

Table 3-1: Pin assignment for relay adapter (SUB-D-09)

Pin
Name
SUB-D
1 P contact
2 P contact
3 P contact
4 P contact
5
6 'Normally open'
contact
7 'Normally open'
contact
8 'Normally open'
contact
9 'Normally open'
contact
3.2 SUB-D adapter from 10-pin FB connector X5 or X2
to 25-pin SUB-D connector (male)
Relay points for the CNC ready request and the amplifier releases are provided at connector X5 of the APCI-
8001 and to pins 1-10 of X2 of the OPMF Optionprint. These are 'normally open' contacts. This means that
the release relays are available for up to 8 axes on a connector. All relays are switched off after the PC is
switched on, after a reset action or after an error occurs.
The CNC ready relay is activated after the boot process (mcbt.exe).
The release relay is activated for the respective selected axis channels by using the cl() command for PCAP
and the CL() command for SAP.
With this adapter cable, connector X5 of the APCI-8001 and pins 1-10 of X2 of the OPMF are converted to a
25-pin SUB-D connector. This connector is fitted to a PC slot board. The conversion results in a different pin
assignment than to X5/X2.
Description/comments
CNC ready
Release axis channel 1
Release axis channel 2
Release axis channel 3
Not connected
CNC ready
Release axis channel 1
Release axis channel 2
Release axis channel 3
Source
APCI-8001 FB-10-P5.1
APCI-8001 FB-10-P5.3
APCI-8001 FB-10-P5.5
APCI-8001 FB-10-P5.7
APCI-8001 FB-10-P5.2
APCI-8001 FB-10-P5.4
APCI-8001 FB-10-P5.6
APCI-8001 FB-10-P5.8
47
