46
2.2.6.6

General error

This is an error that cannot be more closely defined (FFFF hex ).
Code
Meaning
FFFF hex
Internal_Error

2.3 Interbus hardware

The OPIBS option can be used on the APCI-8001 motherboard as a component mounting variant, that is, no
other slots are required for the Interbus coupling. The peripheral devices are connected to the APCI-8001
with the aid of 10-pin FB connectors. A loom of cables with a board holder and an integrated 9-pin SUB D
connector is also available for the APCI-8001. This board holder can be installed in a free PC slot next to the
control system. If necessary, an existing open section of the PC mechanics can be used for this purpose.
Note: The 10-pin FB connector P1 is marked with Interbus.
2.3.1

Connector P1 (Interbus): 9-pin SUB-D connector

The remote bus (2 conductor) of the OPIBS Interbus system is connected to connector P1. It is executed on
the board holder as a 9-pin D-SUB plug and is electrically isolated from the potential of the host PC. The
casing of the plug is connected conductively to the PC board holder. The pin assignment has been selected
so that the standard Interbus remote bus cable (e.g. IBS RBC METER-T) by PHOENIX CONTACT or other
manufacturers can be used.

Table 2-12: Pin assignment of the remote bus interface (SUB-D)

Pin
Name
SUB-D
1
DO
2
DI
3
COM
4
5
+5V
6
/DO
7
/DI
8
9
2.3.2

OPIBS option technical data

Characteristic
Max. number of Interbus
subscribers
Structure
Max. number of process data
Max. number of PCP subscribers
Connector
Description/comments
Remote bus outgoing line
Remote bus receiving line
Earth
Not assigned/reserved
Internal distribution voltage
Remote bus inverted outgoing line
Remote bus inverted receiving line
Not assigned/reserved
Not assigned/reserved
Description/properties
512
Component mounting variant on the APIC-8001 motherboard
256 words (4096 binary inputs and outputs)
62 (in preparation)
10-pin FB connector (P1) for Interbus peripheral connection
Explanation
Internal error
Source
(FB)
APCI-8001 FB-10-P1.1
APCI-8001 FB-10-P1.3
APCI-8001 FB-10-P1.5
APCI-8001 FB-10-P1.9
APCI-8001 FB-10-P1.2
APCI-8001 FB-10-P1.4
O
PTIONS MANUAL
