1.2.2.5

rddigob, read digital output bit

See wrdigob in section [1.2.2.7]
1.2.2.6

wrdigo, write digital outputs

D :
ESCRIPTION
B D :
ORLAND ELPHI
C:
V B :
ISUAL ASIC
TSRP C :
OMPONENTS
1.2.2.7

wrdigob, write digital output bit

D :
ESCRIPTION
B D :
ORLAND ELPHI
C:
V B :
ISUAL ASIC
N
OTE
This register can be used to set the digital outputs of the OPMF. You must ensure
that the digital outputs are grouped axis-specifically on the OPMF. If you wish to
set an output, set the respective bit. The bit-coded structure of the digo status word
can be taken from the following table:
Table: Bit-coded structure of the digo word for
Bit No. Function
0 Output 9
1 Output 10
2 Output 11
3 Output 12
4 Output 13
5 Output 14
6 Output 15
7 Output 16
8..31 Not assigned --
Table: Bit-coded structure of the digo word for
Bit No. Function
0 Output 17
1 Output 18
2 Output 19
3 Output 20
4..31 Not assigned --
procedure wrdigo(var tsrp:TSRP);
void wrdigo(struct TSRP far *tsrp);
Sub wrdigo(DTSRP As TSRP)
TSRP[n].digo
This function is used to set or reset one OPMF digital output. The axis number
must be specified in the an parameter (3, ... MAXAXIS-1) The output is reset with
the value 0 or FALSE.
Note: Counting for the bit no. starts at 1.
procedure wrdigob(an:integer; bitnr:integer; value: boolean);
wrdigob(int an, int bitnr, int value);
Sub wrdigob(ByVal an As Long, ByVal bitnr As Long, ByVal value As Long)
PCAP command wrdigo()
Connector X1 / PIN
26
27
28
29
30
31
32
33
Connector X2 / PIN (SUB-D)
26
27
28
29
O
PTIONS MANUAL
axis channels 4, 5 and 6
axis channels 7 and 8
