16

1.3.1.3.1.2 Pin assignment for connector X1, axis channel 5

Pin
Name
Group
18
SERVO5
Setpoint
value 5
19
AGND5
Setpoint
value 5
Note: Jumpers J3 and J4 must be bridged in position 2-3, so that the signals listed in the table are available
at connector X1.

1.3.1.3.1.3 Pin assignment for connector X1, axis channel 6

Pin
Name
Group
34
SERVO6
Setpoint
value 6
35
AGND6
Setpoint
value 6
Note: Jumpers J5 and J6 must be bridged in position 2-3, so that the signals listed in the table are available
at connector X1.

1.3.1.3.1.4 Pin assignment for connector X2, axis channel 7

Pin
(SUB-D)
Name
1
SERVO7 Setpoint
2
AGND7
Note: Jumpers J7 and J8 must be bridged in position 2-3, so that the signals listed in the table are available
at connector X2.

1.3.1.3.1.5 Pin assignment for connector X2, axis channel 8

Pin
(SUB-D)
Name
18
SERVO8 Setpoint
19
AGND8
Note: Jumpers J9 and J10 must be bridged in position 2-3, so that the signals listed in the table are available
at connector X2.
Description
Analog output signal 5 for controlling a power amplifier (+/-10V, 5mA). This
signal is electrically isolated from the OPMF and has reference potential
AGND5.
Reference potential for SERVO5. This potential is electrically isolated from the
OPMF system electronics.
Description
Analog output signal 6 for controlling a power amplifier (+/-10V, 5mA). This
signal is electrically isolated from the OPMF and has reference potential
AGND6.
Reference potential for SERVO6. This potential is electrically isolated from the
OPMF system electronics.
Group
Description
Analog output signal 7 for controlling a power amplifier (+/-10V,
value 7
5mA). This signal is electrically isolated from the OPMF and has
reference potential AGND7.
Setpoint
Reference potential for SERVO7. This potential is electrically isolated
value 7
from the OPMF system electronics.
Group
Description
Analog output signal 8 for controlling a power amplifier (+/-10V,
value 8
5mA). This signal is electrically isolated from the OPMF and has
reference potential AGND8.
Setpoint
Reference potential for SERVO8. This potential is electrically isolated
value 8
from the OPMF system electronics.
O
PTIONS MANUAL
