1.3.1.3.2.5 Pin assignment for connector X2, axis channel 8

Pin (SUB-D) Name
18 PULSE8+
19 PULSE8-
24 SIGN8+
25 SIGN8-
Note: Jumpers J9 and J10 must be bridged in position 1-2, in order for the above-mentioned signals to be
available at connector X2.
1.3.1.4

Pin assignment connector X1, digital inputs

The basic wiring diagrams for the digital inputs I17..I32 listed below are printed in [CM/section 5.2.7.1].
Pin Name Function
9 I17 Digital input 17
10 I18 Digital input 18
11 I19 Digital input 19
12 I20 Digital input 20
13 I21 Digital input 21
14 I22 Digital input 22
15 I23 Digital input 23
16 I24 Digital input 24
42 I25 Digital input 25
43 I26 Digital input 26
44 I27 Digital input 27
45 I28 Digital input 28
46 I29 Digital input 29
47 I30 Digital input 30 and faster hardware latch input to save the actual position of axis
channel 4
48 I31 Digital input 31 and faster hardware latch input to save the actual position of axis
channel 5
49 I32 Digital input 32 and faster hardware latch input to save the actual position of axis
channel 6
1.3.1.5

Pin assignment connector X2, digital inputs

The basic wiring diagrams for the digital inputs I33..I40 listed below are printed in [CM/section 5.2.7.1].
Pin (SUB-D) Name Function
9 I33
10 I34
11 I35
12 I36
13 I37
14 I38
15 I39
16 I40
Group Description
Stepper 8 Pulse signal
Stepper 8 Inverted pulse signal
Stepper 8 Directional signal
Stepper 8 Inverted directional signal
Digital input 33
Digital input 34
Digital input 35
Digital input 36
Digital input 37
Digital input 38
Digital input 39 and faster hardware latch input to save the actual position of
axis channel 7
Digital input 40 and faster hardware latch input to save the actual position of
axis channel 8
