1.3.1.10.1 Pin assignment for reference voltage outputs

The OPMF of the APCI-8001 or APCI-8008 is available with up to 2 reference voltage outputs. These
outputs are assigned to the above-mentioned AD groups. All outputs are set to 10 V. Each output can be
loaded with 5 mA max. (if fewer than 7 axes: 10 mA).
Pin (SUB-D) Name
30 RGND1
31 AREF1
32 RGND2
33 AREF2
Assignment Function
AIN1 .. Reference potential for reference voltage output 1
AIN4 Reference voltage output 1
AIN5 .. Reference potential for reference voltage output 2
AIN8 Reference voltage output 2
