1.3.1.9.4.4 Pin assignment X2, channel 7

Pin (SUB-D) Name
3 CHA7+ Incremental signal (TTL square-wave pulse trains) track A
4 CHA7-
5 CHB7+ Incremental signal track B with 90° electrical phase shift to track A
6 CHB7-
7 NDX7+ Reference signal track 0
8 NDX7-

1.3.1.9.4.5 Pin assignment X2, channel 8

Pin (SUB-D) Name
20 CHA8+ Incremental signal (TTL square-wave pulse trains) track A
21 CHA8-
22 CHB8+ Incremental signal track B with 90° electrical phase shift to track A
23 CHB8-
24 NDX8+ Reference signal track 0
25 NDX8-

1.3.1.10 Pin assignment X2 for the analog input channels

The OPMF of the APCI-8001 is available with up to 8 analog inputs. The resolution of the measurement
value channels is 12-bit including sign, and the measurement value range of 0...5 V, 0...10 V, -5 .. +5 V or
-10 .. +10 V can be set individually for each channel. On the OPMF, the analog inputs are connected to the
internal A/D module via differential amplifiers.
The OPMF of the APCI-8008 is available with up to 8 analog inputs. The resolution of the measurement
value channels is 16-bit including sign, and the measurement value range of -5 .. +5 V or -10 .. +10 V can be
set only for all channels together. On the OPMF, the analog inputs are connected to the internal A/D module
via differential amplifiers.
Caution: On the OPMF module of the APCI-8008 Rev. A, with all analog inputs, the + and – connectors are
inverted. In the succeeding versions Rev. B and higher, this error is corrected.
Pin (SUB-D) Name
34 AIN1+
35 AIN1-
36 AIN2+
37 AIN2-
38 AIN3+
39 AIN3-
40 AIN4+
41 AIN4-
42 AIN5+
43 AIN5-
44 AIN6+
45 AIN6-
46 AIN7+
47 AIN7-
48 AIN8+
49 AIN8-
Function
Inverted incremental signal track A
Inverted incremental signal track B
Inverted reference signal track 0
Function
Inverted incremental signal track A
Inverted incremental signal track B
Inverted reference signal track 0
Assignment Function
Axis Analog input 1
channel 1 Reference potential for AIN1+
Analog input 2
Reference potential for AIN2+
Analog input 3
Reference potential for AIN3+
Analog input 4
Reference potential for AIN4+
Axis Analog input 5
channel 2 Reference potential for AIN5+
Analog input 6
Reference potential for AIN6+
Analog input 7
Reference potential for AIN7+
Analog input 8
Reference potential for AIN8+
