O
PTIONS MANUAL
In order to activate this screen, the rwmos.elf operating system must already be launched on the board
(online mode, RwMos running).

2.2.3.2.1 Explanation of the graphical operating symbols

The following table explains the graphical symbols (speed buttons) from the screenshot above.

Table 2-2: Meaning of the symbols on the [Interbus][SAP] page

Symbol Meaning
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
See Interbus configuration table
Using this button, the AT specifiers introduced according to IEC1131, for use in the Windows
clipboard, can be copied into an SAP programme for further use. The Windows clipboard
contains the following information after you activate this speed button for the above-mentioned
bus structure:
These definitions can be used for variable declaration in an SAP programme.

2.2.3.2.2 Explanation of the SAP Interbus screen text output

Table 2-3: SAP Interbus screen output

MCU-G3 INTERBUS BUS-STRUCTURE (physical order):
IBSCFG REV 2.51. Date: Tue Oct 30 08:30:42 2001
---------------------------------------------------------------------------------------------------
Device BusNo. PD-Bits
SegNo. (Length-Code) (Hex)
---------------------------------------------------------------------------------------------------
1 1.0 0 (0x00)
2 1.1 16 (0x01)
3 1.2 16 (0x01)
4 2.0 16 (0x01)
---------------------------------------------------------------------------------------------------
SAP (IEC1131-AT) Program Configuration:
-----------------------------------------------------------------------
Device AT-Specifier
-----------------------------------------------------------------------
1 %IWInterBus.DevicePD.1.0
2 %QWInterBus.DevicePD.2.0
3 %IWInterBus.DevicePD.3.0
3 %QWInterBus.DevicePD.3.0
-----------------------------------------------------------------------
Please include the following lines in your SAP-Source-File:
const InterBus = 500;
const DevicePD = $200;
%IWInterBus.DevicePD.1.0
%QWInterBus.DevicePD.2.0
%IWInterBus.DevicePD.3.0
%QWInterBus.DevicePD.3.0
Device-Id Name
8 (08) BK 2L-LB
190 (be) DI
189 (bd) DO
11 (0b) BK-I/O-T
Access-Type
Input
Output
Input
Output
Description
BK with 2-wire (local) bus branch
Digital module with input data
Digital module with output data
BK with Digital Input/Output
Length (Bits)
16
16
16
16
