Section 3 - Configuration
An IP Filter is an advanced feature that allows you to drop IP traffic based on specific rules. Each IP packet is marked with a source address, destination
address, and ports.
Name:
Indicates the name of the filter. The name is for reference purposes
only and does not affect functionality.
Status: Indicates whether the filter is set to Enable or Disable.
Source IP:
Indicates the source IP or IP range to which the rule will apply
Source Port:
Indicates the source port or port range to which the rule will apply.
Destination Indicates the destination IP or IP range to which the rule will apply
IP:
Destination Indicates the destination port or port range to which the rule will
Port:
apply.
Protocol Indicates protocol types affected by the filter.
Type:
Time Indicates the schedule used by the filter.
Schedule:
Action:
Click the pencil ( ) icon to edit the filter, click the trash can icon (
) to delete the filter.
Click Add to add a new filter, described in IP Filter Config on page 67.
