Appendix C - Technical Specifications
LTE Band
1
•
Category 6: Band 2/4/13 (700/1700/1900 MHz)
Data Rates
2
•
1200Mbps (max) in 802.11ac with 80MHz channel + 802.11n with
•
40MHz channel dual mode
•
866 Mbps (max) in 802.11ac mode with 80MHz channel
•
300Mbps (max) in 802.11n mode with 40MHz channel
•
150Mbps (max) in 802.11n mode with 20MHz channel
•
6/9/11/12/18/24/36/48/54Mbps in 802.11g/a mode
•
1/2/5.5/11Mbps in 802.11b mode
•
LTE Uplink: Up to 50 Mbps
•
LTE Downlink: Up to 300 Mbps
Standards
•
IEEE 802.11ac/n/g/b/a
•
IEEE 802.3i
•
IEEE 802.3u
Wireless Security
•
64 / 128-bit WEP (Wired Equivalent Privacy)
•
WPA & WPA2 (Wi-Fi Protected Access)
Firewall
•
Network Address Translation (NAT)
•
Stateful Packet Inspection (SPI)
VPN
•
L2TP/PPTP/IPSEC/VPN Pass-through
Antenna
•
Two detachable 4G antennas
Supported frequency band is dependent upon regional hardware version.
1
Maximum wireless signal rate derived from IEEE Standard 802.11ac/n/g/b/a specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building
2
materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range.
D-Link DWR-961 User Manual
Technical Specifications
Ports
•
Four LAN ports (RJ-45)
•
WAN port (RJ-45)
SIM/UICC Slot
•
Standard Mini-SIM/UICC slot
LED Status Indicators
•
Power
•
Internet
•
5 GHz
•
2.4 GHz
•
4G
•
LAN
•
WAN
•
Signal Strength
Dimensions
•
170 x 180 x 80 mm (6.7 x 7.1 x 3.15 in)
Operating Temperature
•
0 to 40 ˚C (32 to 104 ˚F)
Operating Humidity
•
10% to 90% (Non-condensing)
Certifications
•
FCC
•
RoHS
149
