Summary of Contents for D-Link DGS-1210-12TS/ME
-
Page 1: User Manual
User Manual DGS-1210/ME Series Product Model : Metro Ethernet Switches Release 2.10 ©Copyright 2016. All rights reserved. -
Page 2: Table Of Contents
Supported Web Browsers ........................16 Connecting to the Switch .......................... 16 Accessing the Web-based Management Interface .................. 17 Web-based Management ..........................17 D-Link Network Assistant (DNA) ........................17 Configuration ............................. 19 Web-based Management ..........................19 Tool Bar > Save Menu ..........................20 Save Configuration ........................... - Page 3 System > IEEE802.3az EEE Settings ...................... 40 System > SMTP Service > SMTP Server Settings .................. 41 System > SMTP Service > SMTP Service ....................41 System > D-Link Discover Protocol Settings .................... 42 Configuration > Jumbo Frame ........................43 Configuration > 802.1Q VLAN ........................43 Configuration >...
- Page 4 Table of Contents DGS-1210 series Metro Ethernet Managed Switch User Manual Configuration > Link Aggregation > LACP Port Settings................54 Configuration > BPDU Protection Settings ....................54 Configuration > IGMP Snooping > IGMP Snooping ................. 55 Configuration > IGMP Snooping > IGMP Access Control Settings ............57 Configuration >...
- Page 5 Table of Contents DGS-1210 series Metro Ethernet Managed Switch User Manual RMON > RMON History Control Configuration ..................87 RMON > RMON Alarm Configuration ...................... 88 RMON > RMON Event Configuration ....................... 88 Security > Trusted Host ..........................89 Security > Safeguard Engine........................89 Security >...
- Page 6 Table of Contents DGS-1210 series Metro Ethernet Managed Switch User Manual Monitoring > Packets > UMB Cast (RX) ....................118 Monitoring > Errors > Received (RX) ..................... 119 Monitoring > Errors > Transmitted (TX)....................120 Monitoring > Cable Diagnostics ......................122 Monitoring >...
- Page 7 Table of Contents DGS-1210 series Metro Ethernet Managed Switch User Manual L3 Features ............................150 QoS (Quality of Service) ......................... 150 Security ..............................151 OAM ............................... 151 Management ............................151...
-
Page 8: About This Guide
Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly forbidden. Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. -
Page 9: Product Introduction
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual Product Introduction Switch Description Front Panel Description LED Indicators Rear Panel Description Side Panel Description Connecting the DPS-200A/500A/500DC to the RPS Port (for DGS-1210- 10/12TS/20/28X/28XS/52/ME only) ... - Page 10 CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc. NOTE: The power budget is 78 Watts for DGS-1210-10P/ME. The front panel of the DGS-1210-12TS/ME switch consists out of the following: • 10 1000Mbps SFP port • 2 10/100/1000Mbps Copper Ports •...
- Page 11 1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual • LEDs for Power, RPS, Console, Link/Act for port 1 ~ 28 Figure 1.5 – DGS-1210-28/ME Front Panel CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc. The front panel of the DGS-1210-28P/ME switch consists out of the following: •...
- Page 12 1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual • LEDs for RPS, Power, Console, Fan Error, Link/Act for port 1 ~ 28 Figure 1.8 – DGS-1210-28X/ME Front Panel CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc. The front panel of the DGS-1210-28XS/ME switch consists out of the following: •...
-
Page 13: Led Indicators
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc. NOTE: The power budget is 193 Watts for DGS-1210-52P/ME. The front panel of the DGS-1210-52MP/ME switch consists out of the following: •... - Page 14 1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual Location LED Indicative Color Status Description Solid Power on. Light Power Green Light Power off. Solid Console on. Light Console Green Blinking POST is in progress. Light Console off. Fan Error (for DGS-1210-28P/ME, Solid...
-
Page 15: Rear Panel Description
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual When there is a secure Solid 1000Mbps Ethernet connection Green (or link) at any of the ports. Green When there is reception or Blinking transmission (i.e. Activity—Act) Green of data occurring at a 1000Mbps Ethernet connected port. - Page 16 1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual DGS-1210-12TS/ME Figure 1.17－ DGS-1210-12TS/ME Rear Panel DGS-1210-20/ME Figure 1.18－ DGS-1210-20/ME Rear Panel DGS-1210-28/ME Figure 1.19－DGS-1210-28/ME Rear Panel DGS-1210-28P/ME Figure 1.20 － DGS-1210-28P/ME Rear Panel DGS-1210-28MP/ME Figure 1.21 －DGS-1210-28MP/ME Rear Panel DGS-1210-28X/ME Figure 1.22－...
-
Page 17: Side Panel Description
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual DGS-1210-52/ME Figure 1.24 － DGS-1210-52/ME Rear Panel DGS-1210-52P/ME Figure 1.25 － DGS-1210-52P/ME Rear Panel DGS-1210-52MP/ME Figure 1.26 － DGS-1210-52MP/ME Rear Panel DGS-1210-52MPP/ME Figure 1.27 － DGS-1210-52MPP/ME Rear Panel Side Panel Description The left- and right-hand panels of the Switch have heat vents to dissipate heat. -
Page 18: Connecting The Dps-200A/500A/500Dc To The Rps Port (For Dgs-1210-10/12Ts/20/28/28X/28Xs/52/Me Only)
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 1.29 - Inserting the SFP modules into the Switch Figure 1.30 - Installing the SFP Module The Switch is equipped with SFP ports, which are to be used with fiber-optical transceiver cabling in order to uplink various other networking devices for a gigabit link that may span great distances. -
Page 19: Installing The Rps Into A Rack-Mount Chassis (For Dgs-1210-10/12Ts/20/28/28X/28Xs/52/Me Only)
1 Product Introduction DGS-1210 series Metro Ethernet Managed Switch User Manual The following section explains how to connect the DPS-200A/500A/500DC to the Switch. • Disconnect the Switch from the main AC power source. • Insert the 14-pin end of the DPS-CB150-2PS into the DPS-200A/500A/500DC and the 2-pin end into the receptacle of the RPS port on the Switch. -
Page 20: Hardware Installation
2 Hardware Installation DGS-1210 series Metro Ethernet Managed Switch User Manual Hardware Installation This chapter provides unpacking and installation information for the D-Link DGS-1210/ME Metro Ethernet Switch. Step 1: Unpacking Open the shipping carton and carefully unpack its contents. Please consult the packing list located in the User Manual to make sure all items are present and undamaged. -
Page 21: Step 3 - Plugging In The Ac Power Cord
2 Hardware Installation DGS-1210 series Metro Ethernet Managed Switch User Manual Then, use the screws provided with the equipment rack to mount the switch in the rack. Figure 2.3 – Mount the Switch in the rack or chassis Please be aware of following safety Instructions when installing: A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. -
Page 22: Power Failure
2 Hardware Installation DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 2.4 – Plugging the switch into an outlet Power Failure As a precaution, the switch should be unplugged in case of power failure. When power is resumed, plug the switch back in. -
Page 23: Getting Started
However, if you want to manage multiple D-Link Smart Managed Switches, the D-Link Network Assistant (DNA) is a more convenient choice. By using the D-Link Network Assistant (DNA), you do not need to change the IP address of your PC, making it easier to simultaneously initialize multiple D-Link Managed Switches. -
Page 24: Accessing The Web-Based Management Interface
D-Link Network Assistant (DNA) D-Link Network Assistant (DNA) is a program that is used to discover switches which are in the same Layer 2 network segment as your PC. You can download the DNA App from the Chrome web store and install it in a Chrome web browser. - Page 25 Figure 3.4 – D-LINK Network Assistant Click ‘ADD TO CHROME’ button on the right hand side of the search results. Click ‘Add app’ button in the pop-up window to install the D-Link Network Assistant in Chrome. When the installation process has finished: (Option 1) Click the ‘LAUNCH APP’...
-
Page 26: Configuration
Logout button first, then it will be seen as an abnormal exit and the login session will still be occupied. Finally, by clicking on the D-Link logo at the upper-left corner of the screen you will be redirected to the local D-Link website. -
Page 27: Tool Bar > Save Menu
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Tool Bar > Save Menu The Save Menu provides Save Configuration and Save Log functions. Figure 4.2 – Save Menu Save Configuration Select to save the entire configuration changes you have made of the device to switch’s non-volatile RAM then click Save Config button to take effect. -
Page 28: Reboot Device
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Reboot Device Provide a safe way to reboot the system. Click Reboot to restart the switch. Figure 4.7 – Tool Menu > Reboot Device Configuration Backup & Restore Allow the current configuration settings to be saved to a file (not including the password), and if necessary, you can restore configuration settings from this file. -
Page 29: Firmware Backup & Upgrade
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual FTP path: Specify the FTP path where the configuration file located. FTP File Name: Enter the file name which to be updated on the FTP server. Click Backup to save the current settings to the FTP server. Click Restore after selecting the backup settings file you want to restore. -
Page 30: Flash Information
The Online Help provides two ways of online support: Figure 4.11 – Online Help D-Link Support Site: This will lead you to the D-Link website where you can find online resources such as updated firmware images. User Guide: This can offer an immediate reference for the feature definition or configuration guide. -
Page 31: Device Information
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.12 –Function Tree Device Information The Device Information provides an overview of the switch, including essential information such as firmware & hardware information, and IP address. It also offers an overall status of common software features: STP: Click Settings to link to Configuration >... -
Page 32: System > Firmware Information
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.14 – System > System Settings IP Information: There are two ways for the switch to obtain an IP address: Static and DHCP (Dynamic Host Configuration Protocol). When using static mode, the IP Address, Subnet Mask, Gateway, DHCP Option 12 State and DHCP Option 12 Host Name can be manually configured. -
Page 33: System > Serial Port Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.15 – System > Firmware Information System > Serial Port Settings The Serial Port Settings allows the user to adjust the Baud Rate and the Auto Logout values. Figure 4.16 – System > Firmware Information Baud Rate: Specify the baud rate for the serial port on the Switch. -
Page 34: System > Static Arp Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.17 – System > IP Interface Interface Name: Specifies the name of IP interface. VLAN Name: Specifies the VLAN name of IP interface. IPv4 Address: Specifies the IPv4 address for the interface. Netmask: Select the netmask of IP address. -
Page 35: System > Ipv6 Neighbor Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.19 – System > IPv6 System Settings IPv6 System Settings: Interface Name: Displays the interface name of IPv6. IPv6 State: Specifies the IPv6 to be enabled or disabled. DHCPv6 Client: Specifies the DHCPv6 client to be enabled or disabled. IPv6 Network Address: Specifies the IPv6 Network Address. -
Page 36: System > Dhcp Auto Configuration
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Interface Name: Specifies the interface name of the IPv6 neighbor. To search for all the current interfaces on the Switch, go to the second Interface Name field in the middle part of the window, tick the All check box. Tick the Hardware option to display all the neighbor cache entries which were written into the hardware table. -
Page 37: System > Port Configuration > Port Description
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Speed: Gigabit Fiber connections can operate in 1000M Full Force Mode, Auto Mode or Disabled. Copper connections can operate in Forced Mode settings (1000M Full, 100M Full, 100M Half, 10M Full, 10M Half), Auto, or Disabled. -
Page 38: System > Port Configuration > Port Media Type
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Port: Displays the port that has been error disabled. Port State: Describes the current running state of the port, whether Enabled or Disabled. Connection Status: This field will read the uplink status of the individual ports, whether Enabled or Disabled. Reason: Describes the reason why the port has been error-disabled, such as a STP loopback occurrence. -
Page 39: System > Snmp Settings > Snmp Group Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.28 – System > SNMP Settings > SNMP User Table User Name: Enter a SNMP user name of up to 32 characters. Group Name: Specify the SNMP group of the SNMP user. SNMP Version: Specify the SNMP version of the user. -
Page 40: System > Snmp Settings > Snmp View Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.29– System > SNMP Settings > SNMP Group Table System > SNMP Settings > SNMP View Table This page allows you to maintain SNMP views to community strings that define the MIB objects which can be accessed by a remote SNMP manager. -
Page 41: System > Snmp Settings > Snmp Engine Id
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Host IP Address: Select IPv4 or IPv6 and specify the IP address of SNMP management host. SNMP Version: Specify the SNMP version to be used to the management host. Community String/SNMPv3 User Name: Specify the community string or SNMPv3 user name for the management host. -
Page 42: System > User Accounts
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Port Link Up / Link Down: Port connection information. RSTP Port State Change: Events of a RSTP port state changes. Firmware Upgrade State: Information of firmware upgrade - success or failure. Trap notification if PoE Power On / Off: Specifies the device to send trap notification when PoE power On or Off. -
Page 43: System > Arp Aging Time Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual System > ARP Aging Time Settings The ARP Aging Time Settings page provides user to globally set the maximum amount of time, in minutes, and Address Resolution Protocol (ARP) entry can remain in the Switch’s ARP table, without being accessed, before it is dropped from the table. -
Page 44: System > Web Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual System > Web Settings The WEB State is Enabled by default. If user chooses to disable this by selecting Disabled, user will lose the ability to configure the system through the web interface as soon as these settings are applied. Figure 4.39–... -
Page 45: System > Mac Notification Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual The user may use Infinite times radio button, in the Repeat Pinging for field, which will tell the ping program to keep sending ICMP Echo packets to the specified IP address until the program is stopped. The user may opt to choose a specific number of times to ping the Target IPv4 or IPv6 Address by clicking its radio button and entering a number between 1 and 255. -
Page 46: System > System Log Configuration > System Log Server
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual System > System Log Configuration > System Log Server The user can send Syslog messages to up to four designated servers using the System Log Server. It supports maximum 500 system log entries. To set the System Log Server configuration, click Apply. Figure 4.45 - System >... -
Page 47: System > Power Saving
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual NOTE: The time must be set after current time, otherwise it will take effect on the next cycle time. System > Power Saving The Power Saving mode feature reduces power consumption automatically when the RJ-45 port is link down or the connected devices are turned off. -
Page 48: System > Smtp Service > Smtp Server Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.48 – System > IEEE802.3az EEE Settings From Port / To Port: A consecutive group of ports may be configured starting with the selected port. State: Enabled or Disabled the IEEE802.3az EEE for the specified ports. By default, all ports are enabled. Click Apply to make the configurations take effect. -
Page 49: System > D-Link Discover Protocol Settings
Once the message is ready, click Send to send this mail to all recipients configured on the Switch for SMTP. System > D-Link Discover Protocol Settings For the D-Link Discovery Protocol (DDP) supported device, this page is an option for you to disable DDP or configure the DDP packet report timer. -
Page 50: Configuration > Jumbo Frame
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual D-Link Discover Protocol Report Timer (Seconds): Configure the report timer of D-Link Discover Protocol in seconds. The values are 30, 60, 90, 120 or Never. The default is 30 seconds. - Page 51 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Add VID to create a new VID group, assigning ports from 01 to 10 as Untag, Tag, Forbidden or Not Member. Enable or disable the VLAN Advertisement. A port can be untagged in only one VID. To save the VID group, click Apply.
-
Page 52: Configuration > Private Vlan > Private Vlan Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Select Enabled of Asymmetric VLAN and click Apply to change to Asymmetric VLAN mode: Figure 4.57 - Configuration > 802.1Q VLAN > VID Assignments Configuration > Private VLAN > Private VLAN Settings A private VLAN is comprised of a primary VLAN, up to one isolated VLAN, and a number of community VLANs. -
Page 53: Configuration > Private Vlan > Private Vlan Trunk
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Find Private VLAN: Specify to display a private VLAN information. VLAN Name: Enter a VLAN name for the private VLAN to be displayed. This name can be up to 32 characters in length. -
Page 54: Configuration > Vlan Status
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.60 - Configuration > Private VLAN > Private VLAN Trunk Config Promiscuous Trunk Ports: To specify the promiscuous trunk ports to the specified private VLAN to be enabled or disabled. A promiscuous port belongs to the primary VLAN and can communicate with all interfaces, including the community and isolated host ports and private VLAN trunk ports that belong to the secondary VLANs associated with the primary VLAN. -
Page 55: Configuration > Mac-Based Vlan Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Configuration > MAC-Based VLAN Settings The table is used to create MAC-based VLAN entries on the switch. A MAC address can be mapped to any existing static VLAN and multiple MAC addresses can be mapped to the same VLAN. When a static MAC- based VLAN entry is created for a user, the traffic from this user is able to be serviced under the specified VLAN regardless of the authentication function operated on the port. -
Page 56: Configuration > Gvrp Timer Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual GVRP: The Group VLAN Registration Protocol (GVRP) enables the port to dynamically become a member of a VLAN. GVRP is Disabled by default. Ingress Checking: This field can be toggled using the space bar between Enabled and Disabled. Enabled enables the port to compare the VID tag of an incoming packet with the PVID number assigned to the port. -
Page 57: Configuration > Qinq > Vlan Translation Cvid Entry Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.65 - Configuration > QinQ > QinQ Settings From Port / To Port: A consecutive group of ports that are part of the VLAN configuration starting with the selected port. Role: The user can choose between UNI or NNI role. -
Page 58: Configuration > Layer 2 Protocol Tunneling Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Apply to make the configurations take effect. Click Delete All to remove all the CVID entries. Q-in-Q and VLAN Translation Rules: For Ingress untagged packets at UNI ports: 1. The Switch does not reference the VLAN translation table. 2. -
Page 59: Configuration > 802.1V Protocol Vlan > 802.1V Protocol Group Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Configuration > 802.1v Protocol VLAN > 802.1v Protocol Group Settings The 802.1v Protocol Group Settings page allows user to configure the untagged ports of different protocols on the same physical port. Figure 4.68 - Configuration >... -
Page 60: Configuration > Vlan Trunk Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual To clear all previously configured lists click the Delete All button. Configuration > VLAN Trunk Settings The VLAN Trunk Settings is used to combine a number of VLAN ports together to create VLAN trunks. To create Vlan Trunk Port settings on the Switch, enter the ports to be configured, change the state to Enabled and click Apply, the new settings will appear in the VLAN Trunk Port Settings Table below. -
Page 61: Configuration > Link Aggregation > Lacp Port Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Configuration > Link Aggregation > LACP Port Settings The LACP Port Settings is used to create port trunking groups on the Switch. The user may set which ports will be active and passive in processing and sending LACP control frames. Figure 4.72 –... -
Page 62: Configuration > Igmp Snooping > Igmp Snooping
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.73 – Configuration > BPDU Protection Settings Trap Status: Specify to send trap packet when Attack Detected, Attack Cleared, None or Both. Log Status: Specify the Log Status when Attack Detected, Attack Cleared, None or Both. Recover Time (60-1000000): Specify the BPDU protection Auto-Recovery timer, the range is from 60 to 1000000 and default is 60 seconds. - Page 63 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.74 – Configuration > IGMP Snooping > IGMP Snooping By default, IGMP is disabled. If enabled, the IGMP Global Settings will need to be entered: Host Timeout (130-153025 sec): This is the interval after which a learned host port entry will be purged. For each host port learned, a 'Port Purge Timer' runs for 'Host Port Purge Interval'.
-
Page 64: Configuration > Igmp Snooping > Igmp Access Control Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.75 – Configuration > IGMP Snooping > IGMP Snooping-Parameters Settings Click Edit button to enter the Router Port Settings page, and the ports to be assigned as router ports for IGMP snooping for the VLAN. -
Page 65: Configuration > Igmp Snooping > Ism Vlan Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.78 – Configuration > IGMP Snooping > IGMP Access Control Settings From Port/To Port: Select the port ranges to be configured. Status: Enable or disable the IGMP Access Control of specified ports. Click Apply to make the configurations take effect. -
Page 66: Configuration > Igmp Snooping > Host Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Member Ports: Enter a port or list of ports to be added to the Multicast VLAN. Member ports shall be the untagged members of the multicast VLAN. Tagged Member Ports: Enter a port or list of ports that will become tagged members of the Multicast VLAN. UnTagged Source Ports: Enter a port or list of ports that will become untagged members of the Multicast VLAN. -
Page 67: Configuration > Igmp Snooping > Limited Multicast Range Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Add to create a new IP Multicast Profile or click Delete All to clear all the entries. Configuration > IGMP Snooping > Limited Multicast Range Settings The Limited Multicast Range Settings page allows user to configure the Limited Multicast. Specify the port range, select Access IP Type is IPv4 or IPv6 and select the Access is Deny or Permit then Click Apply to make the configurations take effect. -
Page 68: Configuration > Igmp Snooping > Igmp Snooping Static Group Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.84- Configuration > IGMP Snooping > Max Multicast Group Settings From Port / To Port: Specify the port ranges to be configured. IP Type: Specify the IP type is IPv4 or IPv6. Max Group (1-512): Specify the Max Group to be configured. -
Page 69: Configuration > Mld Snooping > Mld Snooping Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click the Delete button to remove the specific entry based on the information entered. Click the View All button to display all the existing entries. Click the Edit button to re-configure the specific entry. After clicking the Edit button, the following page will appear: Figure 4.86- Configuration >... -
Page 70: Configuration > Mld Snooping > Mld Host Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual select the ports to be assigned for MLD snooping for the VLAN, and press Apply for changes to take effect. Configuration > MLD Snooping > MLD Host Table The MLD Host Table page displays the MLD Snooping information. Figure 4.88- Configuration >... -
Page 71: Configuration > Sntp Settings > Time Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.90 – Configuration > Loopback Detection Loopback Detection State: Use the drop-down menu to enable or disable loopback detection. The default is Disabled. Mode: Specify the Loopback Detection to be Port-based or VLAN-based. Interval (1-32767): Set a Loop detection Interval between 1 and 32767 seconds. -
Page 72: Configuration > Sntp Settings > Timezone Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual If choosing SNTP for the clock source, then the following parameters will be available: SNTP First Server: Select IPv4 or IPv6 and specify the IP address of the primary SNTP server from which the system time is retrieved. -
Page 73: Configuration > Dhcp/Bootp Relay > Dhcp/Bootp Relay Global Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual From: Month / Day: Enter the month DST and date DST will start on, each year. From: Time In HH:MM: Enter the time of day that DST will start on, each year. To: Month / Day: Enter the month DST and date DST will end on, each year. -
Page 74: Configuration > Dhcp/Bootp Relay > Dhcp/Bootp Relay Interface Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual DHCP Relay Agent Information Option 82 Check: This field can be toggled between Enabled and Disabled using the pull-down menu. It is used to enable or disable the Switches ability to check the validity of the packet’s option 82. -
Page 75: Configuration > Dhcp Local Relay Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Configuration > DHCP Local Relay Settings The DHCP Local Relay Settings page allows the user to configure DHCP Local Relay. DHCP broadcasts are trapped by the switch CPU, and replacement broadcasts are forwarded with Option 82. Replies from the DHCP servers are trapped by the switch CPU, the Option 82 is removed and the reply is sent to the DHCP Client. -
Page 76: Configuration > Dhcpv6 Relay Option38 Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Enabled – Enables DHCPv6 Relay on the device. Disabled – Disables DHCPv6 Relay on the device. This is the default value. DHCPv6 Relay Hops Count Limit (1-32): The field allows and entry between 1 and 32 to define the maximum number of router hops DHCPv6 messages can be forwarded. - Page 77 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual and Multiple Spanning Tree Protocol (MSTP) as defined by the IEEE802.1 specification. RSTP can operate with legacy equipment implementing IEEE 802.1D, however the advantages of using RSTP will be lost. The IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) evolved from the 802.1D STP standard.
-
Page 78: Configuration > Spanning Tree > Stp Port Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual to become the Root Bridge. If it turns out that the Switch has the lowest Bridge Identifier, it will become the Root Bridge. A time interval may be chosen between 6 and 40 seconds. The default value is 20. (Max Age has to have a value bigger than Hello Time) Hello Time (1-10 sec): The user may set the time interval between transmissions of configuration messages by the root device, thus stating that the Switch is still functioning. -
Page 79: Configuration > Spanning Tree > Mst Configuration Identification
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual State: Use the drop-down menu to enable or disable STP by per-port based. It will be selectable after the global STP is enabled. External Cost: This defines a metric that indicates the relative cost of forwarding packets to the specified port list. -
Page 80: Configuration > Spanning Tree > Stp Instance Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.100 - Configuration > Spanning Tree > MST Configuration Identification MST Configuration Identification Settings: Configuration Name: A previously configured name set on the Switch to uniquely identify the MSTI (Multiple Spanning Tree Instance). -
Page 81: Configuration > Spanning Tree > Mstp Port Information
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual The window above contains the following information: MSTI ID: Enter the MSTI ID in this field. An entry of 0 denotes the CIST (default MSTI). Priority: Enter the new priority in the Priority field. The user may set a priority value between 0-61440. Click Apply to implement the new priority setting. -
Page 82: Configuration > Ethernet Oam > Ethernet Oam Event Configuration
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.103 - Configuration > Ethernet OAM > Ethernet OAM Port Settings From Port/To Port: Select a range of ports to be configured. Mode: Use the drop-down menu to select to operate in either Active or Passive. The default mode is Active. State: Use the drop-down menu to enable or disable the OAM function. -
Page 83: Configuration > Ddm > Ddm Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual From Port / To Port: Select a range of ports to be configured. Link Event: Select the link event, Link Monitor or Critical Link Event. Link Monitor: Select the link monitor. Avaliable options are Error Symbol, Error Frame, Error Frame Period, and Error Frame Seconds. -
Page 84: Configuration > Ddm > Ddm Voltage Settings Threshold Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.106 - Configuration > DDM > DDM Temperature Threshold Settings Port: Specifies the port to be configured. Type: Specifies the type for the operating parameter, the options are High Alarm, Low Alarm, High Warning and Low Warning. -
Page 85: Configuration > Ddm > Ddm Bias Current Threshold Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Low Warning: Specifies the low threshold for the warning. When the operating Voltage falls below the configured value, the action associated with the warning is taken. Vaule (0 – 6.55): Specifies the value for the specified type of port. Click the Apply button to accept the changes made. -
Page 86: Configuration > Ddm > Ddm Rx Power Threshold Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Port: Specifies the port to be configured. Type: Specifies the type for the operating parameter, the options are High Alarm, Low Alarm, High Warning and Low Warning. High Alarm: Specifies the high threshold for the alarm. When the TX power threshold rises above the configured value, the action associated with the alarm is taken. -
Page 87: Configuration > Duld > Duld Global Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.111 - Configuration > DDM > DDM Status Table Configuration > DULD > DULD Global Settings The DULD Global Settings page allows user to configure the DULD recover time. Figure 4.112 - Configuration >... -
Page 88: Configuration > Erps Setting
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.114 - Configuration > Multicast Forwarding & Filtering > Multicast Filtering From Port / To Port: Specify the ports of the VLAN on which the corresponding MAC address belongs to. Multicast Filtering Mode: This drop-down menu allows you to select the action the Switch will take when it receives a multicast packet that is to be forwarded to one of the ports in the range specified above. -
Page 89: Qos > Traffic Control
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual R-APS VLAN (1-4094): To configure the R-APS VLAN ID. Click Apply or Clear All to implement changes made. Click the Delete button to remove the specific entry. Click the Detail Information link to view detailed information of the R-APS entry. Click the Sub-Ring Information link to view the Sub-Ring information of the R-APS entry. -
Page 90: Qos > Bandwidth Control
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Action: Select the method of traffic control from the pull down menu. The choices are: Drop – Utilizes the hardware Traffic Control mechanism, which means the Switch’s hardware will determine the Packet Storm based on the Threshold value stated and drop packets until the issue is resolved. -
Page 91: Qos > Cos Scheduling Mechanism
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.118 – QoS > Bandwidth Control From Port / To Port: A consecutive group of ports may be configured starting with the selected port. Type: This drop-down menu allows you to select between RX (receive), TX (transmit), and Both. This setting will determine whether the bandwidth ceiling is applied to receiving, transmitting, or both receiving and transmitting packets. -
Page 92: Qos > 802.1P Default Priority
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.120 - QoS > CoS Output Scheduling Class ID: Specify the priority queue for the switch. The value is from 0 to 7. Weight (1-55): Specify the weight for a CoS. The value is from 1 to 55. Click Apply to make the configurations take effect. -
Page 93: Qos > Dscp Priority Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Once the user had assigned a priority to the port groups on the Switch, you can then assign this Class to each of the four levels of 802.1p priorities. Click Apply to make the configurations take effect. QoS >... -
Page 94: Rmon > Rmon Basic Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Ethernet Priority: Specify the Ethernet Priority is Off or 802.1p on the port. IP Priority: Specify the IP Priority is Off or DSCP on the port. Click Apply to make the configurations take effect. RMON >... -
Page 95: Rmon > Rmon Alarm Configuration
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Apply to make the configurations take effect. RMON > RMON Alarm Configuration The RMON Alarm Configuration page allows the user to configure the network alarms. Network alarms occur when a network problem, or event, is detected. Figure 4.128 - RMON >... -
Page 96: Security > Trusted Host
To delete the IP address, simply click the Delete button. Check the unwanted address, and then click Apply. Security > Safeguard Engine D-Link’s Safeguard Engine is a robust and innovative technology that automatically throttles the impact of packet flooding into the switch's CPU. This function helps protect the Switch from being interrupted by malicious viruses or worm attacks. -
Page 97: Security > Gratuitous Arp
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.132 – Security > CPU Protect CPU Protect State: Specifies the CPU protect state to be enabled or disabled. Click the Apply button to accept the changes made. The CPU Protect Types are ARP, BPDU, ICMP, IGMP and SNMP. Select the CPU Protect Type and enter the Rate limit which the value is between 0 and 65535 pps. -
Page 98: Security > Port Security
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Apply to make configurations make effects. Security > Port Security Port Security is a security feature that prevents unauthorized computers (with source MAC addresses) unknown to the Switch prior to stopping auto-learning processing from gaining access to the network. A given ports’... -
Page 99: Security > Smart Binding > Smart Binding Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.135 - Security > SSL Settings The SSL Settings page allows users to download a certificate file for the SSL function on the Switch from a TFTP server. The certificate file is a data record used for authenticating devices on the network. It contains information on the owner, keys for authentication and digital signatures. -
Page 100: Security > Smart Binding > Smart Binding
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.136 – Security > Smart Binding > Smart Binding Settings The Smart Binding Settings page contains the following fields: From Port/ To Port: Select a range of ports to set for IP-MAC-port binding. Admin State: Use the drop-down menu to enable or disable these ports for Smart Binding. -
Page 101: Security > Smart Binding > White List
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.137 – Security > Smart Binding > Smart Binding The Manual Binding Settings contains the following fields: From Port / To Port: Specifies the port ranges for MAC address to bind to the IP address of Binding list. IP Address: Specifies the IP address to bind to the MAC address set below. -
Page 102: Security > Smart Binding > Dhcp Snooping List
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.139 – Security > Smart Binding > Black List By giving conditions, desired devices information can be screened out below then click Find to search for a list of the entry: VID: Enter the VLAN ID number of the device. - Page 103 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.141 - Security > 802.1X > 802.1X Settings By default, 802.1X is disabled. To use EAP for security, select enabled and set the Authentication Mode and Authentication Protocol then click Apply. Authentication Mode: Indicates the 802.1X mode enabled on the device.
-
Page 104: Security > 802.1X > 802.1X User
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual received. The Switch then requests the identity of the client and begins relaying authentication messages between the client and the authentication server. The default setting is Auto. Direction: Sets the administrative-controlled direction on the port. The possible field values are: Both –... -
Page 105: Security > 802.1X > 802.1X Guest Vlan
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual be disconnected from the Switch. The user may set the number of attempts from 1 to 255. The default setting is 2. Key: Set the key the same as that of the RADIUS server. Confirm Key: Confirm the shared key is the same as that of the RADIUS server. -
Page 106: Security > Mac Address Table > Dynamic Forwarding Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.146 - Security > MAC Address Table > Static Mac Address-add MAC Security > MAC Address Table > Dynamic Forwarding Table This allows the Switch’s dynamic MAC address forwarding table to be viewed. When the Switch learns an association between a MAC address and a port number, it makes an entry into its forwarding table. -
Page 107: Security > Mac Address Table > Auto Learning Vlan Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual MAC Address: The MAC address entered into the address table. Port: The port to which the MAC address above corresponds. Type: Describes the method which the Switch discovered the MAC address. The possible entries are Dynamic, Self, and Static. -
Page 108: Security > Access Authentication Control > Authentication Server Group
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.150 – Security > Access Authentication control > Application Authentication Settings Application: Lists the configuration applications on the Switch. The user may configure the Login Method List and Enable Method List for authentication for Console, Telnet application, SSH and the WEB (HTTP) application. -
Page 109: Security > Access Authentication Control > Authentication Server
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual NOTE: The user must configure Authentication Server Hosts using the Authentication Server Hosts page before adding hosts to the list. Authentication Server Hosts must be configured for their specific protocol on a remote centralized server before this function can work properly. -
Page 110: Security > Access Authentication Control > Login Method Lists
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Security > Access Authentication Control > Login Method Lists This feature will configure a user-defined or default Login Method List of authentication techniques for users logging on to the Switch. Successful login using any of these techniques will give the user a "User" privilege only. -
Page 111: Security > Access Authentication Control > Local Enable Password Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Priority 1, 2, 3, 4: The user may add one, or a combination of up to four of the following authentication methods to this method list: none – Adding this parameter will require an authentication to access the Switch. local –... -
Page 112: Security > Dos Prevention Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Security > DoS Prevention Settings The DoS is a malicious attack against a network. This attack is designed to stop a network from functioning by flooding it with useless traffic. Symptoms of a malicious attack include the inability to access any web site or a particular web site being unavailable and network performance slowing down. -
Page 113: Security > Dhcp Server Screening > Dhcp Server Screening Vlan Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Security > DHCP Server Screening > DHCP Server Screening Vlan Settings The DHCP Server Screening VLAN Settings page allows the user to view and configure the VLAN state for the DHCP Server Screening. Figure 4.160–... -
Page 114: Security > Dhcp Server Screening > Filter Icmpv6
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.162 – Security > DHCP Server Screening > Filter DHCPv6 Server Log State: Specify to enable or disable the log state for filter DHCPv6 server. Click Apply to makes effects. Filter DHCPv6 Server State: Ports: Specify the ports, or select All Ports. -
Page 115: Security > Ssh Settings > Ssh Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.163 – Security > DHCP Server Screening > Filter ICMPv6 Log State: Specify to enable or disable the log state for filter ICMPv6 server. Click Apply to makes effects. Filter ICMPv6 RA_All_Node State: Ports: Specify the ports, or select All Ports. -
Page 116: Security > Ssh Settings > Ssh Authmode And Algorithm Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual To configure the SSH server on the Switch, modify the following parameters and click Apply: SSH State: Enabled or Disabled SSH on the Switch. The default is Disabled. Max Session (1 - 4): Enter a value between 1 and 4 to set the number of users that may simultaneously access the Switch. -
Page 117: Security > Ssh Settings > Ssh User Authentication Lists
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Security > SSH Settings > SSH User Authentication Lists The SSH User Authentication Lists page is used to configure parameters for users attempting to access the Switch through SSH. Figure 4.166 – Security > SSH Settings > SSH User Authentication Lists The user may view the following parameters: User Name: A name of no more than 15 characters to identify the SSH user. -
Page 118: Security > Mac-Based Access Control (Mac) > Mac-Based Access Control Local Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.167 – Security > MAC-based Access Control (MAC) > MAC-based Access Control Settings MAC-based Access Control Global Settings: MAC-based Access Control State: Enable or disable the MAC-based Access Control function on the Switch. -
Page 119: Security > Mac-Based Access Control (Mac) > Mac-Based Access Control Authentication State
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.168 – Security > MAC-based Access Control (MAC) > MAC-based Access Control Local Settings To add a MAC address to the local authentication list, enter the MAC address and the target VLAN ID into their appropriate fields and click Add. -
Page 120: Monitoring > Session Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.171 – Monitoring > Port Statistics Previous Page: Go back to the Statistics main page. Refresh: To renew the details collected and displayed. Clear Counter: To reset the details displayed. Monitoring >... -
Page 121: Monitoring > Memory Utilization
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Monitoring > Memory Utilization The Memory Utilization displays the percentage of the memory being used, expressed as an integer percentage and calculated as a simple average by time interval. Click Apply to implement the configured settings. -
Page 122: Monitoring > Packet Size
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual The user may use the real-time graphic of the Switch at the top of the web page to view utilization statistics per port by clicking on a port. Click Apply to make the configurations take effect. The following field can be set: Time Interval: Select the desired setting between 1s and 60s, where "s"... -
Page 123: Monitoring > Packets > Transmitted (Tx)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual 64: The total number of packets (including bad packets) received that were 64 octets in length (excluding framing bits but including FCS octets). 65-127: The total number of packets (including bad packets) received that were between 65 and 127 octets in length inclusive (excluding framing bits but including FCS octets). -
Page 124: Monitoring > Packets > Received (Rx)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.179 - Monitoring > Packet s > Transmitted (TX) (table for Bytes and Packets) The following fields can be set or viewed: Time Interval: Select the desired setting between 1s and 60s, where “s” stands for seconds. The default value is one second. -
Page 125: Monitoring > Packets > Umb Cast (Rx)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual To view the Received Packets Table, click the link View Table, which will show the following table: Figure 4.181 - Monitoring > Packet s > Received (RX) (table for Bytes and Packets) The following fields can be set or viewed: Time Interval: Select the desired setting between 1s and 60s, where “s”... -
Page 126: Monitoring > Errors > Received (Rx)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual To view the UMB Cast Table, click the View Table link, which will show the following table: Figure 4.183 - Monitoring > Packets > UMB Cast (RX) (table for Unicast, Multicast and Broadcast Packets) The following fields can be set or viewed: Time Interval: Select the desired setting between 1s and 60s, where “s”... -
Page 127: Monitoring > Errors > Transmitted (Tx)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual To view the Received Error Packets Table, click the link View Table, which will show the following table: Figure 4.185 - Monitoring > Errors > Received (RX) (table) The following fields can be set or viewed: Time Interval: Select the desired setting between 1s and 60s, where “s”... - Page 128 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.186 - Monitoring > Errors > Transmitted (TX) (line graph) To view the Transmitted Error Packets Table, click the link View Table, which will show the following table: Figure 4.187 - Monitoring > Errors > Transmitted (TX) (table) The following fields can be set or viewed: Time Interval: Select the desired setting between 1s and 60s, where “s”...
-
Page 129: Monitoring > Cable Diagnostics
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Monitoring > Cable Diagnostics The Cable Diagnostics is designed primarily for administrators and customer service representatives to examine of the copper cable quality. It rapidly determines the type of cable errors occurred in the cable. Select a port and then click the Test Now button to start the diagnosis. -
Page 130: Monitoring > Browse Arp Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.189 - Monitoring > System Log ID: Displays an incremented counter of the System Log entry. The Maximum entries are 500. Time: Displays the time in days, hours, and minutes the log was entered. Log Description: Displays the description of event recorded. -
Page 131: Monitoring > Ethernet Oam > Browse Ethernet Oam Statistics
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Port: Select the port to be viewed. Port List: Enter a list of ports. Tick the All Ports check box to select all ports. Click Find to locate a specific entry based on the information entered. Click Clear to clear all the information entered in the fields. -
Page 132: Monitoring > Mld Snooping > Mld Snooping Group
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.194 - Monitoring > IGMP Snooping > IGMP Snooping Host VLAN Name: Specify the name of the VLAN for which to be displayed the IGMP Snooping Host information. VID (1-4094): Specify the list of the VLAN IDs for which to be displayed the IGMP Snooping Host information. Port: Specify the ports of IGMP Snooping Host information to be displayed. -
Page 133: Monitoring > Port Access Control > Radius Account Client
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.196 - Monitoring > Port Access Control > RADIUS Authentication The user may also select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. -
Page 134: Monitoring > Sflow > Sflow Global Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.197 - Monitoring > Port Access Control > RADIUS Account Client The user may also select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. -
Page 135: Monitoring > Sflow > Sflow Analyzer Server Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.198 - Monitoring > sFlow > sFlow Global Settings sFlow State: Specify to enable or disable the sFlow feature. Click Apply to make the configurations take effect. Monitoring > sFlow > sFlow Analyzer Server Settings The Switch can support 4 different Analyzer Servers at the same time and each sampler or poller can select a collector to send the samples. -
Page 136: Monitoring > Sflow > Sflow Flow Sampler Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Apply to make the configurations take effect. Monitoring > sFlow > sFlow Flow Sampler Settings This sFlow Flow Sampler Settings page allows user to configure the sFlow flow sampler parameters. By configuring the sampling function for a port, a sample packet received by this port will be encapsulated and forwarded to the analyzer server at the specified interval. -
Page 137: Acl > Acl Configuration Wizard
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Delete All to remove all entries. ACL > ACL Configuration Wizard Access Control List (ACL) allows you to establish criteria to determine whether or not the Switch will forward packets based on the information contained in each packet's header. -
Page 138: Acl > Access Profile List
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Rate Limit - Rate limiting is activated if all other ACL criteria is met. Replace DSCP - Reassigns a new DSCP value to the packet if all other ACL criteria are met. Ports: Enter a range of ports to be configured. -
Page 139: Acl > Acl Finder
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual The steps of adding an access profile is like below: 1) After selecting the Profile ID and Frame Type (MAC, IPv4, IPv6 or Packet content ACL), specify attributes like Untagged/Tagged (for MAC), ICMP/IGMP/TCP/UDP/Protocol... -
Page 140: Acl > Cpu Filter Access Profile List
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Press Apply for the settings to take effect. From: Specify the origin of accessible packets. The possible values are: Any - Indicates CPU Filter action will be on packets from any source. MAC Address - Indicates CPU Filter action will be on packets from this MAC address. -
Page 141: Acl > Cpu Filter Finder
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Profile ID: Indicates the profile Identification number. The possible configured profile IDs are 1~50, and profile ID 51 is reserved for Voice VLAN. Owner Type: The owner type of CPU Filter profile, it can be normal CPU Filter, Voice VLAN or Surveillance VLAN. - Page 142 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual ACL rule to limit traffic. The step of bandwidth is 64kbps. Due to limited metering rules, not all ACL rules can associate with a metering rule. Figure 4.210 - ACL > ACL Flow Meter Profile ID: The pre-configured Profile ID for which to configure the Flow Metering parameter.
-
Page 143: Poe > Poe Port Settings (Dgs-1210-10P/28P/28Mp/52P/52Mp/52Mpp/Me Only)
IEEE802.3af standards and pre-802.3at standards. DGS-1210-10P/28P/28MP/52P/52MP/52MPP/ME works with all D-Link 802.3af or 802.3at capable devices. The Switch also works in PoE mode with all non-802.3af capable D-Link AP, IP Cam and IP phone equipment via the PoE splitter DWL-P50. - Page 144 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.212 – PoE > PoE Port Settings From Port/To Port: Specifies the PoE function of a port or ports. State: Select “Enabled” or “Disabled” to configure PoE function for designated port(s). Default is Enabled. Time Range: Select the PoE time profile configured from Time-Based PoE >...
-
Page 145: Poe > Poe System Settings (Dgs-1210-10P/28P/28Mp/52P/52Mp/52Mpp/Me Only)
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual PoE > PoE System Settings (DGS-1210-10P/28P/28MP/52P/52MP/52MPP/ME only) This PoE System Settings page will display the PoE status including System Budget Power, Support Total Power, Remainder Power, and The ratio of system power supply. Figure 4.213 –... -
Page 146: Lldp > Lldp Global Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Click Apply to create a new time range or click Delete to delete a time profile from the table. LLDP > LLDP Global Settings LLDP (Link Layer Discovery Protocol) provides IEEE 802.1AB standards-based method for switches to advertise themselves to neighbor devices, as well as to learn about neighbor LLDP devices. -
Page 147: Lldp > 802.1 Extension Lldp Port Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Notification State: Specifies whether notification is sent when an LLDP topology change occurs on the port. The possible field values are: Enabled – Enables LLDP notification on the port. Disabled – Disables LLDP notification on the port. This is the default value. Admin Status: Specifies the LLDP transmission mode on the port. -
Page 148: Lldp > 802.3 Extension Lldp Port Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Protocol VLAN ID : Specifies the VLAN ID to be enabled or disabled in the LLDP port. If select Enabled, users can specifies the content of VLAN ID. VLAN Name : Specifies the VLAN name to be enabled or disabled in the LLDP port. If select Enabled, users can specifies the content of VLAN Name. -
Page 149: Lldp > Lldp Statistics Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.219 – LLDP > LLDP Management Address Settings From Port/To Port: A consecutive group of ports may be configured starting with the selected port. Address Type: Specify the LLDP address type on the port. The value is always IPv4. Address: Specify the address. -
Page 150: Lldp > Lldp Management Address Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual RxPort Frames – Displays the total number of LLDP frames received on the port. RxPortTLVsDiscarded – Each LLDP frame can contain multiple pieces of information, known as TLVs. If a TLV is malformed, it is counted and discarded. RxPortTLVsUnrecognized –... -
Page 151: Lldp > Lldp Remote Port Table
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.223 – LLDP > LLDP Local Port Normal Table Click View of Detailed column to display detail information. Figure 4.224 – LLDP > LLDP Local Port Detailed Table LLDP > LLDP Remote Port Table This LLDP Remote Port Table page is used to display the LLDP Remote Port Brief Table. - Page 152 4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.225 – LLDP > LLDP Remote Port Table To view the settings for a remote port, click View Normal and the following page displays. Figure 4.226 – LLDP > LLDP Remote Port Normal Table To view the detail settings for a remote port, click View Detailed and the following page displays.
-
Page 153: Lldp > Lldp-Med Settings
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.227 – LLDP > LLDP Remote Port Detailed Table LLDP > LLDP-MED Settings By selecting a range of ports (From Port and To Port), the power PSE TLV type can be enabled for all selected ports to indicate the power source equipment (PSE) switch to transmit high power (15.4 to 30 Watts) to the pre-standard of 802.3at power devices via LLDP MDI TLV. -
Page 154: L3 Functions > Ipv4 Routing Table Finder
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.229 – L3 Functions > IPv4 Static Route IPv4 Address: Specifies an IPv4 address to be assigned to the static route. Netmask: Specifies a subnet mask to be applied to the corresponding subnet mask of the IPv4 address. Gateway: Specifies the entry of a Gateway IP address to be applied to the corresponding gateway of the IPv4 address. -
Page 155: L3 Functions > Ipv6 Routing Table Finder
4 Configuration DGS-1210 series Metro Ethernet Managed Switch User Manual Figure 4.231 – L3 Functions > IPv6 Static Route IPv6 Address / Prefix Length: Specifies an IPv6 address to be assigned to the static route. Nexthop Address: Specifies the corresponding IPv6 address for the next hop gateway address in IPv6 format. -
Page 156: Appendix A - Ethernet Technology
Appendix A - Ethernet Technology DGS-1210 series Metro Ethernet Managed Switch User Manual Appendix A - Ethernet Technology This chapter will describe the features of the D-Link and provide some background information about Ethernet/Fast Ethernet/Gigabit Ethernet switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and... -
Page 157: Appendix B - Ethernet Technology
Appendix B - Ethernet Technology DGS-1210 series Metro Ethernet Managed Switch User Manual Appendix B - Ethernet Technology QoS (Quality of Service) Features Be able to classify packets according to L2 Features follow contents: Supports up to 16K MAC address - Switch port Supports 256 static MAC - 802.1p priority... -
Page 158: Security
SSL: Support v3, IPv4 and IPv6 DHCPv6 Relay: Support DHCP local relay Smart Binding and option 37 - Supports D-Link IMPB SNMP Trap - Supports ARP packet Inspection as default, System Log: Support log server with IPv4 ARP and IP packet Inspection as option.
