LINEA PRO 6 FEATURES

The Linea Pro 6 allows mobile employees to convert their iPhone into a powerful solution for the retail,
warehousing, supply chain, ticketing and hospitality industries. The Linea Pro 6 includes an encrypted
or unencrypted 3-track magnetic stripe reader, optional 1D or 2D barcode scanner, optional Bluetooth®,
and optional RFID.
Feature
1D/2D Barcode Scanner
Magnetic Stripe Reader
(MSR)
Contactless Card
Reader (RFID)
Bluetooth
Compatibility
Syncing
Indicators
Battery Status
Note:
Use of the Barcode Scanning, Magnetic Card and/or RFID reader features requires the
installation of special software. Please contact your reseller to inquire about available
software, or contact Infinite Peripherals directly for recommendations on compatible third
party software solutions.
Linea Pro 6 User Manual
UM-00003 Version: A
The Linea Pro 6 supports one-dimensional (1D) and two-dimensional (2D)
barcode symbols, which can be read in any direction (omni-directional).
The effective reading distance of the barcode reader varies depending
on the barcode size. The barcode scanner is also capable of reading
barcodes on an LCD screen.
The Linea Pro 6 has a built-in magnetic stripe reader. The card reader
incorporates a (3) track, bi-directional magnetic read head, requiring a
single swipe to read field data from all three tracks.
The Linea Pro 6 has an RFID tag/card reader with read and write
capability at 13.56 MHz. The RFID reader incorporates several RFID
formats, depending on the model of your Linea Pro 6.
Available Bluetooth 2.0 SPP compatibility, which allows connection to a
Bluetooth peripheral, such as a printer.
The Linea Pro 6 enables your iOS device to be synced with iTunes.
The Linea Pro 6 uses (4) LEDs to indicate battery status levels.
The battery status may be checked by pressing the Battery Status button.
Description
