Barcode Scanner - 2D Barcodes

The Linea Pro 6 2D model uses a scan engine that supports one-dimensional (1D) and two-dimensional
(2D) barcode symbols. The effective reading distance of the barcode reader varies depending on the
barcode size.
To Scan a 2D Barcode:
1. Activate the Linea Pro 6 by pressing the Scan button.
2. Position the scan head so that the pointer is aimed at the barcode, and the barcode is within the
width of the red illumination box.
3. Slowly pull the unit back, gradually increasing the distance between the barcode and scanner, until
the barcode has been read by the scanner.
Scan Button
Linea Pro 6 User Manual
UM-00003 Version: A
Figure 10: 2D Barcode Scanning
15-20 cm
