CHARGING YOUR LINEA PRO 6

Charging the Linea Pro 6 through the USB Port

The Linea Pro 6 uses a Lithium ion rechargeable battery. The battery should be fully charged prior to
the first use.
The Linea Pro 6 supports pass through charging to the iOS device. The iPhone and Linea Pro 6 may
be charged together via the mini USB port or by placing it in a Linea Pro 6 Single or 5-Unit Charging
Station. Due to current charging limitations, the Linea Pro 6 should not be charged via USB from a PC/
Mac connection.
To Charge the Linea Pro 6:
1. Connect mini USB charger cable to the USB port (shown in the figure below).
CAUTION:
To prevent electrical damage to the Linea Pro 6 and/or battery, please use approved USB
to Mini USB cables only.
Note:
The battery should be charged in an ambient operating temperature of 0°C to +40°C.
Charging time for a fully drained battery is approximately 5h and 30 min to achieve full charge
status.
If the device is equipped with encrypted magnetic stripe reader, do not allow the battery to fully
discharge. The device will disconnect from the iPhone when the battery is drained below 3.6V.
Linea Pro 6 User Manual
UM-00003 Version: A
USB Sync/Charge Port
Figure 6: USB Sync/Charge Port
