Installing ZDS-II
Follow the steps below to install the ZDS II and documentation:
1. Insert the ZDS II CD into the CD-ROM drive. DemoShield launches automatically. If the
DemoShield does not launch automatically, open the Windows Explorer, browse to your CD-
ROM drive, and double-click launch.exe to launch the installer.
2. From the product installer list you may choose to install ZDS II alone; or both ZDS II and
associated documentation. You may also copy the documentation directly from your CD-ROM
drive to your hard disk using Windows Explorer or read the documentation directly from the
CD-ROM itself.
For customer service and technical support, Zilog® recommends you to create an account at
www.zilog.com.

Installing the USB Smart Cable

Follow the steps below for installing the USB Smart Cable and associated driver software.
Windows Vista-32
Follow the steps below to install the USB Smart Cable for Windows Vista-32.
1. Connect the USB Smart Cable to the Host PC. The Found New Hardware dialog box is
displayed.
2. Select [Locate and install the driver software (recommended)]. The Driver Software
Installation window is displayed, and then the Found New Hardware-USB Smart Cable dialog
box is displayed.
3. Select [I don't have the disc. Show me other options].
4. Select [Browse my computer for driver software (advanced)].
5. Browse to the following driver directory:
<ZDS II Installation Directory>\device drivers\USB
The Windows Security dialog box is displayed.
6. Select [Install this driver software anyway].
7. When the software is installed, click [Close].
Windows XP
Follow the steps below to install the USB Smart Cable for Windows XP:
1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard should
activate automatically after connecting the Zilog USB device for the first time; select [No, not
at this time] if asked to connect to Windows Update.
2. Select [Install from a list or specific location (Advanced)]; then click [Next].
Note: If the Windows Logo testing dialog appears, select [Continue Anyway].
3. Select [Search for the best driver in these locations and Include this location in search:]
4. Browse to the following driver directory and click [Next]:
<ZDS installation>\device drivers\USB\
5. Click [Next] after the appropriate driver is found.
6. Click [Finish] to complete the installation.
