Introduction
This quick start guide describes how to set up Zilog's ZNEO™ Z16FMC Series Motor
Control Development Kit and use it to evaluate your motor control designs and applica-
tions.
The Z16FMC Series Motor Control Development Kit features a Motor Control Modular
Development System (MC MDS) daughter board mounted on a 3-Phase Motor Control
Application Board (see Figure 1). The MC MDS board consists of a 64LQFP Z16FMC
chip and a DBG connector to connect the kit to a host development PC via the USB Smart
Cable. The 3-Phase Motor Control Application Board provides spade lug connectors for
the 3-phase motor and fused spade lug connectors for an adjustable 24 V DC, 3 A work-
bench power source.
This document guides you through the following elements:
•
Power supply requirements to power the 3-phase motor supplied with the kit
•
How to run the kit's preloaded sample code in standalone mode
•
How to connect the kit to your development PC
•
Running the sample code in Zilog Developer System II (ZDS II) Debug mode
Kit Contents
All hardware (except an external adjustable power supply) and software/documentation
required to evaluate the Zilog
Series Motor Control Development Kit. For details on kit contents, refer to the Z16FMC
Series Motor Control Development Kit Packing List (PAK0025). The sample code used in
this development kit is based on the Zilog Application Note titled Sensorless BLDC Motor
Control Using the ZNEO Z16FMC MCU (AN0311). The latest sample code for this docu-
ment, AN0311-SC01, can be downloaded at www.zilog.com.
System Requirements
Table 1 lists the system requirements for running ZDS II.
™
Z16FMC
Development Kit
Quick Start Guide
®
motor control solution is included within the Z16FMC
®
Copyright ©2010 Zilog
www.zilog.com
Series Motor Control
, Inc. All rights reserved.
QS007901-1110
Advertisement
Table of Contents
Related Manuals for ZiLOG Z16FMC Series
Summary of Contents for ZiLOG Z16FMC Series
- Page 1 Quick Start Guide QS007901-1110 Introduction This quick start guide describes how to set up Zilog’s ZNEO™ Z16FMC Series Motor Control Development Kit and use it to evaluate your motor control designs and applica- tions. The Z16FMC Series Motor Control Development Kit features a Motor Control Modular Development System (MC MDS) daughter board mounted on a 3-Phase Motor Control Application Board (see Figure 1).
-
Page 2: Running In Standalone Mode
(P4 and P5) on the 3-Phase Motor Control Application Board (see Figure 1). Running in Standalone Mode The Z16FMC Series Motor Control Development Kit is shipped with the sample code from the Application Note titled Sensorless Brushless DC Motor Control with the Z16FMC MCU (AN0311) preloaded into the Z16FMC chip’s internal Flash memory. -
Page 3: Step 2. Set Switches
Z16FMC Series Motor Control Development Kit Quick Start Guide the motor leads to the spade lugs on the 3-Phase Motor Control Application Board as shown in Figure 2. Figure 1. MC MDS Board Mounted on 3-Phase Motor Control Application Board Step 2. - Page 4 Z16FMC Series Motor Control Development Kit Quick Start Guide Green wire White wire Blue wire Figure 2. Z16FMC Series Development Kit Motor and DBG Connections QS007901-1110 Page 4 of 15...
- Page 5 Z16FMC Series Motor Control Development Kit Quick Start Guide Step 3. Configure the 5 V DC Universal Power Supply The universal power supply kit features different plug adapters in one box and the power supply in another. The power supply ships with a slide-out plate that must be removed to insert the location-specific plug adapter.
-
Page 6: Executing The Sample Code
If it does not automatically launch, go to the root of the CD-ROM and dou- ble-click the file. launch.exe 2. DemoShield provides several installation choices. To install ZDS II right away, select Install Zilog Developer Studio. You can install other software and accompanying documentation later. QS007901-1110 Page 6 of 15... - Page 7 Z16FMC Series Motor Control Development Kit Quick Start Guide 3. Follow the instructions on the screen to complete the installation. Step 3. Install the Opto-Isolated USB Smart Cable The opto-isolated USB Smart Cable connects the development kit to a high-speed or full- speed USB port on your ZDS II host system.
- Page 8 Observe the following steps to install the USB Smart Cable for Windows XP systems. 1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard should activate automatically after connecting the Zilog USB device for the first time;...
- Page 9 USB Smart Cable is connected both to the host PC and to the devel- opment board’s DBG port. 3. Run the ZDS II software. By default, the Zilog Developer Studio II program is located in the Start menu under: ...
- Page 10 Z16FMC Series Motor Control Development Kit Quick Start Guide 4. Select Open Project from the File menu. The Open Project dialog box appears. 5. Browse to the folder for the file, located by Samples Z16FMC_motordemo.zdsproj default in the following filepath: c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\...
- Page 11 Z16FMC Series Motor Control Development Kit Quick Start Guide Figure 4. Zilog Developer Studio II Opening Screen 7. Select the correct debug tool using Project Settings Debugger Debug Tool. For example, Select USBSmartCable when using the USB Smart Cable.
- Page 12 Quick Start Guide Figure 5. Option Bits Warning Dialog Box 12. Click Go to start the program. The screen changes as illustrated in Figure 6 on page 12. Icon Figure 6. Zilog Developer Studio II Active Screen QS007901-1110 Page 12 of 15...
-
Page 13: Troubleshooting Tips
Z16FMC Series Motor Control Development Kit, refer to the Zilog Developer Studio II–ZNEO User Manual (UM0171). Troubleshooting Tips If you experience trouble running the sample code with the Z16FMC Series Motor Control Development Kit, check the following before contacting Zilog Technical Support for assistance: •... - Page 14 • Try reloading the sample project as described in Executing the Sample Code on page 6. If you perform these steps and cannot get the sample code to run, contact Zilog Technical Support at support.zilog.com. QS007901-1110 Page 14 of 15...
-
Page 15: Life Support Policy
Z8, ZNEO and Z16FMC are trademarks or registered trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
