Getting Started with Zilog's ZMOTION TM Development Kit
Download and Run the Sample Project
Sample projects are included on the Application CD. Copy these projects to a convenient folder on
your PC. Once copied, ensure the folders are not set to "Read Only" by right clicking on the folder and
selecting properties. Unselect the "Read-only" attribute and click "OK". Make sure you apply changes
to this and sub folders when prompted.
In this example we will use the ZMotion_Basic project, but the steps apply to all other projects too.
At this point you should have loaded ZDS-II and the Smart Cable USB driver on to your computer.
Open ZDS-II and select [File] [Open Project], then navigate to the ZMotion_Basic project folder. Open
the ZMotion_Basic.zdsproj project. When you first receive your kit, this is the project that is already
loaded in the ZMotion MCU. Right click in open grey area below the menu icons and select
"Workbook Mode". This turns on the tabs at the bottom of the editor which makes it easier to switch
between files.
Click on the "Rebuild All" icon to build the project. The build output should not indicate any errors. If
you receive errors, try re-loading the projects from the original Application CD and ensure that the
folders are not set to "Read Only".
Right Click here
"File" Menu "Rebuild
and select
Item All"
"Workbook Mode"
Build Output
