Mechanical Information
JMPR1:
On – 4 Pin PIR Sensor
Off – 3 Pin PIR Sensor
UM022801-0610
Debug Header
JMPR2:
On – U4 TXD Enabled
Off – U4 ANA0 Enabled
Getting Started with Zilog's ZMOTION
DB9 Serial
Interface
Power
Switch
Blue LED
(Power)
Red LED
(Motion)
16 of 18
TM
Development Kit
5V Power
Input
9V Battery
(Optional)
