Introduction
This Quick Start Guide describes how to set up Zilog's ZNEO
and start using it to build designs and applications.
Kit Contents
For a complete list of material shipped with the ZNEO Series Development Kit, refer to
®
the ZNEO
Series of Microcontrollers Development Kit Packing List (PAK0010).
Requirements
Table 1
lists the system requirements for running Zilog Developer Studio II (ZDS II).
Table 1. ZDS II System Requirements
Recommended Configuration
•
PC running MS Windows XP
Professional
•
Pentium III/500 MHz or higher processor
•
128 MB RAM
•
110 MB hard disk space
•
Super VGA video adapter
•
CD-ROM drive
•
One or more RS-232 communication
ports
•
USB High-Speed Port
®
Series of
ZNEO
Microcontrollers Development
Kit
Quick Start Guide
Copyright ©2008 by Zilog
www.zilog.com
®
Series Development Kit
Minimum Configuration
•
PC running MS Windows 98SE/
Win2000–SP4/WinXP Professional
•
Pentium II/233 MHz processor
•
96 MB RAM
•
25 MB hard disk space (documentation
not installed)
•
Super VGA video adapter
•
CD-ROM drive
•
One or more RS-232 communication
ports
•
USB High-Speed Port
®
, Inc. All rights reserved.
QS005703-0908

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZNEO Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZiLOG ZNEO Series

Summary of Contents for ZiLOG ZNEO Series

  • Page 1 Series Development Kit and start using it to build designs and applications. Kit Contents For a complete list of material shipped with the ZNEO Series Development Kit, refer to ® the ZNEO Series of Microcontrollers Development Kit Packing List (PAK0010).

  • Page 2: Configuring The 5 V Dc Universal Power Supply

    ® ZNEO Series of Microcontrollers Development Kit Configuring the 5 V DC Universal Power Supply The universal power supply kit features several different plug adapters in one box and the power supply in another. The power supply ships with a slide-out plate that must be removed to insert the location-specific plug adapter.
  • Page 3 ® ZNEO Series of Microcontrollers Development Kit DBG Connector Pin 1 (indicated by square) Figure 1. ZNEO Development Board Jumper Settings The jumper settings to set up the ZNEO development board is provided below: 1. For initial setup, ensure that jumper J2, DIS RS232, is OUT (shunt not installed) and jumper J3, DIS IRDA, is IN (shunt installed).
  • Page 4 – Switch S3 is used to control the sequence in which LEDs D2, D3, and D4 flash when running the Demo program. For complete details on jumper settings for ZNEO Series development kits, refer to ® the Z16F2800100ZCOG ZNEO Series Development Kit User Manual (UM0202).
  • Page 5 ® ZNEO Series of Microcontrollers Development Kit 2. DemoShield provides several installation choices. Select Install Zilog Developer Studio to install now. You can install other software and accompanying documenta- tion later. 3. Follow the instructions on the screen to complete the installation.
  • Page 6 4. Browse to one of the following driver directory: <Zilog Developer Studio II Installation Directory>\ device drivers\USB <Zilog Developer Studio II Installation CD>\Device Drivers\USB 5. Click Next, and then click Next again after the appropriate driver is found. 6. Click Finish to complete the installation.
  • Page 7 4. Select Specify a location; then browse to one of the following driver directory: <Zilog Developer Studio II Installation Directory>\ device drivers\USB <Zilog Developer Studio II Installation CD>\Device Drivers\USB 5. Click Next, and then click Next again after the appropriate driver is found. 6. Click Finish to complete the installation.
  • Page 8 This project is designed to compile and download into ZNEO internal Flash Memory and blink the development board LEDs. Note: These procedures reference the file located Z16F2800100ZCOG.zdsproj in the below path: c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\ samples\QuickStart\ where is the ZDS II version number. <version_number> For example, c:\Program Files\ZiLOG\ZDSII_ZNEO_4.10.1\ samples\QuickStart\ 1.
  • Page 9 5. Browse to the folder for the file, located by Samples Z16F2800100ZCOG.zdsproj default in below path: c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\samples\ QuickStart 6. Select the file and click Open. The initial ZDS II Z16F2800100ZCOG.zdsproj program screen opens (see Figure 3 on page 10).
  • Page 10 ® ZNEO Series of Microcontrollers Development Kit Figure 3. ZDS II Opening Screen 7.Click the Rebuild All icon to build the project. Wait for the Rebuild build to complete as indicated by the Build Complete All Icon confirmation in the status window at the bottom of the screen (see Figure 4 on page 11).
  • Page 11 ® ZNEO Series of Microcontrollers Development Kit 9. Click Go to start the program. The screen changes as shown in Figure 5 on page 12. Icon Figure 4. ZDS II Build Completed Screen QS005703-0908 Page 11 of 18...
  • Page 12 LEDs and make them blink in the opposite direction, slide switch S3 to the opposite position. ® For more information on using ZDS II and building projects for your ZNEO develop- ® ment kit, refer to the Zilog Developer Studio II–ZNEO Series User Manual (UM0171). QS005703-0908 Page 12 of 18...
  • Page 13 Address Space settings). Complete information on internal and external memory configuration is described in ® Configuring Memory for Your Program section in the Zilog Developer Studio II–ZNEO Series User Manual (UM0171). Note:...
  • Page 14 Status window at the bottom Build Complete of the screen. The resulting hex file will be located in below path: c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\samples \QuickStart\External_Flash_Release\ 3. Select Tools → Flash Loader to run the Flash Loader. The Flash Loader window is displayed. See Figure 6 on page 15.
  • Page 15 5. The Flash Loader should default to the directory and hex file for the project you built. If you do not see hex file , click the button and browse z16F2800100zcog.hex to the following directory: c:\Program Files\ZiLOG\ZDSII_ZNEO_<version_number>\samples \QuickStart\External_Flash_Release\ Select the hex file and proceed. z16F2800100zcog.hex 6. Select Program and Verify.

  • Page 16: Troubleshooting Tips

    Then select Debug from the Build Configuration drop-down menu and click the Rebuild All icon. You can now connect to the target and download the code. Detailed instructions for using the Flash Loader are provided in the Zilog Developer ® Studio II–ZNEO Series User Manual (UM0171).
  • Page 17 Click the Go button. LEDs D2, D3, and D4 should blink in sequence. The hyper- terminal should display the ‘Hello World!’ message. If you perform these steps and cannot get the demo code to run, contact Zilog Technical Support at www.zilog.com. QS005703-0908...
  • Page 18 NOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within this document has been verified according to the general principles of electrical and mechanical engineering. ZNEO is a registered trademark of Zilog, Inc. All other product or service names are the property of their respective owners. QS005703-0908...
  • Page 19 Rev C: Swapped ANA 8 and ANA 9 on MCU page and MDS interface page POWER&COMMUNICATIONS MDS INTERFACE D[15:0] PA0_T0IN D[15:0] D[15:0] PA1_T0OUT A[23:0] PA2_DE0 A[23:0] A[23:0] -DIS_IrDA PA7_SDA -DIS_IrDA -DIS_232 PC0_T1IN PC0_T1IN -DIS_232 PA3_CTS0 PA4_RXD0 -MC_EN -MC_EN PA5_TXD0 -XM_EN -XM_EN PK[7:0] PK[7:0]...
  • Page 20 R1 10K R1 10K Vref OPINP_CINN ANA6 PA0_T0IN CINP ANA11 PA1_T0OUT 100pF 100pF OPOUT ANA3 PA2_DE0 PE0_DATA0 AGND OPINN ANA7 PA3_nCTS0 PE1_DATA1 ANA_M2 ANA2 PA4_RXD0 PE2_DATA2 7.8K 7.8K ANA_M1 ANA1 PA5_TXD0 PE3_DATA3 ANA_M0 ANA0 PA6_SCL PE4_DATA4 12.4K 12.4K ANA_5 ANA5 PA7_SDA PE5_DATA5 PE6_DATA6...
  • Page 21 VCC_33V D[15:0] PF0_ADR0 PF1_ADR1 PE0_DATA0 PF2_ADR2 PE1_DATA1 PF3_ADR3 PE2_DATA2 -CS0 PF4_ADR4 PE3_DATA3 -TRSTN PF5_ADR5 PE4_DATA4 -F91_WE -FLASH_EN PF6_ADR6 PE5_DATA5 VCC_33V PF7_ADR7 PE6_DATA6 PE7_DATA7 SN74LVC00 SN74LVC00 PG0_ADR8 VCC_33V PG1_ADR9 PJ0_DATA8 SN74LVC00 SN74LVC00 -DIS_FLASH PG2_ADR10 PJ1_DATA9 PG3_ADR11 PJ2_DATA10 VCC_33V PG4_ADR12 PJ3_DATA11 PG5_ADR13 PJ4_DATA12 PG6_ADR14 PJ5_DATA13...
  • Page 22 VCC_5V VCC_33V VCC_5V 0.1uF 0.1uF CON DC CON DC 10uF 10uF 0.1uF 0.1uF 0.1uF 0.1uF VCC_33V CONSOLE SPX2815AU-3.3 SPX2815AU-3.3 0.1uF 0.1uF 0.1uF 0.1uF VCC_33V 0.1uF 0.1uF PA5_TXD0 TXD0 PA5_TXD0 T1IN T1OUT 100 OHm 100 OHm CTS0 10uF 10uF RXD0 T2IN T2OUT 0.1uF 0.1uF...
