- Page 1 Getting Started with Zilog’s ZMOTION Development Kit Using the ZMOTION Detection and Control Development Kit Users Manual UM022801-0610 Copyright©2010 by Zilog®, All rights reserved. www.zilog.com...
-
Page 2: Kit Contents
Getting Started with Zilog’s ZMOTION Development Kit Introduction This getting started guide acquaints users with Zilog’s ZMOTION Development Kit and provides instructions on setting up and using the kit to demonstrate its basic operation. The following topics are covered: ... - Page 3 Getting Started with Zilog’s ZMOTION Development Kit ZMOTION Development Kit Contents Machine Screws and Nuts 0.77” Focal Circular 0.9” Focal Flat Lenses Mica Washers DB9 - DB9 4 - #4-40 x ¾” Lens Holder (1) Lens Holder (1) Serial Cable (1) 2 - #4-40 x ½”...
-
Page 4: Installing The Lens
Getting Started with Zilog’s ZMOTION Development Kit The following sections describe the operation of the kit in more detail, including how to download and debug your own ZMOTION project. Installing the Pyroelectric Sensor The Pyroelectric sensor used on the board can be changed by inserting the device into the appropriate socket. - Page 5 Getting Started with Zilog’s ZMOTION Development Kit PIR Sensor Clip On The lens is slid over top the PIR sensor and the notch on the PIR sensor is aligned with the notch in the base of the lens. There are actually 2 notches in the base of the lens. The correct notch to use is the one that is in line with the notch in the middle of the lens and is aligned with the horizontal axis of the beam pattern.
- Page 6 Getting Started with Zilog’s ZMOTION Development Kit Circuit Board Clip In This lens style clips directly into the circuit board over top the PIR sensor. There are 4 mounting clips on the lens that are aligned with the slots in the circuit board. Note the locating tab on the side of the lens is to be aligned with the tab on the silk-screen.
- Page 7 Getting Started with Zilog’s ZMOTION Development Kit Circular Lens Holder 0.77 Focal The circular lens holder is a 2 piece assembly that provides a 0.77” focal length mounting. To assemble the lens and lens holder, place the circular lens into the base of the lens holder, aligning the notch on the lens with the inside notch on the base.
- Page 8 Getting Started with Zilog’s ZMOTION Development Kit Flat Lens Holder 0.9 Focal The flat lens holder is a 2 piece assembly that provides a 0.9” focal length mounting. To assemble the lens and lens holder, place the flat lens into the inside of the cap. Ensure that the grooves of the lens are facing inward.
-
Page 9: Installing The Usb Smart Cable
Follow the steps below to install the USB Smart Cable for Windows XP: 1. Connect the Zilog USB device to the Host PC. The Found New Hardware Wizard should activate automatically after connecting the Zilog USB device for the first time; select [No, not at this time] if asked to connect to Windows Update. - Page 10 Follow the steps below to install the USB Smart Cable for Windows 98SE: 1. Connect the Zilog USB device to the Host PC. The Add New Hardware Wizard should activate automatically after connecting the Zilog USB device for the first time.
- Page 11 Getting Started with Zilog’s ZMOTION Development Kit Connecting the USB Smart Cable to the Development Board Caution: The power to the development board must be disconnected or turned OFF before connecting or disconnecting the USB Smart Cable. Attach one end of the six-conductor ribbon cable (included) to the USB Smart Cable six-pin DBG connector (see figure below).
- Page 12 Getting Started with Zilog’s ZMOTION Development Kit Download and Run the Sample Project Sample projects are included on the Application CD. Copy these projects to a convenient folder on your PC. Once copied, ensure the folders are not set to “Read Only” by right clicking on the folder and selecting properties.
- Page 13 Getting Started with Zilog’s ZMOTION Development Kit Make sure the ZMOTION Development board is powered off and connect the USB Smart Cable (Debugger) to P3 as described above. Apply power to the Development board and click the “Reset” icon in ZDS-II.
- Page 14 Getting Started with Zilog’s ZMOTION Development Kit Making Changes to the ZMOTION_Basic Project To change the duration of the LED on time, change the following line in main.c: unsigned char cMDDelayTime = DELAY_1SEC; // LED ON time Change the line as follows to select a 5 second LED on time: unsigned char cMDDelayTime = DELAY_5SEC;...
- Page 15 Getting Started with Zilog’s ZMOTION Development Kit Board Design Information Schematic UM022801-0610 15 of 18...
- Page 16 Getting Started with Zilog’s ZMOTION Development Kit Mechanical Information Debug Header 5V Power Input DB9 Serial JMPR1: Interface JMPR2: On – 4 Pin PIR Sensor Power 9V Battery On – U4 TXD Enabled Off – 3 Pin PIR Sensor Switch (Optional) Off –...
- Page 17 Getting Started with Zilog’s ZMOTION Development Kit yroelectric Sensor Socket Mechanical information for the socket that holds the pyroelectric sensor is shown below. The leads on the pyroelectric sensor should be trimmed no shorter than 2.3mm (.090”) and no longer than 3.3mm (0.130”).
- Page 18 Z8 Encore!, ZMotion and Z8 Encore! XP are registered trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
