MG ZS Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Preface................................................................................................................................ 1
Introduction ................................................................................................................................... 1
The Owner's Handbook ......................................................................................................................................................... 1
Status at Time of Printing ....................................................................................................................................................... 1
Symbols Used ............................................................................................................................................................................ 1
In an Emergency........................................................................................................................................................................ 2
Vehicle Identification Information................................................................................................ 3
Vehicle Identification ................................................................................................................................................................ 3
Vehicle Identification Label ..................................................................................................................................................... 4
Instructions for Use of Electric Vehicle........................................................................................ 6
Effects of Ambient Temperature ........................................................................................................................................... 6
Instructions for High Voltage Battery Pack Recycling ...................................................................................................... 6
Driving Range............................................................................................................................................................................. 7
Equalisation Charging............................................................................................................................................................... 8
High Voltage System................................................................................................................................................................. 9
Instructions If An Accident Occurs.................................................................................................................................... 11
1 Instruments and Controls ........................................................................................... 13
Instruments and Controls ........................................................................................................... 14
CONTENTS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZS Series and is the answer not in the manual?

Questions and answers

William Dawson
May 7, 2025

audio alerts preferences

0
1 comments:
Mr. Anderson
May 19, 2025

The MG ZS Series has a Pedestrian Alert Control System that uses audio alerts to warn pedestrians when the vehicle is moving at low speeds. The system sounds a speaker when all of the following conditions are met:

1. The vehicle is in READY mode.
2. The pedestrian alert system is enabled.
3. The vehicle is accelerating and its speed is between 0 mph (0 km/h) and 19 mph (30 km/h), or decelerating and its speed is above 0 mph (0 km/h) but less than or equal to 15 mph (25 km/h).

The speaker does not sound under these conditions:

1. The vehicle is not in READY mode.
2. The pedestrian alert system is disabled.
3. During acceleration, the speed is 19 mph (30 km/h) or higher.
4. During deceleration, the speed is over 15 mph (25 km/h).

The system can be turned on or off via the infotainment system, but it defaults to ON when the vehicle is restarted. It can only be turned off if there are no nearby pedestrians and the surroundings clearly do not require a warning tone.

This answer is automatically generated

0
Roy
March 31, 2025

Warning light like a cup with steam?????

0
1 comments:
Mr. Anderson
March 31, 2025

The warning light that looks like a cup with steam on an MG ZS Series indicates a high motor temperature or a fault in the electric drive system. When this warning appears, it means the motor temperature is high, and although the warning message may disappear after a few seconds, the warning indicator will stay on. You should continue driving at a constant speed with a low load to cool the motor. If the vehicle cannot be driven or the issue persists, contact an MG Authorised Repairer immediately.

This answer is automatically generated

0
Ronette
July 8, 2025

How do I disable the coffee cup warning light on the dashboard?

0

Related Manuals for MG ZS Series

Summary of Contents for MG ZS Series

  • Page 1: Table Of Contents

    CONTENTS Preface..........................1 Introduction ........................... 1 The Owner's Handbook ................................. 1 Status at Time of Printing ............................... 1 Symbols Used .................................... 1 In an Emergency..................................2 Vehicle Identification Information....................3 Vehicle Identification ................................3 Vehicle Identification Label ..............................4 Instructions for Use of Electric Vehicle..................6 Effects of Ambient Temperature ............................
  • Page 2 CONTENTS Instrument Pack ........................... 16 Information Centre ........................18 Warning Lights and Indicators....................30 Lights and Switches........................41 Master Lighting Switch................................41 Headlamp Levelling Manual Adjustment..........................43 Fog Lamp Switch ..................................44 Direction Indicator/Main Beam Switch..........................45 Hazard Warning Lamp................................47 Wipers and Washers........................
  • Page 3 CONTENTS Door Mirrors................................... 55 Interior Rearview Mirror..............................57 Sunvisors............................58 Windows............................59 Power Operated Window Switch ............................59 Window Operation................................59 Sunroof ............................62 Instructions ....................................62 Sunroof Operation ................................. 62 Interior Lights ..........................66 Front Power Socket........................67 Storage Devices ..........................69 Instructions ....................................
  • Page 4 CONTENTS Centre Console Cup Holder .............................. 72 Roof Luggage Rack ........................73 Maximum Authorised Load for the Roof.......................... 73 Periodical Check ..................................73 2 Air Conditioning and Audio Systems ................ 75 Ventilation ............................. 76 A/C Particle/Pollen Filter ..............................77 Vents ......................................77 Electronic Temperature Control ....................
  • Page 5 CONTENTS Defrost/Demist ..................................84 Heated Rear Window ................................84 3 Seats & Restraints ......................87 Seats............................... 88 Overview ....................................88 Head Restraints..................................89 Front Seats ....................................90 Rear Seats....................................92 Front Seat Heating ................................92 Seat Belts ............................94 Protection Provided by Seat Belts ............................94 Wearing Seat Belts..................................
  • Page 6 CONTENTS Disabling the Passenger Airbag............................109 Service and Replacement of Airbags ..........................111 Disposal of Airbags................................112 Child Restraints .......................... 113 Important Safety Instructions about Using Child Restraints ..................113 Child Restraints Groups..............................116 Approved Child Restraint Positions ..........................118 4 Starting & Driving ...................... 123 Keys ..............................
  • Page 7 CONTENTS READY Mode..................................136 Switching the Power System OFF.............................138 Pedestrian Alert Control System .................... 139 Economical and Environmental Driving .................. 140 Running-in....................................140 Economic Driving..................................140 Driving in Special Environment............................141 Check and Service ................................142 Vehicle Control ........................... 143 Vehicle Control System ...............................143 Power Limit of Electrical Appliances..........................143 Charging Requirements......................
  • Page 8 CONTENTS Charging Information ................................154 Equalisation Charging................................155 Charging Times ..................................155 Electric Drive System (EDS) ....................158 Instructions ....................................158 Gear Shift Control................................158 Vehicle Start-off..................................161 Driving on Hills ..................................162 Driving Mode (MODE)................................162 Energy Regeneration (KERS)..............................164 Battery Status Display （BATTERY） ......................166 Protection Mode...................................167 Brake System ..........................169 Foot Brake .....................................169 Electronic Brake Force Distribution (EBD) ........................170 Electronic Brake Assistance (EBA) ..........................170...
  • Page 9 CONTENTS Auto Hold .....................................176 Active Rollover Protection (ARP) ...........................178 Emergency Braking Hazard Warning Lights Control (HAZ) ..................178 Electronic Parking Brake (EPB)............................179 Stability Control System (SCS) and Traction Control System (TCS)........182 Adaptive Cruise Control System ..................... 183 Adaptive Cruise Control System Activation .........................184 Adaptive Cruise Target Speed Adjustment ........................187 Adaptive Cruise Target Following Distance Adjustment ....................188 Adaptive Cruise Pause.................................188...
  • Page 10 Lane Departure Warning System (LDW) ........................213 Lane Departure Prevention System (LDP) ........................217 Lane Keeping Assist System (LKA) ..........................221 MG Pilot System ..................................225 Forward Collision Warning System (FCW) ........................229 Automatic Emergency Braking System (AEB) and Automatic Emergency Braking System for Pedestrians (AEBP) .................................231...
  • Page 11 CONTENTS Hazard Warning Devices......................240 Hazard Warning Lights ................................240 Warning Triangle ...................................240 Emergency Starting ........................242 Using Booster Cables ................................242 Starting the Car ...................................242 Towing and Shipping........................245 Towing Vehicle ..................................245 Transporting using Trailer or Transporter ........................248 Tyre Repair ..........................249 Tool Identification ................................249 Tyre Repair ....................................249 Changing a Wheel...
  • Page 12 CONTENTS Bulb Specification..................................263 Bulb Replacement .................................264 6 Maintenance ....................... 279 Maintenance..........................280 Routine Servicing ..................................280 Bonnet ............................283 Opening the Bonnet................................283 Closing the Bonnet................................283 Bonnet Open Warning ................................283 Front Compartment ........................285 Cooling System........................... 286 Coolant Check and Top Up ...............................286 Coolant Specification................................287 Brake............................
  • Page 13 CONTENTS Battery Maintenance ................................290 Battery Replacement ................................290 High Voltage Battery Pack ......................292 Precautions and restricted conditions for use of battery ...................292 Washers ............................294 Windscreen Washer Check and Top Up ........................294 Washer Nozzles..................................295 Washer Fluid Specification ..............................295 Wipers ............................296 Wiper Blades ..................................296 Replacing Front Wiper Blades ............................297 Replacing Rear Wiper Blades ............................298...
  • Page 14 CONTENTS Wheel Balance..................................300 Wheel Alignment..................................300 Caring for Your Tyres ................................300 Tyre Pressure ..................................301 Valves .......................................301 Punctured Tyres ..................................301 Tyre Wear Indicators ................................302 Replacement Tyres ................................302 Wheel Fitment Rotation ..............................303 Snow Chains ..................................303 Cleaning and Vehicle Care ......................304 Exterior Care..................................304 Cleaning the Interior................................308 7 Technical Data ......................
  • Page 15 CONTENTS Recommended Fluids and Capacities ..................316 Wheel Alignment (Unladen Condition) .................. 317 Wheels and Tyres ........................317 Tyre Pressure (Cold) ........................317...

  • Page 17: Preface

    Always remember that if you have any queries concerning information that must be considered with the operation or specification of your car, your MG great care, in order to reduce the risk of Authorised Repairer will be glad to advise you.

  • Page 18: In An Emergency

    PREFACE In an Emergency This symbol indicates that parts described must be IMPORTANT disposed of by authorised persons or bodies to protect the environment. Remember the breakdown safety code Asterisk If a breakdown occurs while travelling: • Wherever possible, consistent with road safety and An asterisk (*) appearing within the text, identifies features traffic conditions, the car should be moved off the or items of equipment that are either optional, or are only...

  • Page 19: Vehicle Identification Information

    Always quote the Vehicle Identification Number (VIN) • Stamped on a plate visible through the bottom left hand when communicating with MG Authorised Repairer. If the corner of the windscreen; drive motor or electric drive system is involved, it may be...

  • Page 20: Vehicle Identification Label

    PREFACE Vehicle Identification Label • On the inner side of the tailgate visible by opening the tailgate. The vehicle identification label contains the following Note: The DLC is located in the driver footwell at the information: base of the fascia panel on the RH side. The VIN •...
  • Page 21 PREFACE Location of Vehicle Identification Label The identification label is located at the lower side of right pillar B.

  • Page 22: Instructions For Use Of Electric Vehicle

    Arbitrary sources, such as flammable objects, heat and water disposal may cause pollution, hazard and damage to the sources. environment. The high-voltage battery pack MUST be recycled by an MG Authorised Repairer or a professional...

  • Page 23: Driving Range

    MG Authorised Repairer. See official Website for details: www.mg.co.uk. • The actual driving range of vehicle will reduce with the increase of vehicle age.

  • Page 24: Equalisation Charging

    PREFACE Equalisation Charging • Try and use the vehicle between the recommended ambient temperatures. In order to assist in extending the service life of the high • Do not park or store the vehicle for long periods with voltage battery pack is recommended that an equalisation a low state of charge, where possible charge the vehicle charge is carried out at regular intervals.

  • Page 25: High Voltage System

    PREFACE High Voltage System • The high voltage system used on your vehicle features AC and DC voltages up to 460V. All high voltage components have warning labels attached - please observe these warnings and any requirements when operating within or close to these areas.
  • Page 26 PREFACE The high-voltage system component layout is shown below: 1 High-voltage Harness 2 On Board Charger 3 Power Distribution Unit (PDU) 4 Electric Heater 5 High Voltage Battery (ESS) 6 Manual Service Disconnect (MSD) 7 Electric A/C Compressor 8 Electric Drive System (EDS) 9 HV Battery Heater 10 Charging Port...

  • Page 27: Instructions If An Accident Occurs

    • If your car is being recovered by an independent recovery agent, please contact MG Authorised Repairer for maintenance.

  • Page 29: 14 Instruments And Controls
