3. DIMENSIONS

FRAME REFERENCE
V50009.x
V50017.x
V50030.x
1 V50045.x
V50060.x
V50075.x
V50090.x
V50110.x
V50145.x
2
V50170.x
V50210.x
V50250.x
FRAME REFERENCE
V50275.x
V50330.x
3
V50370.x
V50460.x
V50580.x
V50650.x
4
V50800.x
V50900.x
POWER ELECTRONICS V5 Operation Instructions
16
H1 H2
415 395
415 395
415 395
415 395
415 395
415 395
415 395
525 505
525 505
525 505
525 505
525 505
Figure 3.1 Frame 1
H1 H2
791 771.5
791 771.5
791 771.5
791 771.5
926 910
926 910
926 910
926 910
Figure 3.3 Frame 3
H3 W1 W2
350 225 125
350 225 125
350 225 125
350 225 125
350 225 125
350 225 125
350 225 125
460 315 160
460 315 160
460 315 160
460 315 160
460 315 160
H3 W1 W2
710 580 350
710 580 350
710 580 350
710 580 350
840 640 480
840 640 480
840 640 480
840 640 480
NET
D Y1 WEIGHT
(kg)
230 - 12,0
230 - 12,0
230 - 12,0
230 - 12,0
230 - 12,0
230 - 12,0
230 - 12,0
260 - 18,5
260 - 18,5
260 - 18,5
260 - 18,5
260 - 18,5
Figure 3.2 Frame 2
NET
D Y1 WEIGHT
(kg)
310 - 47,8
310 - 47,8
310 - 47,8
310 - 47,8
330 - 80,0
330 - 80,0
330 - 80,0
330 - 80,0
Figure 3.4 Frame 4
V5IM01BI
