4. STANDARD POWER RATINGS

IP PROTECTION
IP20
•
For higher power ratings, contact to Power Electronics customer support.
POWER ELECTRONICS V5 Operation Instructions
18
FRAME CODE I (A)
V50009 9
V50017 17
V50030 30
1
V50045 45
V50060 60
V50075 75
V50090 90
V50110 110
V50145 145
2
V50170 170
V50210 210
V50250 250
V50275 275
V50330 330
3
V50370 370
V50460 460
V50580 580
V50650 650
4
V50800 800
V50900 900
5 V51200 1250
Table 5 Standard ratings for 230V and 500V supply voltage.
IP PROTECTION FRAME
1
2
IP20
3
4
5
Table 6. Standard ratings for 690V supply voltage.
230V (kW) 400V (kW)
2 4
5 7
9 15
14 22
18 30
22 37
25 45
35 55
45 75
50 90
65 110
75 132
85 150
100 185
115 200
145 250
185 315
200 355
250 450
280 500
400 710
CODE I (A) 690V (kW)
V50009.6 9
V50017.6 17
V50030.6 30
V50045.6 45
V50060.6 60
V50075.6 75
V50090.6 90
V50110.6 110
V50145.6 145
V50170.6 170
V50210.6 210
V50250.6 250
V50275.6 275
V50330.6 330
V50370.6 370
V50460.6 460
V50580.6 580
V50650.6 650
V50800.6 800
V50900.6 900
V51200.6 1250
440V (kW) 500V (kW)
5 5,5
9 11
18,5 18,5
25 30
35 40
45 50
55 65
65 80
90 100
110 115
120 150
160 180
170 200
200 220
220 257
270 315
375 415
425 460
500 560
560 630
850 900
7,5
15
30
45
60
75
90
110
140
160
200
230
250
315
355
450
560
630
800
900
1250
V5IM01BI
