Indication UDL
Description UNDERLOAD
Note Under load condition.
Indication PTC
Description MOTOR PTC
Note Motor PTC fault.
Indication OVT
Description SOFT-STARTER OVERTEMPERATURE
Note The temperature inside the soft starter is too high.
Indication SHP
Description SHEARPIN CURRENT
Note The shearpin function has switched off the soft starter.
Indication ASY
Description ASYMMETRIC CURRENT
Note Asymmetric current at the motor.
Indication FLT
Description FAULT
Note A fault has awitched off the Soft-Starter.
Indication STD
Description START DELAY
Note The V5 delays the start signal set in screen G4.1 Start delay.
Indication EXT
Description EXTERNAL FAULT
Note Fault status is active due to an external fault command through one of the digital inputs.
Indication P/T
Description TORQUE PULSE
Note The V5 is applying torque pulse set in screen G4.2 moment during the time set in screen
G4.3.
Indication ILT
Description CURRENT LIMIT
Note The V5 has reached a maximum current level allowed in screen G4.7. Current limit.
Indication HIP
Description HIGH PRESSURE
Note It warns during the time entered in screen G16.4.
Indication LOP
Description LOW PRESSURE
Note It warns during the time entered in screen G16.5. and G16.6.
Indication NOF
Description NO FLOW
Note It warns during the time entered in screen G16.7 and G16.8.
Indication LWA
Description LOW WATER
Note It warns during the time entered in screen G16.9.
