Summary of Contents for Power Electronics SE-4E15
- Page 1 E E T AUTOMATIC VOLTAGE REGULATOR...
- Page 2 OWER ELECTRONICS SE-4E15 AUTOMATIC VOLTAGE REGULATOR...
-
Page 3: Automatic Voltage Regulator
E E T AUTOMATIC VOLTAGE REGULATOR... - Page 4 260mm Φ6 Φ6 SE - 4E15 380mm 355mm HEIGHT 62mm Φ6 Φ6 235mm 240mm Φ6 Φ6 POWER TRANSFORMER FOR SE-4E15 140mm 105mm 1.5 KVA 16Kg HEIGHT 240mm Φ6 Φ6 220mm...
-
Page 5: General Description
SE-4E15 MODEL GENERAL DESCRIPTION The SE-4E15 is a high performance Height three angle fullwave phase AVR designed to performs especially good for high current brushless generators. It powerered from a special transformer that isolates it at the same time. TECHNICAL SPECIFICATION... - Page 6 MODEL SE-4E15 ver.2020 380 - 440 V BUS BAR AUTOMATIC FLASH 50 - 60 Hz COMPATIBILITY. UNDER FREQUENCY PROTECTION. P/F COMPENSATED IN PARALLEL OPERATION. CABLE CHECKER IN PARALLEL OPERATION. PHASE SEQUENCE INDICATOR. REGULATION +/- 0.5% OPERATIONAL TEMPERATURE 80 C MAX POWER &...
- Page 7 INSTRUCTIONS TO INSTALLING AND ADJUSTING THE AVR MODELS: SE-4A15, SE-4E15, SE-4A65, SE-4E65, SE-3A110, SE-3E110 SE-4E110, SE-4A110, SE-4E150, SE-4A150, SE-4E200, SE-4A200 THREE PHASE CONNECTION & WRONG PHASE SEQUENCE INDICATOR 1. The right suggestion of the phases is a must for the normal function of the AVR.
- Page 8 ELECTRONICS INSTRUCTIONS TO INSTALLING AND ADJUSTING THE AVR MODELS: SE-4A15, SE-4E15, SE-4A65, SE-4E65, SE-3A110, SE-3E110 SE-4E110, SE-4A110, SE-4E150, SE-4A150, SE-4E200, SE-4A200 U/F - Under Frequency Protection. It protects the generator from over-excitation current due to lower engine revs. To adjusting the U/S trimmer proceed as follows: UNDER FREQ PROTECTION The AVR comes with pre-configured Under Frequency protection.
- Page 9 INSTRUCTIONS TO INSTALLING AND ADJUSTING THE AVR MODELS: SE-4A15, SE-4E15, SE-4A65, SE-4E65, SE-3A110, SE-3E110 SE-4E110, SE-4A110, SE-4E150, SE-4A150, SE-4E200, SE-4A200 ΤΡΙΦΑΣΙΚΗ ΣΥΝΔΕΣΗ & ΣΥΣΤΗΜΑ ΕΛΕΓΧΟΥ ΔΙΑΔΟΧΗΣ ΦΑΣΕΩΣ 1. Η σωστή διαδοχή των φάσεων είναι απαραίτητη προϋπόθεση για την ομαλή λειτουργία του AVR.
- Page 10 ΠΡΑΣΙΝΟ LED ΕΛΕΓΧΟΥ ΣΥΝΔΕΣΗΣ Το πράσινο led είναι ένα εξελιγμένο σύστημα αυτοελέγχου, το οποίο έχει στόχο να βοηθήσει τον τεχνίτη για την σωστή καλωδίωση της νέας εγκατάστασης. Το σύστημα αυτό είναι αποκλειστική πατέντα της POWER ELECTRONICS παγκοσμίως. Το πράσινο led θα ανάψει μόνο* στην...
