Fault
F25
LOW PRESSURE
Description
Low pressure protection.
Possible Cause
The V5 is running and the pressure switch opens for longer than the time entered in
screen G16.5.
Action
Check hydraulic installation (broken pipes). Check pump has got water. Check pressure
switch. Check proper wiring from pressure switch to V5 digital input 2. The V5 will require
resetting on the display or via D INPUT 5 if configured for 2 wire start/stop. Check
parameter setting is done according to application requirements.
Fault
F26
FLOW SWITCH
Description
No flow protection.
Possible Cause
The flow switch is ignored for the time set in screen G16.7 on receipt of a valid start signal.
After this time the V5 will trip if no flow is indicated for longer than the time set in screen
G16.8. No water in the pump.
Action
Check proper pump water supply. Check flow switch. Check proper wiring form flow switch
to V5 digital input 3. The V5 will require resetting on the display or via D INPUT 5 if
configured for 2 wire start/stop. Check parameter setting is done according to application
requirements.
Fault
F27
DEEP WELL PROBE
Description
Low level protection
Possible Cause
The well probe controller (or other level controller) detects a lack of water. The tank or
pump has no water.
Action
Check water level. Check hydraulic installation. Check level switch. Check proper wiring
from deep well probe flow controller to V5 digital input 4. The V5 will not reset unless the
low water fault has been cleared (D INPUT 4 closed). Check parameter setting is done
according to application requirements.
