3. DIMENSIONS AND STANDARD RATINGS.

IP00 – IP54
V2009 – V2075
REFERENCE
V2009
V2017
V2030
V2045
V2060*
V2075*
V2009B*
V2017B*
V2030B*
V2045B*
V2060B*
V2075B*
* All types signed with "*" do have an integrated BYPASS function. The Motor protection is operating
all the time.
12 | POWER ELECTRONICS User's Manual V2
Fig. 4: V2 Dimensions.
220V
A
KW
2.2
9
4
17
9
30
15
45
18.5
60
22
75
2.2
9
4
17
9
30
15
45
18.5
60
22
75
Table 1: V2 standard ratings.
IP54
V2060B – V2075B
380V DIMENSIONS
KW (mm)
4 350x157x132
7,5 350x157x132
15 350x157x132
22 350x157x132
30 350x157x132
37 350x157x132
4 350x157x132
7,5 350x157x132
15 350x157x132
22 350x157x132
30 410x157x132
37 410x157x132
IP
PROTECTION
IP00
IP00
IP00
IP00
IP00
IP00
IP54
IP54
IP54
IP54
IP54
IP54
