8.8 Monitoring Parameter

Name Description
d0.80 ASF status word *
d0.81 Pressure command
d0.82 Pressure feedback
d0.83 Flow command
d0.84 Speed command
d0.85 Reserved
d0.86 Reserved
d0.87 Reserved
d0.88 Warning type
d0.89 Error type
Tab. 8-8: Monitoring parameter
* For detail information of d0.80 ASF status word please reference
status word definition" on page
DOK-RCON03-FCP5020****-QU02-EN-P
0x0000...0xFFFF
0.0...1,000.0 (0.0...1,000.0 bar)
0.0...1,000.0 (0.0...1,000.0 bar)
-5,000...5,000 (-5,000...5,000 rpm)
-5,000...5,000 (-5,000...5,000 rpm)
-
-
-
0: No warning
1: Pressure feedback exceed limit
2: Pressure command exceed limit
3: Flow command exceed limit
4: Oil filter warning
5: Oil level warning
6: Oil temperature warning
7: Oil change warning
8: Reserved
9: Pump thermal protection warning
10: Pump power limitation warning
0: No error
1: Pressure feedback exceed pump limit
2: Pressure sensor error
3: Parameter setting error
4: Oil filter error
5: Oil level error
6: Oil temperature error
7: Oil change error
8: Oil level or temperature error
9: Pump thermal protection error
67.
