Bosch Rexroth AG
Block Diagram of Main Functions

7.5 Quick Configuration For Rexroth HM20 Pressure Sensor

For application using Rexroth HM20 pressure transducer, configuration parame-
ters of HM20 sensor can be automatically loaded by selecting the corresponding
type code in parameter F2.10. Please make sure the right analog input channel
has been set through [F2.00]...[F2.02] before setting [F2.10], since the configu-
ration parameters (AI input mode and scaling factors) will be set for the selec-
ted channel for pressure feedback.
Name
Code
E1.35 AI1 input mode
E1.40 AI2 input mode
H8.05 EAI input mode
F2.00 Analog input AI1
F2.01 Analog input AI2
External analog input EAI
F2.02
(-10V...10V, 4...20mA)
Pressure feedback
F2.06
sponding to 10V or 20mA
22/75
Setting range
0: 0...20 mA
1: 4...20 mA
2: 0...10 V
3: 0...5 V
4: 2...10 V
0...4 (same as E1.35)
5: -10...10 V
0: No function assigned from ASF
1: Pressure command
2: Pressure feedback
3: Flow command
corre-
0.1...1000.0 bar
Default Min.
2 -
1 -
0 -
0 -
2 -
0 -
100.0 0.1
DOK-RCON03-FCP5020****-QU02-EN-P
FcP 5020
Attri.
Run
Run
Stop
Stop
Stop
Stop
Stop
