FcP 5020
Bit
2 Master / slave selection
3 p/Q parameter group selection
4 Reserved
5 Reserved
6 Reserved
7 Reserved
8 Reserved
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 ASF control word enable
Tab. 9-3: ASF control word definition
Bit
0
Control mode
1
2 Master / slave status
3 p/Q parameter group
4 Reserved
5 Reserved
6
Pressure command digital selec-
tion
7
8 Reserved
9 Reserved
DOK-RCON03-FCP5020****-QU02-EN-P
Description
0: Master
1: Slave
0: Parameter group 0
1: Parameter group 1
-
-
-
-
-
-
-
-
-
-
-
0: Inactive
1: Active
Description
0: p/Q control mode
1: Flow control mode
2: p control mode
0: Master
1: Slave
0: Parameter group 0
1: Parameter group 1
-
-
0: F1.05 Pressure command digital setting 0
1: F1.06 Pressure command digital setting 1
2: F1.07 Pressure command digital setting 2
3: F1.08 Pressure command digital setting 3
-
-
Bosch Rexroth AG
Fieldbus Communication
Setting range
Setting range
67/75
