Bosch Rexroth Sytronix FcP 5020 Quick Start Manual page 27

FcP 5020
Name
Code
Pressure feedback null offset
F2.07
in V or mA
F2.10 Pressure sensor type
Tab. 7-4: Parameter list of HM20 pressure sensor auto selection
DOK-RCON03-FCP5020****-QU02-EN-P
Block Diagram of Main Functions
Setting range
0.0...5.0 V, mA
0: Others
1: HM20-2X/10-C
2: HM20-2X/50-C
3: HM20-2X/100-C
4: HM20-2X/160-C
5: HM20-2X/250-C
6: HM20-2X/315-C
7: HM20-2X/400-C
8: HM20-2X/630-C
9: Reserved
10: Reserved
11: HM20-2X/10-H
12: HM20-2X/50-H
13: HM20-2X/100-H
14: HM20-2X/160-H
15: HM20-2X/250-H
16: HM20-2X/315-H
17: HM20-2X/400-H
18: HM20-2X/630-H
Bosch Rexroth AG
Default Min. Attri.
4.0
0.1 Stop
(mA)
3 - Stop
23/75
