Bosch Rexroth AG
Block Diagram of Main Functions
Code
F2.00 Analog input AI1
F2.01 Analog input AI2
External analog input EAI (-10V...
F2.02
10V, 4...20mA)
Pressure command corresponding
F2.04
to 10V or 20mA
Pressure command null offset in V
F2.05
or mA
F3.10 Filter time for pressure rising [0]
Filter time for pressure dropping
F3.11
[0]
F4.00 Protection function control word
F4.20 p/Q command soft start delay
F4.21 Minimum pressure command limit
F4.22 Maximum pressure command limit [F4.21]...1,000.0 bar
Tab. 7-2: Parameter list of pressure command processing
The setting is equally applicable to another parameter group related
to filter time for pressure command rising and dropping, i.e. F3.30,
F3.31.
F2.04, F2.05: Scaling for pressure command
Fig. 7-5: Pressure command scaling
20/75
Name
0: No function assigned from
ASF
1: Pressure command
2: Pressure feedback
3: Flow command
0.1...1,000.0 bar
0.0...5.0 V, mA
0...999 ms
0...999 ms
0...15
Bit0: Pressure sensor failure
(PSF)
Bit1: Actual pressure monitor-
ing
Bit2: p/Q max. command limit
Bit3: Oil changing detection
0.0...1,000.0 s
0.0...[F4.22] bar
Setting range
DOK-RCON03-FCP5020****-QU02-EN-P
FcP 5020
Default Min.
Attri.
0
-
Stop
2
-
Stop
0
-
Stop
10.0
0.1
Stop
0.0
0.1
Stop
80
1
Run
40
1
Run
0
-
Run
0.0
0.1
Stop
5.0
0.1
Stop
250.0
0.1
Stop
