FcP 5020
Code
F2.16 X1 input
F2.17 X2 input
F2.18 X3 input
F2.19 X4 input
F2.20 X5 input
F2.21 EX1 input
F2.22 EX2 input
F2.23 EX3 input
F2.24 EX4 input
DOK-RCON03-FCP5020****-QU02-EN-P
Name
0: No function assigned from
ASF
1: Pressure command selec-
tion bit0
2: Pressure command selec-
tion bit1
3: p/Q parameter selection
4: Reserved
5: Master / slave mode switch
6: Oil filter warning
7: Oil level warning
8: Oil temperature warning
9: Oil filter error
10: Oil level error
11: Oil temperature error
12: Oil level / temperature
error
13: Oil filter warning inverse
14: Oil level warning inverse
15: Oil filter error inverse
16: Oil level / temperature
error inverse
17: Reserved
18: Reserved
19: Reserved
20: Pressure drop compensa-
tion trigger
21: Pressure overshoot com-
pensation trigger
FcP 5020 Parameter List
Setting range Default Min.
(RUN)
(Error
reset)
Bosch Rexroth AG
Attri.
0
- Stop
0
- Stop
0 - Stop
0 - Stop
0 - Stop
0 - Stop
0 - Stop
0 - Stop
0 - Stop
57/75
