FcP 5020 Parameter List
Code
AO1 output
F2.31
(use E2.27 for gain)
EAO output
F2.32
(use H8.27 for gain)
F2.36 DO1 output
F2.37 EDO output
F2.40 Relay 1 output
F2.41 Extension relay output
Tab. 8-2: Parameter list of group F2
Analog output setting:
For example:
F2.31=1: Pressure command
●
F2.31 = 2: Pressure feedback
●
F2.31 = 3: Setting speed
●
F2.31 = 4: Output speed
●
58/75
Name
0: No function assigned from
ASF
1: Pressure command (scaled
by F2.04)
2: Pressure feedback (scaled
by F2.06)
3: Setting speed (include di-
rection) (scaled by F2.08)
4: Output speed (include di-
rection) (scaled by F2.08)
0: No function assigned from
ASF
1: Converter warning
2: Green CytroPac flashing
LED
3: Red CytroPac flashing LED
0: No function assigned from
ASF
1: Converter warning
2: Two points / double pump
control
Setting range
Default Min.
DOK-RCON03-FCP5020****-QU02-EN-P
FcP 5020
Attri.
0
-
Run
0
-
Run
1
-
Run
0
-
Run
0
-
Run
0
-
Run
