3.4 DMX MODE

• Press the button MENU so many times until the display shows DMX ADDRESS, and press the button ENTER
to confirm.
• Press UP/DOWN button to select the desired value (001-512). Press and hold to scroll quickly.
• Press ENTER button to store.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.
To able to operate the ECLIPSEPARFC with a light controller, adjust the DMX start address for the first a
DMX channel. If e. g. address 33 on the controller is provided for controlling the function of the first DMX
channel, adjust the start address 33 on the ECLIPSEPARFC. The other functions of the light effect panel are
then automatically assigned to the following addresses.
An example with the start address 33 is shown below:
Number
Address of
DMX
start (example)
channels
6 33

3.5 DMX CONFIGURATION

ECLIPSEPARFC is equipped with different DMX configuration.
• Press the button MENU so many times until shows DMX CHANNEL, and press the button ENTER to confirm.
• Select the desired DMX configuration ( 1CH - 2CH - 4CH1 - 5CH - 6CH1 - 10CH1 - 15CH1 - 4CH2 - 6CH2 - 10CH2 - 15CH2
) through the buttons UP/DOWN.
3.6 SETTINGS
You can change the parameters for the device by following these steps:
SCREEN
You can change the following parameters related to the display, following the same procedure:
• Press the MENU button to access the main menu.
• Press the UP / DOWN keys to scroll the menu, select the Set Up icon, then press the ENTER button to
enter the next menu.
• Press UP / DOWN to scroll through the menu, then select Screen, and press the ENTER button to enter
the next menu.
• Press UP / DOWN to scroll through the menu, and then select one of the following settings for the dis-
play and press the ENTER key to display it.
- Back Light - Backlight display Auto Off. This feature allows you to automatically turn off the backlight
after a specified time that you can set using the arrow buttons. To have the display always on select
On or choose another value to turn off the display after the amount of time you choose.
- Flip Display - Orientation of the display. This function allows you to rotate the display 180° to get a
better view of the display when the unit is hanging upside down. Select YES to activate or NO to dis-
able this function.
- Key Lock - With this function, you can lock the buttons on the control panel. If this functionis activat-
ed, the keys are automatically locked. To disable or temporarily disable the key lock function, press
the buttons in the following order to regain access to menu commands: UP, DOWN, UP, DOWN,
ENTER. Select ON to activate or OFF to disable
• Press the ENTER button to confirm your choice.
• Press the MENU button repeatedly to exit the menu and save changes.
ECLIPSEPARFC
DMX address Next possible start address
occupied for unit No. 1
33 - 38
Next possible start address
for unit No. 2
39
Next possible start address
for unit No. 3
44 49
