- Page 1 EclProfile FW IPVW High quality Full White LED ellipsoidal with Variable White source USER MANUAL English version REV.02-06/22...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
-
Page 3: Table Of Contents
ROTATING GOBO ASSEMBLY (CODE ECLPRIPROTGOBO1 - OPTIONAL) ....28 14 - TEST OF IP65 RATING 15 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............30 REPLACING THE FUSE ....................30 VISUAL CHECK OF PRODUCT HOUSING ..............30 TROUBLESHOOTING ..................... 31 PROLIGHTS - EclProfile FW IPVW... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. Installation •... - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - EclProfile FW IPVW...
-
Page 7: Packaging
• ECLPRPOYO: pole operated aluminium yoke bracket for ECLCTPLUS and ECLFS; • ECLPRIPROTGOBO1BK/WH: rotating gobo assembly for ECL Profile fixtures, black/white; • IPTESTBOX: portable vacuum and pressure tester for ProLights IP fixtures; • SPGM12: 28mm spigot for fixtures, M12 bolt;... -
Page 8: Technical Drawing
2 - TECHNICAL DRAWING Weight: 7.3 kg - 16.09 lbs ECLFWIPVW without optic Weight: 10.2 kg - 22.48 lbs ECLFWIPVW with ECLPRL05 Weight: 9.2 kg - 20.28 lbs ECLFWIPVW with ECLPRL10 PROLIGHTS - EclProfile FW IPVW... - Page 9 Weight: ECLPRL26: 9.7 kg - 21.38 lbs ECLFWIPVW with ECLPRL26 Weight: ECLPRL36: 9.4 kg - 20.72 lbs ECLFWIPVW with ECLPRL36 Weight: ECLPRL50: 9 kg - 19.84 lbs ECLFWIPVW with ECLPRL50 Weight: 9.1 kg - 20.06 lbs ECLFWIPVW with ECLPRL70 PROLIGHTS - EclProfile FW IPVW...
- Page 10 Weight: 11.3 kg - 24.91 lbs ECLFWIPVW with ECLPRLZ1530 Weight: 11.3 kg - 24.91 bs ECLFWIPVW with ECLPRLZ2550 Fig. 01 PROLIGHTS - EclProfile FW IPVW...
-
Page 11: Installation
Do not use any type of clamp that does not completely encircle the structure when fastened. RSR0630A/B RSR0630A/B steel security cable steel security cable C6040 C6002 clamp clamp 213 mm Ø13 mm [8.4 in] [Ø0.5 in] 80 mm [3.1 in] Fig. 02 PROLIGHTS - EclProfile FW IPVW... -
Page 12: Connection To The Mains Supply
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - EclProfile FW IPVW... -
Page 13: Product Overview
12. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (T5A, 250 V); ); 13. POWER IN: for connection to the Mains 100-240V~/50-60Hz; 14. POWER OUT: power output for connection of multiple units in series; 15. GORE VALVE. 12 13 Fig. 03 PROLIGHTS - EclProfile FW IPVW... -
Page 14: Dmx Connection
... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 05 - Example 9 DMX channels configuration PROLIGHTS - EclProfile FW IPVW... -
Page 15: Construction Of The Dmx Termination
2. Reach the addressing menu, then select the DMX ADDRESS settings. 3. Select the address from 1 to 512 using the navigation arrows/buttons and confirm by pressing ENTER. 4. Press Menu to exit and return to the Home screen. PROLIGHTS - EclProfile FW IPVW... -
Page 16: Control Panel
UP: Browse upwards through the menu list and increases the numeric value displayed. DOWN: Browse downwards through the menu list and decreases the numeric value displayed. ENTER: Used to confirm the current menu or confirm the current function value or option within a menu. PROLIGHTS - EclProfile FW IPVW... -
Page 17: Menu Structure
Gobo Rot. Enable Disable Gobo functionality. DMX Mode in use is automatically converted to "Gobo" version. DMX Mode list is switched to "Gobo Rot On" version. Calibration Manufacturer calibration to grant performance and color consistency. PROLIGHTS - EclProfile FW IPVW... - Page 18 TION Hours about product. Lamp Hours Power Cycles Power Consumtion Temperature Fan Speed Gobo Rot. Gobo Rot. RDM Id Version FACTORY Abort To reset the unit to SETTINGS Set Default factory default settings. Values PROLIGHTS - EclProfile FW IPVW...
-
Page 19: Rdm Functions
0x0082 FACTORY_DEFAULTS 0x0090 SOFTWARE_VERSION_LABEL 0x00c0 BOOT_SOFTWARE_VERSION_ID 0x00c1 BOOT_SOFTWARE_VERSION_LABEL 0x00c2 DMX_PERSONALITY 0x00e0 DMX_PERSONALITY_DESCRIPTION 0x00e1 DMX_START_ADDRESS 0x00f0 SENSOR_DEFINITION 0x0200 SENSOR_VALUE 0x0201 DEVICE_HOURS 0x0400 LAMP_HOURS 0x0401 LAMP_STRIKES 0x0402 DEVICE_POWER_CYCLES 0x0405 IDENTIFY_DEVICE 0x1000 RESET_DEVICE 0x1001 MOTOR_ENABLE 0x8200 MOTOR_RESET 0x8201 PROLIGHTS - EclProfile FW IPVW... -
Page 20: Shortcuts
"Can't load Pg1" Error "Can't load Pg2" Error "Can't load flash" Error Gobo Rot. "Gobo position lost" Warning Refernce signal at unex- pected position "Gobo ref. disabled" Information Use of reference position automatically disabled after referencing failed PROLIGHTS - EclProfile FW IPVW... -
Page 21: Dmx Charts
STROBE STROBE WARM WHITE WARM WHITE XFade FROM WARM WHITE CONTROL COLD WHITE CCT to WW/CW FINE WARM WHITE CONTROL COLD WHITE WARM WHITE COLD WHITE FINE FINE COLD WHITE CONTROL COLD WHITE FINE CONTROL PROLIGHTS - EclProfile FW IPVW... - Page 22 CROSSFADE FROM CCT to WW/CW 000 ÷ 255 Linear crossfade from CCT to WW/CW WARM WHITE 000 ÷ 255 0÷100% WARM WHITE FINE 000 ÷ 255 COLD WHITE 000 ÷ 255 0÷100% COLD WHITE FINE 000 ÷ 255 PROLIGHTS - EclProfile FW IPVW...
- Page 23 DMX Lost Slave 104 ÷ 105 Gobo Rot. Off 106 ÷ 107 Gobo Rot. On 108 ÷ 109 Gobo Rot. Reset 110 ÷ 111 Reserved 112 ÷ 253 Reset All Channels Control 254 ÷ 255 PROLIGHTS - EclProfile FW IPVW...
- Page 24 WARM WHITE CONTROL COLD WHITE GOBO ROT. WARM WHITE COLD WHITE GOBO ROT. FINE. FINE FINE GOBO ROT. COLD WHITE CONTROL FINE. COLD WHITE GOBO ROT. FINE GOBO ROT. CONTROL FINE. GOBO ROT. GOBO ROT. FINE. PROLIGHTS - EclProfile FW IPVW...
- Page 25 Pos 216,56° Pos 219,38° Pos 222,19° Pos 225,00° Pos 227,81° Pos 230,63° Pos 233,44° Pos 236,25° Pos 239,06° Pos 241,88° Pos 244,69° Pos 247,50° Pos 250,31° Pos 253,13° Pos 255,94° Pos 258,75° Pos 261,56° Pos 264,38° PROLIGHTS - EclProfile FW IPVW...
- Page 26 CW Spin 1,16 rpm CW Spin 0,97 rpm CW Spin 0,79 rpm CW Spin 0,63 rpm CW Spin 0,49 rpm CW Spin 0,36 rpm CW Spin 0,26 rpm CW Spin 0,17 rpm CW Spin 0,10 rpm Stop PROLIGHTS - EclProfile FW IPVW...
- Page 27 CCW Spin 36,47 rpm CCW Spin 37,63 rpm CCW Spin 38,81 rpm CCW Spin 40,00 rpm GOBO ROTATION FINE All 16bit DMX values are possible, 000 ÷ 255 the list above only shows intermedium value. PROLIGHTS - EclProfile FW IPVW...
-
Page 28: Accessories Installation
OPTIC (CODE ECLPRL - OPTIONAL) Loosen and remove the two marked knobs of the optic. Mount the desired optic (A) in the middle part. Then insert and tighten the knobs (B) in the holes. Fig. 08 PROLIGHTS - EclProfile FW IPVW... -
Page 29: Gel Filter Frame (Code Eclprtpg - Optional)
Push the clip (A), located at the top of the optics body, outwards and lift it (B). DETAIL Insert the filter (A) into the marked track (DETAIL) and close the clip (B), always applying an outward push. NOTE: To remove the accessory, reverse the procedure. Fig. 09 PROLIGHTS - EclProfile FW IPVW... -
Page 30: Gobo Holder (Code Eclprgh - Optional)
• Ø external (OD)= 86 mm (3.4 in) • Ø of image (ID)= 64.5 mm (2.5 in) • Thinckness= 1.1 mm (0.04 Put in place the gobo (2). ATTENTION! Load with mirror surface toward the light source. Please turn! PROLIGHTS - EclProfile FW IPVW... - Page 31 Loosen the marked screws (A). Then open the slot of the middle part (B). Insert the gobo holder into the slot. The flaps (A) will go into the appropriate size. NOTE: To remove the accessory, reverse the procedure. Fig. 11 PROLIGHTS - EclProfile FW IPVW...
-
Page 32: Steel Iris Diaphram (Code Eclpriris - Optional)
Loosen the marked screws (A). Then open the slot of the middle part (B). Insert the steel iris diaphram into the slot. The flaps (A) will go into the appropriate size. NOTE: To remove the accessory, reverse the procedure. Fig. 12 PROLIGHTS - EclProfile FW IPVW... -
Page 33: Soft Edge Filter (Code Eclprsef1 - Optional)
Loosen the marked screws (A). Then open the slot of the middle part (B). Insert the soft edge filter into the slot. The flaps (A) will go into the appropriate size. NOTE: To remove the accessory, reverse the procedure. Fig. 13 PROLIGHTS - EclProfile FW IPVW... -
Page 34: Soft Focus Diffusion (Code Eclprsmoothf1 - Optional)
Loosen the marked knob (A) and screw (B). Then rotate (C) the middle part and remove it (D). DETAIL Insert the soft focus diffusion (A) by placing the magnets (DETAIL) on the back of the framing system (B) of the middle part. NOTE: To remove the accessory, reverse the procedure. Fig. 14 PROLIGHTS - EclProfile FW IPVW... -
Page 35: The Pole Operated Yoke (Code Eclprpoyo - Optional)
Loosen and remove the marked screws (A). Then remove the bracket (B). DETAIL Mount the Pole Operated Yoke bracke (A) and tighten the screws (DETAIL). NOTE: To remove the accessory, reverse the procedure. Fig. 15 PROLIGHTS - EclProfile FW IPVW... -
Page 36: Rotating Gobo Assembly (Code Eclpriprotgobo1 - Optional)
Insert the soft edge filter into the slot. The flaps (A) will go into the appropriate size. Then connect the rotating gobo assembly throught the connector (C) into the socket. NOTE: To remove the accessory, reverse the procedure. Fig. 16 PROLIGHTS - EclProfile FW IPVW... -
Page 37: Test Of Ip65 Rating
Connect the air hose to the IPTESTBOX by inserting the quick-connect fitting into the coupler (2). Insert the threaded end into the threaded valve hole socket (3). For the operating procedure using the instrument, refer to the IPTESTBOX user manual. Fig. 17 PROLIGHTS - EclProfile FW IPVW... -
Page 38: Maintenance
WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. -
Page 39: Troubleshooting
• Check if the Fuse is intact and eventually replace it if fault. necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in... - Page 40 Note...
- Page 41 Note...
- Page 42 Note...
- Page 44 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
