EclPanel TWCXL
1.500W Tuneable White and colourful LED
soft light with pixels and lighting effects
USER MANUAL
English version
REV.01-07/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EclPanel TWCXL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProLights EclPanel TWCXL

Summary of Contents for ProLights EclPanel TWCXL

  • Page 1 EclPanel TWCXL 1.500W Tuneable White and colourful LED soft light with pixels and lighting effects USER MANUAL English version REV.01-07/22...
  • Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.

  • Page 3: Table Of Contents

    FRONT HIGH / MEDIUM / LOW DIFFUSION FILTER (CODES EPTWCXLFILTERHD / MD / LD - OPTIONAL) ......................88 14 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............89 REPLACING THE FUSE ....................89 VISUAL CHECK OF PRODUCT HOUSING ..............89 TROUBLESHOOTING ..................... 90 PROLIGHTS - EclPanel TWCXL...

  • Page 4: Safety Information

    • Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. Installation •...
  • Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
  • Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - EclPanel TWCXL...

  • Page 7: Packaging

    • C6046A/B: aluminum clamp for 28mm spigot, 100kg loa, 40-55mm tubes, silver/black. • RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black. • UPBOX1UP5: firmware uploader kit, USB IN, 5pin XLR DMX OUT, USB OUT. PROLIGHTS - EclPanel TWCXL...

  • Page 8: Technical Drawing

    [7.3] [37.8] Weight: 48,7 kg - 107,36 lbs 1711 mm 586 mm 1165 mm [67.4 in] [23.1 in] [45.9 in] Empty weight: 125 kg - 275,58 lbs Full weight: 225 kg - 496,04 lbs Fig. 01 PROLIGHTS - EclPanel TWCXL...

  • Page 9: Installation

    Do not use any type of clamp that does not completely encircle the structure when fastened. RSR0630A/B C6046 steel security cable clamp Ø13 mm 0.5 in Ø5 mm 0.2 in 25 mm 1.0 in Fig. 02 PROLIGHTS - EclPanel TWCXL...

  • Page 10: Connection To The Mains Supply

    • Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - EclPanel TWCXL...

  • Page 11: Product Overview

    13. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (250V,T20A, Ø6X30). ). 14. WEIPU SA12 series 4P-F connector for remote control. WEIPU SA12 series 4P-F connector for remote control. Fig. 03 PROLIGHTS - EclPanel TWCXL...

  • Page 12: Dmx Connection

    ... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 05 - Example 15 DMX channels configuration PROLIGHTS - EclPanel TWCXL...

  • Page 13: Construction Of The Dmx Termination

    This function allow a product receiving an ethernet signal protocol to re-transmit the incoming signal onto a wired DMX line through its onboard XLR-out connector. • An Ethernet protocol (Artnet, sACN or others available) has to be enabled from Ethernet menu PROLIGHTS - EclPanel TWCXL...

  • Page 14: Operation As A Wireless Transmitter

    4. Select WDMX mode and set it on Receiver (please note that WDMX mode will be available only if WDMX ON/OFF is set to ON). 5. Enable RX RESET to ON to reset the receiver (please note that RX RESET will be available only if WDMX mode is set to Receiver). PROLIGHTS - EclPanel TWCXL...

  • Page 15: Wdmx To Dmx (Rx)

    • The wireless icon on the receiver display indicates the received signal strength. WDMX TO DMX (RX) This function enable or disable the retransmission of the wireless DMX signal received throught the DMX port on the receiver side. PROLIGHTS - EclPanel TWCXL...

  • Page 16: Control Panel

    • Used to access the menu tree and to confirm selec- tions. • Programmable quick buttons. • Quick info shortcut. • Quick Settings shortcut. • Quick Colors shortcut. • Dimmer function on Standalone Mode. 2 - 4 • Parameter tweaking on Standalone Mode. PROLIGHTS - EclPanel TWCXL...

  • Page 17: Menu Structure

    Set Dimmer End behaviour. Fade Off @ End Snap Off will make fixture snap when dimming out to 0. Fade Off will make fixture fade when dimming out to 0. This selection affects only 004-000 DMX value behaviour. PROLIGHTS - EclPanel TWCXL...
  • Page 18 Auto mode automatically flips the display when needed. Auto Keylock Lock the buttons on the control panel by a password: UP, DOWN, UP, DOWN, ENTER. Configura- Mode 1 Stores all setting to the tion Presets Mode 2 Mode 3 Mode 4 PROLIGHTS - EclPanel TWCXL...
  • Page 19 Show software version for each PCB. Version CTR2: V1.1.00.0 DISP: V1.1.00.0 RDM UID 15D0022F**** View the UID of the product (RDM control). Documen- Shows QR Codes for direct access to User Manual tation and DMX Charts PROLIGHTS - EclPanel TWCXL...

  • Page 20: Dimmer Curves

    4. INVERSE SQUARE LAW - Light intensity control is coarser at low levels and finer at high levels. 5. HIGHRES@LOW - Very Fine control at low light intensity and coarser at medium and high levels. LINEAR S-CURVE DMX % DMX % SQUARE LAW INVERSE SQUARE LAW DMX % DMX % HIGHRES@LOW DMX % PROLIGHTS - EclPanel TWCXL...

  • Page 21: Rdm Functions

    0x0081 DEVICE_LABEL 0x0082 FACTORY_DEFAULTS 0x0090 SOFTWARE_VERSION_LABEL 0x00C0 DMX_PERSONALITY 0x00E0 DMX_PERSONALITY_DESCRIPTION 0x00E1 DMX_START_ADDRESS 0x00F0 SENSOR_DEFINITION (LED temperature sensor) 0x0200 CURVE 0x0343 CURVE_DESCRIPTION 0x0344 OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_DESCRIPTION 0x0348 DEVICE_HOURS 0x0400 DISPLAY_INVERT 0x0500 IDENTIFY_DEVICE 0x1000 PROLIGHTS - EclPanel TWCXL...

  • Page 22: Dmx Charts

    CCT + XY 16 bit CCT + XY + GEL 8 bit CCT + XY + GEL 16 bit CCT + XY + FX 8 bit CCT + XY + FX 16 bit EXTENDED Control 8bit EXTENDED Control 16 bit PROLIGHTS - EclPanel TWCXL...

  • Page 23: M1 Cct 8 Bit

    Dimmer Fine Strobe Green Blue Red Fine White Green White Point Green Fine Preset Blue Fan Control Blue Fine Control Channel White RESERVED White Fine White Point White Point Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 24: M5 Hsi 8Bit

    Crossfade XY1 to XY2 Y 1 Fine Transition type control Preset Crossfade XY1 to XY2 Fan Control Crossfade XY1 to XY2 Fine Control Channel RESERVED X 2 Fine Y 2 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 25: M9 Gel 8Bit

    Fan Control FX Parameter 4 Fine Control Channel FX Parameter 5 RESERVED FX Parameter 5 Fine FX Parameter 6 FX Parameter 6 Fine FX Parameter 7 FX Parameter 7 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 26: M13 Source Emulation 8 Bit

    Green-Magenta Point Fine Blue Crossfade CCT to RGBW White Crossfade CCT to RGBW Fine Preset Fan Control Red Fine Control Channel Green RESERVED Green Fine Blue Blue Fine White White Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 27: M17 Cct + Rgbw + Gel 8 Bit

    Blue Preset Blue Fine Fan Control White Control Channel White Fine RESERVED Crossfade RGBW to GEL Crossfade RGBW to GEL Fine GEL Source CCT GEL Brand GEL Categor GEL Selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 28: M19 Cct + Rgbw + Fx 8 Bit

    FX Parameter 3 Fine FX Parameter 4 FX Parameter 4 Fine FX Parameter 5 FX Parameter 5 Fine FX Parameter 6 FX Parameter 6 Fine FX Parameter 7 FX Parameter 7 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 29: M21 Cct + Hsi 8Bit

    Crossfade CCT to HSI CCT Fine Green-Magenta Point Saturation Green-Magenta Point Fine Preset Crossfade CCT to HSI Fan Control Crossfade CCT to HSI Fine Control Channel RESERVED Hue Fine Saturation Saturation Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 30: M23 Cct + Hsi + Gel 8 Bit

    Hue Fine GEL Selector Saturation Preset Saturation Fine Fan Control Crossfade HSI to GEL Control Channel Crossfade HSI to GEL Fine RESERVED GEL Source CCT GEL Brand GEL Categor GEL Selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 31: M25 Cct + Hsi + Fx 8 Bit

    FX Parameter 3 Fine FX Parameter 4 FX Parameter 4 Fine FX Parameter 5 FX Parameter 5 Fine FX Parameter 6 FX Parameter 6 Fine FX Parameter 7 FX Parameter 7 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 32: M27 Cct + Xy 8 Bit

    Crossfade CCT to XY CCT Fine Green-Magenta Point Green-Magenta Point Fine Preset Crossfade CCT to XY Fan Control Crossfade CCT to XY Fine Control Channel RESERVED X Fine Y Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 33: M29 Cct + Xy + Gel 8 Bit

    X Fine GEL Selector Preset Y Fine Fan Control Crossfade XY to GEL Control Channel Crossfade XY to GEL Fine RESERVED GEL Source CCT GEL Brand GEL Categor GEL Selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...

  • Page 34: M31 Cct + Xy + Fx 8 Bit

    FX Parameter 3 Fine FX Parameter 4 FX Parameter 4 Fine FX Parameter 5 FX Parameter 5 Fine FX Parameter 6 FX Parameter 6 Fine FX Parameter 7 FX Parameter 7 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 35 Layer2 Parameter 4 Fine Layer2 Parameter 5 Layer2 Parameter 5 Fine Layer2 Parameter 6 Layer2 Parameter 6 Fine Layer2 Parameter 7 Layer2 Parameter 7 Fine Layer2 Parameter 8 Layer2 Parameter 8 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 36 CCT + RGBW 16 bit 12PX M21 CCT + HSI 8bit 12PX M22 CCT + HSI 16 bit 12PX M27 CCT + XY 8 bit XY coords are 16bit 12PX M28 CCT + XY 16 bit PROLIGHTS - EclPanel TWCXL...
  • Page 37 48PX M15 CCT + RGBW 8 bit 48PX M21 CCT + HSI 8bit 48PX M27 CCT + XY 8 bit XY coords are 16bit PIXEL LAYOUT 1 Pixel 2 Pixel 6 Pixel 12 Pixel 48 Pixel PROLIGHTS - EclPanel TWCXL...
  • Page 38 2PX M4 6PX M3 6PX M4 12PX M3 12PX M4 48PX M3 48PX M4 Function Dimmer Dimmer Fine Strobe Red Fine Green Green Fine Blue Blue Fine White White Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 39 Saturation Fine Last Cell 2PX M5 2PX M6 6PX M5 6PX M6 12PX M5 12PX M6 48PX M5 48PX M6 Function Dimmer Dimmer Fine Strobe Hue Fine Saturation Saturation Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 40 48PX M7 48PX M8 Function Dimmer Dimmer Fine Strobe X 1 Fine Y 1 Fine Crossfade XY1 to XY2 Crossfade XY1 to XY2 Fine X 2 Fine Y 2 Fine Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 41 CCT Fine Green-Magenta Point Green-Magenta Point Fine Crossfade CCT to RGBW Crossfade CCT to RGBW Fine Red Fine Green Green Fine Blue Blue Fine White White Fine CCT Range selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 42 12PX M21 12PX M22 48PX M21 48PX M22 Function Dimmer Dimmer Fine Strobe CCT Fine Green-Magenta Point Green-Magenta Point Fine Crossfade CCT to HSI Crossfade CCT to HSI Fine Hue Fine Saturation Saturation Fine CCT Range selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 43 12PX M27 12PX M28 48PX M27 48PX M28 Function Dimmer Dimmer Fine Strobe CCT Fine Green-Magenta Point Green-Magenta Point Fine Crossfade CCT to XY Crossfade CCT to XY Fine X Fine Y Fine CCT Range selector Preset Fan Control Control Channel RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 44 3800 3900 9102 10012 3900 4000 10012 10923 4000 4100 10923 11833 4100 4200 11833 12743 4200 4300 12743 13653 4300 4400 13653 14563 4400 4500 14563 15474 4500 4600 15474 16384 4600 4700 16384 17294 PROLIGHTS - EclPanel TWCXL...
  • Page 45 9100 9200 57343 58253 9200 9300 58253 59164 9300 9400 59164 60074 9400 9500 60074 60984 9500 9600 60984 61894 9600 9700 61894 62804 9700 9800 62804 63715 9800 9900 63715 64625 9900 10000 64625 65535 PROLIGHTS - EclPanel TWCXL...
  • Page 46 6800 6900 23552 24064 6900 7000 24064 24576 7000 7100 24576 25088 7100 7200 25088 25600 7200 7300 25600 26112 7300 7400 26112 26624 7400 7500 26624 27136 7500 7600 27136 27648 7600 7700 27648 28160 PROLIGHTS - EclPanel TWCXL...
  • Page 47 12400 12500 52223 52735 12500 12600 52735 53247 12600 12700 53247 53759 12700 12800 53759 54271 12800 12900 54271 54783 12900 13000 54783 55295 13000 13100 55295 55807 13100 13200 55807 56319 13200 13300 56319 56831 PROLIGHTS - EclPanel TWCXL...
  • Page 48 4200 4300 8485 8846 4300 4400 8846 9207 4400 4500 9207 9568 4500 4600 9568 9930 4600 4700 9930 10291 4700 4800 10291 10652 4800 4900 10652 11013 4900 5000 11013 11374 5000 5100 11374 11735 PROLIGHTS - EclPanel TWCXL...
  • Page 49 9700 9800 28344 28705 9800 9900 28705 29066 9900 10000 29066 29428 10000 10100 29428 29789 10100 10200 29789 30150 10200 10300 30150 30511 10300 10400 30511 30872 10400 10500 30872 31233 10500 10600 31233 31594 PROLIGHTS - EclPanel TWCXL...
  • Page 50 15200 15300 48203 48565 15300 15400 48565 48926 15400 15500 48926 49287 15500 15600 49287 49648 15600 15700 49648 50009 15700 15800 50009 50370 15800 15900 50370 50731 15900 16000 50731 51092 16000 16100 51092 51453 PROLIGHTS - EclPanel TWCXL...
  • Page 51 Neutral / No Effect Full Minus Green 1023 -99% to -1% 1024 32511 Neutral / No Effect 32512 33023 Default @ 128 1% to 99% 33024 64511 Full Plus Green 64512 65023 Neutral / No Effect 65024 65535 PROLIGHTS - EclPanel TWCXL...
  • Page 52 Default @ 255 8 bit value 16 bit value Function Note From From 0 - 360° 65535 Default @ 255 Saturation 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 53 6800 6900 23552 24064 6900 7000 24064 24576 7000 7100 24576 25088 7100 7200 25088 25600 7200 7300 25600 26112 7300 7400 26112 26624 7400 7500 26624 27136 7500 7600 27136 27648 7600 7700 27648 28160 PROLIGHTS - EclPanel TWCXL...
  • Page 54 12400 12500 52223 52735 12500 12600 52735 53247 12600 12700 53247 53759 12700 12800 53759 54271 12800 12900 54271 54783 12900 13000 54783 55295 13000 13100 55295 55807 13100 13200 55807 56319 13200 13300 56319 56831 PROLIGHTS - EclPanel TWCXL...
  • Page 55 Default @ 0 Over White Point Under White Point Reserved Crossfade Layer 1 to Layer 2 8 bit value 16 bit value Function Note From From Linear, Layer 1 to Layer 2 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 56 600 Series Default @ 0 Cosmetic Filters 700 Series Reserved Gel Category Selector (when Gel Brand @ Color) 8 bit value 16 bit value Function Note From From Color Correction CColor SSelection Default @ 0 Reserved PROLIGHTS - EclPanel TWCXL...
  • Page 57 LEE Fluorescent 5700 Kelvin LEE Fluorescent 4300 Kelvin LEE Fluorescent 3600 Kelvin LEE Plus Green 1/2 Plus Green 1/4 Plus Green 1/8 Plus Green Lee Minus Green 1/2 Minus Green 1/4 Minus Green 1/8 Minus Green RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 58 Deep Amber Primary Red Light Rose English Rose Light Salmon Middle Rose Dark Pink Magenta Peacock Blue Steel Blue Light Blue Deep Blue LEE Green Fern Green Dark Green Smokey Pink Bright Pink Marine Blue Golden Amber PROLIGHTS - EclPanel TWCXL...
  • Page 59 Regal Blue RESERVED Gel (LEE: Color Correction) 8 bit value 16 bit value Function Gel Number From From Arctic White Silver Platinum Moonlight White Full CT 85 Industry Sodium HI Sodium Urban Sodium LO Sodium RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 60 Mikkel Blue Colour Wash Blue Berry Blue Virgin Blue Ocean Blue Old Steel Blue Steel Green Liberty Green Dirty Ice Damp Squib JAS Green Bram Brown Dirty White Brown Easy White Seedy Pink Wheat Sun Colour Straw PROLIGHTS - EclPanel TWCXL...
  • Page 61 Full Minusgreen 3308 3/4 Minusgreen 3309 1/2 Minusgreen 3313 1/4 Minusgreen 3314 1/8 Minusgreen 3318 Fluorofilter 3310 Industrial Vapor 3150 Urban Vapor 3152 Tough Y-1 3107 Tough MT 54 3134 Tough MTY 3106 Tough MT2 3102 RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 62 Function Gel Number From From VS Red 2001 VS Orange 2002 VS Yellow 2003 VS Green 2004 VS Cyan 2005 VS Azure 2006 VS Blue 2007 VS Indigo 2008 VS Violet 2009 VS Magenta 2010 RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 63 Tipton Blue Blue Bell Daylight Blue Tharon Delft Blue Cerulean Blue Bermuda Blue Green Blue Alice Blue Primary Blue Baldassari Blue Medium Blue Pale Yellow Green Light Green Moss Green Primary Green Turquoise Blue Green Chocolate RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 64 CCT 1700K - 2000K 21760 43775 Default @ 0 CCT 2000K - 2300K 43776 65535 Candle - P2: Speed 8 bit value 16 bit value Function Note From From Slow to fast 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 65 From From Slow to fast 65535 Default @ 0 Color Chase - P3: Saturation 8 bit value 16 bit value Function Note From From CCT 2800K - 10000K Default @ 0 Saturation 0 - 1 65535 PROLIGHTS - EclPanel TWCXL...
  • Page 66 CCT 2200K - 2600K 21760 43775 Default @ 0 CCT 2600K - 3000K 43776 65535 Fire - P2: Speed 8 bit value 16 bit value Function Note From From Slow to fast 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 67 64511 Full Plus Green 64512 65023 Neutral / No Effect 65024 65535 Strobe - P4: Crossfade from CCT to Color 8 bit value 16 bit value Function Note From From Linear Crossfade 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 68 33024 64511 Full Plus Green 64512 65023 Neutral / No Effect 65024 65535 Lightning - P5: Trigger 8 bit value 16 bit value Function Note From From Reserved 65279 Default @ 0 Reset Loop 65280 65535 PROLIGHTS - EclPanel TWCXL...
  • Page 69 16 bit value Function Note From From 4s to 0.25s 65535 Default @ 0 Pulsing - P3: CCT 8 bit value 16 bit value Function Note From From CCT 2800K - 10000K 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 70 CCT 4700K - 6500K 21760 43775 Default @ 0 CCT 6500K - 10000K 43776 65535 Television - P2: Speed 8 bit value 16 bit value Function Note From From Slow to fast 65535 Default @ 0 PROLIGHTS - EclPanel TWCXL...
  • Page 71 8 bit value 16 bit value Function Note From From 0 - 360° 65535 Default @ 0 Explosion - P7: Saturation 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 72 16 bit value Function Note From From 0 - 360° 65535 Default @ 0 Fluorescent Flicker - P7: Saturation 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 73 16 bit value Function Note From From 0 - 360° 65535 Default @ 0 Process Effect - P7: Saturation 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 74 8 bit value 16 bit value Function Note From From 0 - 360° 65535 Default @ 0 Welding - P7: Saturation 8 bit value 16 bit value Function Note From From 0 - 100% 65535 Default @ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 75 Source Emulation Macro (when Source Emulation Category @ Category 3 - Discharge) 8 bit value 16 bit value Function Note From From Default @ 0 High Pressure Sodium Low Pressure Sodium Mercury Vapor Metal Halide Ceramic Carbon Arc Xenon RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 76 Computer Monitor Electroluminescence Blow Torch Road Flare Amber Caution Green Traffic Light Yellow Traffic Light Red Traffic Light Blue Glow Stick Green Glow Stick Red Glow Stick Yellow Glow Stick Pink Glow Stick Violet Glow Stick RESERVED PROLIGHTS - EclPanel TWCXL...
  • Page 77 Parameter 6 FX Parameter 5 FX Parameter 5 Parameter 6 Fine Fine Parameter 7 FX Parameter 6 FX Parameter 6 Parameter 7 Fine Fine Parameter 8 FX Parameter 7 FX Parameter Parameter 8 Fine 7 Fine PROLIGHTS - EclPanel TWCXL...
  • Page 78 Fan Mode Quiet 2 Const. Out. Fan Mode Off Const. Out. Fan Mode Quiet 1 Dyn. Out Fan Mode Quiet 2 Dyn. Out Fan Mode Off Dyn. Out Reserved for future use Reserved for future use Reserved for future use PROLIGHTS - EclPanel TWCXL...
  • Page 79 Backlight Button 30s Backlight Button 60s Backlight Dimmer Off Backlight Dimmer 25% Backlight Dimmer 50% Backlight Dimmer 75% Backlight Dimmer 100% Flip Display Off Flip Display On Flip Display Auto Reserved for future use RESET ALL CHANNELS CONTROLLED PROLIGHTS - EclPanel TWCXL...
  • Page 80 Preset 13 GEL - Rosco 3408, Base CCT 5600K Preset 14 GEL - Lee 187, Base CCT 3200K Preset 15 GEL - Rosco 3152, Base CCT 3200K Preset 16 GEL - Lee 162, Base CCT 3200K Reserved PROLIGHTS - EclPanel TWCXL...
  • Page 81 Fixed Fan Speed (50%) - Maximum Quiet 1 CLO power available 80% Fixed Fan Speed (35%) - Maximum Quiet 2 CLO power available 65% Fixed Fan Speed (0%) - Maximum Off CLO power available 50% Reserved PROLIGHTS - EclPanel TWCXL...
  • Page 82 48 Pixel direct control for videomapping CCT (2800 - 10000K), RGBW and Color Macros, Film 1M12CH 8bit, matching Film Mode 1M12CH of ECLPANELs CCT (2800 - 10000K), RGBW and Color Macros, 16 Film 2M20CH bit, matching Film Mode 2M20CH of ECLPANELs PROLIGHTS - EclPanel TWCXL...
  • Page 83 0÷100% PIXEL 2 WHITE 000 ÷ 255 0÷100% PIXEL 48 RED 000 ÷ 255 0÷100% PIXEL 48 GREEN 000 ÷ 255 0÷100% PIXEL 48 BLUE 000 ÷ 255 0÷100% PIXEL 48 WHITE 000 ÷ 255 0÷100% PROLIGHTS - EclPanel TWCXL...
  • Page 84 BLUE CROSSFADE FROM CCT TO COLOR WHITE CROSSFADE FROM CCT TO COLOR FINE FAN CONTROL COLOR MACRO RED FINE STROBE GREEN CONTROL GREEN FINE BLUE BLUE FINE WHITE WHITE FINE FAN CONTROL COLOR MACRO STROBE CONTROL PROLIGHTS - EclPanel TWCXL...
  • Page 85 Full plus green 245 ÷ 255 HUE FINE 000 ÷ 255 CROSSFADE FROM CCT TO COLOR 0÷100% 000 ÷ 255 CROSSFADE FROM CCT TO COLOR FINE 000 ÷ 255 0÷100% 000 ÷ 255 RED FINE 000 ÷ 255 PROLIGHTS - EclPanel TWCXL...
  • Page 86 088 ÷ 089 Dark Yellow Green 090 ÷ 091 Just Blue 092 ÷ 093 Sky Blue 094 ÷ 095 Lavender 096 ÷ 097 Light Lavender 098 ÷ 099 Pink Carnation 100 ÷ 101 Medium Pink 102 ÷ 103 PROLIGHTS - EclPanel TWCXL...
  • Page 87 056 ÷ 057 LED FREQUENCY 10KHZ 058 ÷ 059 LED FREQUENCY 12KHZ 060 ÷ 061 LED FREQUENCY 15KHZ 062 ÷ 063 LED FREQUENCY 20KHZ 064 ÷ 065 RESERVED 066 ÷ 253 RESET ALL CHANNELS CONTROLLED 254 ÷ 255 PROLIGHTS - EclPanel TWCXL...

  • Page 88: Accessories Installation

    DETAIL 2 Loosen and remove the screws and tilt knobs (A, DETAIL 1). Then remove the standard bracket (B). Mount the Short Bracket accessory (C) and mount the screws and tilt knobs removed (DETAIL 1). Fig. 08 PROLIGHTS - EclPanel TWCXL...

  • Page 89: Egg Crate (Codes Eptwcxlec30, Eptwcxlec60, Eptwcxlec48C - Op.)

    (C), inside the track guides of the side holder (D). Then diffusion filter holder (B) in its original position and release the spring plunger (A). NOTE: this guide is valid for all egg-crates accessories. Fig. 09 PROLIGHTS - EclPanel TWCXL...

  • Page 90: Front Intensified Diffusion Filter (Codes Eptwcxlfilterint - Optional)

    FRONT HIGH / MEDIUM / LOW DIFFUSION FILTER (CODES EPTWCXLFILTERHD / MD / LD - OPTIONAL) Pull the spring plunger (A) and remove the diffusion filter holder (B). Then replace it with another filter Then release the spring plunger (A). Fig. 10 PROLIGHTS - EclPanel TWCXL...

  • Page 91: Maintenance

    WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel.

  • Page 92: Troubleshooting

    • Check if the Fuse is intact and eventually replace it if fault. necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in...
  • Page 93 Note...
  • Page 94 Note...
  • Page 96 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
