ProLights ECLIPSEHDTWC User Manual page 6

6 ECLIPSEHDTWC
ELETTRONICHE
• Dimmer: Linear 0~100% electronic dimmer
• Dimmer Curves: 4 Different dimming curves available
• Strobe/Shutter: 1-25 Hz, electronic
• Operating Temperature: -10° ~ +45°
• Flicker: Flicker free operation
• Selectable PWM: 600~25K Hz
ALIMENTAZIONE
• Power Supply: 100-240V – 50/60Hz
• Power Consumption (at 230V): 252W
• Power Consumption (at 120V): 257W
• Output (at 230V): 14 units on a single power line
• Output (at 120V): 7 units on a single power line
CARATTERISTICHE FISICHE
• Cooling: Combination of heat pipe cooling system and low noise fan
• Suspension And Fixing: Hanging bracket suitable for safe hanging and positioning
• Signal Connection: 5p in/out
• Power Connection: PowerCON in/out
• IP: 20
• Dimensions (WxHxD): 262.1x551x595.5 mm
• Weight: 7,83kg
595.5
262.1
Disegno tecnico
Fig.1
